Cantilever Shelving Mounting Assembly– Ford Transit High Roof
Page 2
Packaging Contents
Page 3–4
Requirements
Pages 4–5
Assembly Instructions
PRIME DESIGN, A SAFE FLEET BRAND ▪ Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118
Toll Free: 1.8.PRIME.RACK ▪ Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net
Advertisement
Related Manuals for Safe Fleet Prime Design CSM-1001 Series
Summary of Contents for Safe Fleet Prime Design CSM-1001 Series
- Page 1 Page 2 Packaging Contents Page 3–4 Requirements Pages 4–5 Assembly Instructions PRIME DESIGN, A SAFE FLEET BRAND ▪ Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 Toll Free: 1.8.PRIME.RACK ▪ Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net...
-
Page 2: Contents Overview
CONTENTS OVERVIEW 1—Cantilever Shelving Mounting System .... (Qty 1) Ford Transit, High Roof Interior Mounting Assembly (6X) 51.00” Mounting Channel Assembly (1X) 24.00” Mounting Channel Assembly (1X) 32.00” Mounting Channel Assembly (1X) 2—HKT-0203 ............(Qty 1) Nut Rivet (6X) M8 x 18MM (6X) M8 x 25MM (12X) Caddy Mounting Spacer (6X) -
Page 3: Assembly Requirements
ASSEMBLY REQUIREMENTS INSTALLER NOTE: It is important to correctly follow these assembly instructions. These instructions for REQUIRED assembly are provided by the manufacturer at time of Cantilever Shelving delivery, and reflect the technical Plus Nut Applicator Tool specifications applicable at the time of writing. •... -
Page 4: Assembly Overview
ASSEMBLY OVERVIEW NOTE: Mounting Assembly shown installed with Uprights for illustrative purpose only. Separate purchase is required for Uprights and Shelves. CSM ASSEMBLY SEQUENCE Locate the factory tie in hole locations on the Service Body and align with an Interior Mounting Assembly as shown.Hold into position for drilling location in Step 1.2 Drill into the... - Page 5 Attach the Interior Mounting Assembly with Hardware as Install Hardware into the lower Mounting Assembly hole shown into the factory tie in hole. Torque to 90 in-lbs. as shown. Torque to 90 in-lbs. M8 x 25MM Bolt Lock Washer Caddy Mounting Spacer Flat Washer Flat Washer Lock Washer...
