400CP REMOTE CONTROL PANEL
INTRODUCTION
The NSI 400CP represents a key part of a state of the art, total lighting control system. Combined with NSI
dimmers and optionally, an NSI memory control console, a totally integrated system is achieved.
The 400CP can automatically take control of up to 512 dimmer channels. Control is automatically passed between
400CP' s and the memory control console as desired. The 400CP is exceptionally easy to operate and features 4
zone control with programmable fade times. Remote lockout capability is also included. Installation is a snap
with the simple 4 wire digital connection required.
Programming differs from older 400CP panels (prior to release 3.00), please read instructions.
400CP control panels with software release 3.00 and higher are not directly compatible and will not
operate with older 400CP panels with software prior to release 3.00. Contact dealer or factory for
modifications if necessary.
NSI dimming systems used with these release 3.00 panels require the following software releases:
LUMA-NET
INSTALLATION AND OPERATION GUIDE
Software Revision 3.00, Version C
2408CD, 2408CR, 2404CD
DDS 8600/8800/9600/9800
DDS 6000
DDS 5300/5500/5600
* Optional interface kit required for these units.
IMPORTANT
release 2.30 and above.
release 1.30 and above. *
release 1.30 and above. *
release 1.30 and above. *

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUMA-NET 400CP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NSI LUMA-NET 400CP

  • Page 1 INSTALLATION AND OPERATION GUIDE INTRODUCTION The NSI 400CP represents a key part of a state of the art, total lighting control system. Combined with NSI dimmers and optionally, an NSI memory control console, a totally integrated system is achieved. The 400CP can automatically take control of up to 512 dimmer channels. Control is automatically passed between 400CP’...
  • Page 2: System Turn-On

    The 400CP may be connected to the dimming system via parallel or daisy-chained wiring. Due to power supply current demands, 400CP’ s must be limited to 5 units per daisy chain run with 22 awg wire, or 10 units with 20 AWG wire.
  • Page 3 Quickly flashing LOCKOUT Any 400CP may be disabled from operation with a remote key switch or other contact closure. Several Luma-net panels of the same version may be connected to the same contacts in parallel as long as polarity is maintained.
  • Page 4 Factory Default Setting: The 400CP is programmed at the factory for zone 1-4 to be set for channel 1-4 respectively. The fade rate ant other parameters are also set to factory defaults. This may be acceptable for initial testing. If necessary to return the 400CP panel to it’...
  • Page 5 The maximum number of dimmers may be set as follows: Make sure that the 400CP is in the program select mode as discussed. Press the zone 1 increase button and the BUSY led will quit flashing. Press button representing desired number of dimmers as shown in the diagram.
  • Page 6 To program each zone: Make sure that the 400CP is in the program select mode as discussed. The BUSY LED should be flashing. Press the zone 2 increase button to select "dimmer assignment mode" and the BUSY LED will stop flashing.
  • Page 7 If the factory default setting of 5 seconds is desired for each zone then this step may be ignored. To program zone fade time: Make sure that the 400CP is in the program select mode as discussed. Press the zone 3 increase button to enter "fade time mode"and the BUSY LED will stop flashing.
  • Page 8 Master/Slave Mode . 400CP panels may be slaved to one another. Several panels may act as slaves to a master panel which contains the programming. The slaves will mimic the master LED’ s and will operate the scenes and fade times of the master.
  • Page 9 To set Network ID number (units without dipswitch): Make sure that the 400CP is in the program mode as discussed. Press the zone 1,2,3,4 increase buttons at the same time and the BUSY LED will stop flashing Look up the necessary sequence of 1’ s and 0’ for the ID number on the chart at the end of this section.
  • Page 10 400CP REMOTE CONTROL PANEL Software Revision 3.00, Version C ID number codes / dipswitch settings ID number 12345678 ID number 00000000 11000000 01100000 10010000 00110000 11110000 01001000 10101000 00011000 11011000 01111000 10000100 00100100 11100100 01010100 10110100 00001100 11001100 01101100 10011100...
  • Page 11: Operation

    Simply perform a change in the channel level from the console. The lighting channel will then fade back to the new console level at the same fade rate as last commanded by the 400CP for that channel. Once the console level matches or is moved past the lighting level, full console control will be resumed for that channel.
  • Page 12: Warranty

    400CP REMOTE CONTROL PANEL OPERATION Software Revision 3.00, Version C NSI Corporation Limited Warranty WARRANTY NSI Corporation Limited Warranty NSI Corporation warrants new electronics products to be free from defective materials and workmanship for a period of one (1) year from the date of purchase to the original owner when purchased from an authorized NSI dealer.
