Roller Instruction in GRBL Firmware

· What you need
1. USB Type-B Cable
2. Genmistu LC-40 Rotary Roller Module
3. Firmware
4. LaserGRBL/LightBurn
· Firmware Flashing
1. Connect the machine to the power supply and insert the USB
cable.
Power Button
2. Press the repeat engraving button on the back of the machine for
Repeat Engraving
3 seconds, then press the power button to enter the reboot mode.
Open Up_ble_v1.3.exe (Figure 1) and click Start upgrade (Figure 2), the program will flash the
firmware automatically.
3. The firmware upgrade takes about one minute, wait for the progress bar reaches to the end, then
shut down your laser engraver and power it back on. (Figure 3)
Figure 1 Figure 2 Figure 3
05
