REMOTE CONTROL PANEL
INSTALLATION AND OPERATION GUIDE
INTRODUCTION
The NSI 404CP and 408CP represents a key part of a state of the art, total lighting control system. Combined
with NSI dimmers and optionally, an NSI memory control console, a totally integrated system is achieved.
The 404CP can automatically take control and preset the lighting level of up to 100 dimmer channels, while the
408CP will control 45 of 100 dimmer channels. Control is automatically passed between control panels and the
memory control console as desired. The 404CP features 4 scene control while the 408CP features 8 scene control.
Both units have programmable fade times and are exceptionally easy to operate. Remote lockout capability is also
included. Installation is a snap with the simple 4 wire digital connection required.
Programming differs from other Luma-net panels, please read instructions.
Luma-net control panels with software release 3.00 and higher are not directly compatible and will
not operate with older 400CP panels with software prior to release 3.00. Contact dealer or factory
for modifications if necessary.
NSI dimming systems used with these release 3.00 panels require the following software releases:
NSI CORPORATION
LUMA-NET
404CP / 408CP
Software Revision 3.00, Version C
IMPORTANT
2408CD, 2408CR, 2404CD
DDS 8600/8800/9600/9800
DDS 6000
DDS 5300/5500/5600
* Optional interface kit required for these units.
release 2.30 and above.
release 1.30 and above. *
release 1.30 and above. *
release 1.30 and above. *
1
Advertisement
Related Manuals for NSI 404CP
Summary of Contents for NSI 404CP
- Page 1 Software Revision 3.00, Version C INTRODUCTION The NSI 404CP and 408CP represents a key part of a state of the art, total lighting control system. Combined with NSI dimmers and optionally, an NSI memory control console, a totally integrated system is achieved.
-
Page 2: System Turn-On
PC board or connections with fingers or metal objects. On daisy-chain runs, the panels closest to the dimming system should be connected first. 404CP and 408CP panels have dip switches to set network ID number and must have their ID programmed before the system power is connected. - Page 3 LOCKOUT Any 404CP and 408CP may be disabled from operation with a remote key switch or other contact closure. Several Luma-net panels of the same version may be connected to the same contacts in parallel as long as polarity is maintained.
- Page 4 Factory Default Setting: The 404CP and 408CP are programmed at the factory for scene 1-3 (1-7) to be set for channel 1-4 (1-8) respectively. Scene 4 (8) is programmed for dimmers 1-8 off. The fade rate and other parameters are also set to factory defaults.
- Page 5 LEDs of the dimmers may be observed to verify channel selection. To program each scene: Make sure that the 404CP or 408CP is in the program select mode as discussed. The BUSY LED should be flashing.
- Page 6 Software Revision 3.00, Version C Assigning dimmer levels to each scene. Each of the scenes of the 404CP and 408CP must be programmed with the desired levels for each dimmer assigned to the scene. In order to easily identify dimmer channels while programming, the system should have all installed lamps or loads operational.
- Page 7 5 seconds is desired for each zone then this step may be ignored. To program scene fade time: Make sure that the 404CP or 408CP is in the program select mode as discussed. Press the SCENE 3 button to enter the "Fade time mode", and the BUSY LED will stop flashing.
- Page 8 Master/Slave Mode 404CP or 408CP panels may be slaved to one another. Several panels may act as slaves to a master panel which contains the programming. The slaves will mimic the master LED’ s and will operate the scenes and fade times of the master.
- Page 9 REMOTE CONTROL PANEL Software Revision 3.00, Version C Network ID number. Since the Luma-net System is a digital network, all panels and devices attached (except dimmers) must have a unique network ID number. If two panels have the same network ID number, the entire network will stop functioning.
- Page 10 REMOTE CONTROL PANEL Software Revision 3.00, Version C ID number codes / dipswitch settings ID number 12345678 ID number 00000000 11000000 01100000 10010000 00110000 11110000 01001000 10101000 00011000 11011000 01111000 10000100 00100100 11100100 01010100 10110100 00001100 11001100 01101100 10011100 00111100...
-
Page 11: Operation
REMOTE CONTROL PANEL OPERATION Software Revision 3.00, Version C To select a scene: OPERATION To select a scene: Press the button of the scene desired. The LED above each scene indicates that the scene is currently active. The LED will go out when an operation on the same or different panel causes a change to a dimmer contained in the... -
Page 12: Remote Control Panel
REMOTE CONTROL PANEL OPERATION Software Revision 3.00, Version C NSI Corporation Limited Warranty WARRANTY NSI Corporation Limited Warranty NSI Corporation warrants new electronics products to be free from defective materials and workmanship for a period of one (1) year from the date of purchase to the original owner when purchased from an authorized NSI dealer.
