MENARDS ITEM #641-5271
MODEL #1849FM-23-274
ATTACH YOUR RECEIPT HERE
48" ELECTRIC FIREPLACE
ENTERTAINMENT CENTER
ASSEMBLY, CARE & USE INSTRUCTIONS
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer service department
at 1-855-571-1044 9 a.m. - 5 p.m., EST, Monday - Friday. www.greentouchhome.com.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Greentouch 1849FM-23-274
Summary of Contents for Greentouch 1849FM-23-274
- Page 1 MENARDS ITEM #641-5271 MODEL #1849FM-23-274 ATTACH YOUR RECEIPT HERE 48” ELECTRIC FIREPLACE ENTERTAINMENT CENTER ASSEMBLY, CARE & USE INSTRUCTIONS Serial Number__________________ Purchase Date__________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-855-571-1044 9 a.m. - 5 p.m., EST, Monday - Friday. www.greentouchhome.com.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents ................................3 Hardware Contents .................................4 Safety Information ................................4 Preparation ..................................8 Assembly Instructions ..............................8 Change Door Panels (Optional) ............................18 Maximum Recommended Weight Loads........................18 Operating Instructions ..............................19 Care And Maintenance ..............................21 Troubleshooting ................................22 One-Year Limited Warranty ............................23 Replacement Parts List ..............................24... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Wood Door Panel Corner Panel Center Back Panel Partition Back Panel Center Shelf Fireplace Brick Wall Left Outer Wall Base Right Outer Wall Fireplace Glass Front Left Middle Wall Fire Log Right Middle Wall Fireplace Grate Remote Control (Battery Shelf... -
Page 4: Hardware Contents
HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Wooden Dowel Long Bolt Washer Screw L-Bracket Back Panel Shelf Pin x 28 x 24 x 24 Screw x 16 x 32 Grate Screw Door Pull Touch-up Pen Hinge Hinge Screw Tip Restraint Hardware SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. - Page 5 SAFETY INFORMATION (CONTINUED) Modifications not approved by the party responsible for compliance could void user’s authority to operate the equipment. This Class B digital apparatus complies with Canadian ICES-003. IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: DANGER •...
- Page 6 SAFETY INFORMATION (CONTINUED) • Each surface intended to support a load shall have a corresponding statement in the use instructions specifying the maximum intended load for that surface in pounds (kilograms). • Risk of electric shock-connect this furnishing to a properly grounded outlet only. See Grounding Instructions. •...
- Page 7 SAFETY INFORMATION (CONTINUED) Electrical Connection • A 15-Amp, 120-volt, 60 Hz circuit with a properly grounded outlet is required. Preferably, the fireplace will be on a dedicated circuit as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to blow when the heater is in operation.
-
Page 8: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 50 minutes Tools Required for Assembly (not included): Phillips screwdriver ASSEMBLY INSTRUCTIONS 1. - Page 9 ASSEMBLY INSTRUCTIONS (CONTINUED) 2. Insert two wooden dowels (AA) into outer holes on right side of base (P). Attach right outer wall (F), securing with two washers (CC) and two long bolts (BB). Repeat for left outer wall (E). Wooden Dowel Long Bolt Washer 3.
- Page 10 ASSEMBLY INSTRUCTIONS (CONTINUED) 4. Insert two wooden dowels (AA) into the top outer holes on left outer wall (E), left middle wall (G), right middle wall (H) and right outer wall (F). Attach center shelf (D), securing from underneath with eight washers (CC) and eight long bolts (BB).
- Page 11 ASSEMBLY INSTRUCTIONS (CONTINUED) 6. Insert six wooden dowels (AA) into the top outer holes of corner panel (B) and partition (C). Attach top (A), securing with four washers (CC) and four long bolts (BB). Wooden Dowel Long Bolt Washer 7. Place the fireplace grate (S) by matching the bottom pins into the holes on the base (P), secure with screwing two grate screws (HH) by Phillips screwdriver.
- Page 12 ASSEMBLY INSTRUCTIONS (CONTINUED) 8. Remove the film from the adhesive on the top of the fireplace grate (S) and place the fire log (R) on the center of the fireplace grate (S). 9. Screw two L-bracket (EE) onto the fireplace brick wall (O) using four screws (DD). Screw L-Bracket...
- Page 13 ASSEMBLY INSTRUCTIONS (CONTINUED) 10. Align the USB cable from behind through the cable hole on the fireplace brick wall (O). Attach the USB cable from the heater into the USB port behind the fireplace grate (S). Insert the fireplace brick wall (O) into the mantel, slotting it into the grooves on base (P).
- Page 14 ASSEMBLY INSTRUCTIONS (CONTINUED) 12. Insert shelf pins (GG) at desired height, ensuring they are level. Place shelf (I) on top of shelf pins (GG). Repeat for remaining shelves (I). x 16 Shelf Pin 13. Note: The door comes with two different glass door panel/wood door panel options. To select the desired door panel before installing the hinges on doors (J/K).
- Page 15 ASSEMBLY INSTRUCTIONS (CONTINUED) 14. Place door pull (II) into predrilled hole on right door (K), securing with two door pull screws. Repeat for remaining door pull (II). Door Pull 15. Install the doors I. Loosen the screws on the hinge arms and plates pre-attached on the outer walls (E and F). II.
- Page 16 ASSEMBLY INSTRUCTIONS (CONTINUED) 16. If you need to adjust the doors, do so in the following manner. To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws. To adjust door left or right, turn screws (b) on both hinges, in and out. To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.
- Page 17 ASSEMBLY INSTRUCTIONS (CONTINUED) WARNING: You must install the tip restraint hardware to help prevent any accidents or damage to the unit. We strongly recommend attaching the tip restraint hardware to a wall stud and your unit. For all other wall types, please visit your local hardware store to obtain the proper hardware.
-
Page 18: Change Door Panels (Optional)
MAXIMUM LOAD 6.8 kg / 15 lb MAXIMUM LOAD 6.8 kg / 15 lb MAXIMUM LOAD 6.8 kg / 15 lb SKU#641-5271/Model#1849FM-23-274 DISTRIBUTION: Greentouch USA Inc ADDRESS: 207 Byers Creek Rd Ste D Mooresville, NC 28117-6988 COUNTRY OF ORIGIN: VIETNAM MANUFACTURE DATE: MAY, 2021... -
Page 19: Operating Instructions
OPERATING INSTRUCTIONS Control Panel Remote Control To use the remote control, first remove the plastic tab by gently pulling it out of remote control. Controls and Display The control panel will display the heater setting when the unit power is turned ON. Whichever control icon you press will display the current setting of the corresponding function. - Page 20 OPERATING INSTRUCTIONS (CONTINUED) Heater Function • Press the HEATER ICON to display the current heater setting. • Press the HEATER ICON again to scroll down through the heater settings. Note: Long-hold the icon to quickly scroll through settings. • Set the heater to “HI” (High) to have the heater run continually. •...
-
Page 21: Care And Maintenance
CARE AND MAINTENANCE • Make sure the unit is turned OFF, unplugged and the heating elements of heater are cool whenever you are cleaning the heater or fireplace. • Clean the metal trim using a water-dampened soft, clean cloth. DO NOT use brass polish or household cleaners as these products will damage the metal trim. -
Page 22: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Error E1 displayed on The overheat sensor has Unplug unit, wait 15-20 minutes, then the sensor will reset control panel. been engaged. itself. Plug the unit back in and turn on the heater. If the problem persists, call customer service (1-855-571-1044). -
Page 23: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY The manufacturer warrants that your new electric fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this electric fireplace in accordance with the installation and operating instructions furnished with the product at all times. -
Page 24: Replacement Parts List
For replacement parts, call our customer service department at 1-855-571-1044 9 a.m. - 5 p.m., EST, Monday - Friday. www.greentouchhome.com. PART DESCRIPTION PART # 1849FM-23-274-TOP Center Shelf 1849FM-23-274-CENTER SHELF Left Outer Wall PF-1849FM-23-274-LEFT OUTER WALL Right Outer Wall PF-1849FM-23-274-RIGHT OUTER WALL Shelf PU17-1849FM-23-274-SHELF Left Door PU17-1849FM-23-274-LEFT DOOR Right Door PU17-1849FM-23-274-RIGHT DOOR...
