Summary of Contents for Malone ProCut 2000
- Page 1 Topper ProCut 2000 Operators Manual ENSURE ALL OPERATORS ARE FAMILIAR WITH THIS OPERATORS MANUAL, BEFORE USING THE MACHINE Issue: 003 Malone Farm Machinery Ballyglass, Claremorris, Co. Mayo, F12 AP11 Republic of Ireland www.malonefm.com...
-
Page 2: Table Of Contents
TECHNICAL DATA ········································································· 5 DESCRIPTION ··············································································· 5 SAFETY INFORMATION ·································································· 6 SAFETY DECALS ············································································ 8 PRE-OPERATION CHECKLIST ························································· 9 OPERATING THE MACHINE ···························································· 9 MAINTEANCE AND LUBRICATION ················································· 10 MALONE LIMITED WARRENTY······················································ 11 10. SPARE PARTS SECTION ································································· 13 Version C - 14/01/2022... -
Page 3: Declaration Of Confirmity
Serial No: ..........................Date: .............. Manufactured by the above company Conforms to EU Engineering Regulations and other relevant EU guidelines. Conforms to UK Engineering Regulations and other relevant UK guidelines. Signed ............................ (on behalf of Malone Farm Machinery) ............................... (Status) -
Page 4: General Information
This manual is an important part of your machine. It should remain with the machine if and when it is sold. If it is damaged or lost, you may contact your dealer, or Malone Farm Machinery company to get a replacement. -
Page 5: Technical Data
Operator Manual—Topper 2. TECHNICAL DATA Type Topper Pro Cut 2000 Number of rotors Diameter of rotor 1.50 m Working width 1.50 m Width of the machine 1.80 m Length 2.20 m Weight 830 kg Necessary tractor power 30 HP / 22 KW PTO shaft speed 400-540 rpm 3 Hitch point... -
Page 6: Safety Information
Operator Manual—Topper SAFETY INFORMATION In the interest of safety, it is important that great care is adopted at all times during the attachment, transportation, operation and maintenance of this machine. Both the owner and the operator of the machine should read and understand the following section to ensure the safety of themselves and all other persons who enter into the close proximity of these machines. - Page 7 Operator Manual—Topper Never permit anyone between the machine and the tractor whilst either is working or when the • machine is in a raised position. Be aware at all times of the width, height and length of any machinery you are operating, especially •...
-
Page 8: Safety Decals
Operator Manual—Topper SAFETY DECALS Safety decals must be replaced if stickers are missing or become illegible Read the operator’s manual carefully before you operate the machine. Reading the operators manual ensure safe operation of the machine Keep clear of the machine when the rotors are in motion. -
Page 9: Pre-Operation Checklist
• and consult Malone Engineering regarding your concern. (If the Topper's warranty has expired, you may contact another competent mechanical engineer). Malone Engineering takes no responsibility for accidents, injuries or loss of limbs when using the • equipment. OPERATING THE MACHINE... -
Page 10: Mainteance And Lubrication
Operator Manual—Topper MAINTENANCE AND LUBRICATION Check, and tighten (if required), all nuts, bolts and fixing after the first few hours of work and at regular intervals thereafter. Grease PTO shaft every 20 hours of operation and pre / post season. Good maintenance of a machine will ensure a safe working environment and long service life of the machine. -
Page 11: Malone Limited Warrenty
Malone warranty system. These conditions are subject to the following exceptions: Parts of the machine which are not of Malone manufacture, such as tyres, tines, PTO shafts, slip • clutches, hydraulic cylinders, etc. are not covered by this Limited Warranty, but are subject to the warranty of the original manufacturer. - Page 12 This Limited Warranty cannot be assigned or transferred to anyone without the prior written consent • of the company. Malone dealers have no right or authority to assume any obligation or take any decision on the • company's behalf, whether expressly or tacitly.
-
Page 13: Spare Parts Section
Spare Parts Topper... - Page 14 Spare Parts —Topper SPARE PARTS SECTION To be assured of the latest design improvements purchase your Genuine Replacements from the Original Equipment Manufacturer through your local Dealer. Always quote: Machine Type • Year of manufacture • Serial Number • Part Code •...
- Page 15 Spare Parts —Topper ITEM QTY PART NUMBER DESCRIPTION MNLW16 M16 NORDLOCK WASHER M9331240N M12 X 40MM BOLT + NUT M9331250N M12 X 50MM BOLT + NUT M9331650N M16 X 50MM BOLT + NUT M9332060N M20 X 60MM BOLT + NUT M9332450N M24 X 50MM BOLT + NUT MAT10003...
- Page 16 Spare Parts —Topper Malone Farm Machinery Ballyglass, Claremorris Co. Mayo, Ireland. F12 AP11 Tel +353 (0) 94 936 0500 www.malonefm.com...
