Hannlomax HX-508R Quick Start Manual

Alarm Clock Radio with Bluetooth and USB MP3 playback
(Bluetooth Pairing code: HX-508R HANNLOMAX)
1 / FUNC button
2 / TIME SET button
3  / DN button
4  / UP button
5 AL ON/OFF button
6 REPEAT/MEM/SNOOZE button
7 M+/ ■ / SNOOZE button
8 VOLUME + button
9 VOLUME − button
CONNECTING THE UNIT TO POWER
AC OPERATION
Plug one end of the AC adaptor into the DC power Input, and then plug the other end into AC wall outlet.
Before switching on the unit, make sure that the voltage of your electricity supply is the same as that
indicated on the rating plate.
Attention:
1. Do not plug or unplug the power cable while you have wet hands.
2. When planning not to use this unit for a long time, disconnect the power cable from the wall outlet.
3. When disconnecting the power cord from the wall outlet, do not pull on the cord in order to avoid shock
risks caused by damaged cable.
BATTERY OPERATION
Disconnect the AC cord set completely. Open the battery compartment door and insert 4 pieces UM-2 "C"
size batteries into the battery compartment with battery polarity as shown inside the battery compartment.
Model : HX-508R
10 FOLDER DN /DIM. button
11 FOLDER UP / SLEEP button
12 Speaker
13 LCD display
14 Rod antenna
15 USB port
16 AUX-IN jack
17 DC jack
18 Battery compartment
-1-
DIMMER (Control the brightness of the display)
1, Press and hold FOLDER DN /DIM. Button. The Display will show "H 1" (Default setting)
2. Press FOLDER DN /DIM. Button to select the desired display brightness. The brightness level:
H1 ＞ d6 ＞ d5 ＞ d4 ＞ d3 ＞ d2 ＞ d1 ＞ OFF
SETTING THE CLOCK
1. You can only perform the Clock setting when the unit is OFF.
(To ensure the unit is OFF, press and hold the
"OFF" and then the time)
2. Press and hold / TIME SET button. The HOUR digit will begin to flash on the display.
3. Press the  / DN or  / UP button to adjust the hour.
4. When the hour is selected, press the
on the display.
5. Press the  / DN or  / UP button to adjust the minute. When the minute is selected, press the
TIME SET button again.
SETTING THE ALARMS
1. You can only perform the Alarm setting when the unit is OFF mode. Press and hold the AL ON/OFF
button. The ALARM time will begin to show on the display with hour digit flashing.
2. Press / DN or  / UP button to adjust the alarm hour.
3. When the desired alarm hour is selected, press the AL ON/OFF button to confirm. The alarm minute
digit will flash.
4. Press the  / DN or  / UP button to select the alarm minute.
5. When the desired alarm minute is selected, press the AL ON/OFF button to confirm.
6. Press the  / DN or  / UP button to select the alarm wake up source. :
BU: BUZZER
RADIO FREQUENCY: FM RADIO
USb: USB MP3 Playback
7. When the desired alarm alarm wake up source is selected, press the AL ON/OFF button to confirm.
Note : If you choose Radio as the alarm wake up source, when alarm activates, it will go to the last FM
radio station that you listened.
If you choose USB as the alarm wake up source, when alarm activates, it will play the music files in the
USB stick. (It will switch to buzzer alarm if USB device is not inserted or cannot be read)
SNOOZE FUNCTION
1. Whenever the alarm activates, it can be temporarily suspended for a short period of 9 minutes by
pressing the REPEAT/MEM/SNOOZE button or M+/ ■ / SNOOZE button once. The Alarm indicator will
keep flashing.
2. The alarm will then automatically activate again after the 9 minutes SNOOZE period has ended.
3. This procedure can be repeated for up to approximately one hour.
TURN OFF THE ALARM
When the Alarm activate, press the AL ON/OFF button to turn off the Alarm.
TO CANCEL THE ALARM SETTING
Press the AL ON/OFF button repeatedly to cancel the alarm setting. The alarm indicator will go off
/ FUNC button for about 1 second. The display will show
/ TIME SET button again, the MINUTE digit will begin to flash
