- Page 1 Clima Mobile Aluminium Tower 1450/850 Clima 3T - Through the Trapdoor Method Instruction Manual EN 1004-2 en...
- Page 2 BoSS Clima 3T Instruction Manual...
-
Page 3: Table Of Contents
Contents Safety First Introduction Tower Designation Maintenance - Storage - Transport Building the Tower Pre-Assembly Checks Component Diagram Quantity Schedule Stabilisers Assembly 2.5.1 Assembly General: Steps 2.5.2 Assembly For 1450 Towers: Steps 2.5.3 Assembly For 850 Towers: Steps Dismantling Using the Tower Safety Checklist Pre-Use Checklist Movement Of The Assembled Prefabricated Tower Scaffold... -
Page 4: Safety First
Verification and assessment documentation is held by Werner UK Sales & Distribution Ltd. Compliances The BoSS Clima 3T mobile tower system has been designed, tested, approved and certified to EN 1004-1:2020. This instruction manual is in compliance with EN 1004-2-en. -
Page 5: Tower Designation
Clear Height Class (H1 = 1.85m, H2 = 1.90m) *UDL = Uniformly distributed load Maintenance - Storage – Transport • The BoSS mobile tower system is robust and requires little maintenance. • All components and their parts should be regularly inspected to identify damage, particularly to joints. -
Page 6: Building The Tower
• Check the surface is level within the 210mm range of the adjustable legs. • Only components specified in this manual shall be used with BoSS towers. Check all required components are onsite and in a suitable working condition. •... - Page 7 Building The Tower • Check this manual is available and its contents familiar to all those involved. • If assembling outdoors; check the forecast windspeed. ○ The assembled tower is certified to wind forces equating to 27mph, but handling components under those conditions would be hazardous.
-
Page 8: Component Diagram
Building The Tower Component Diagram Horizontal Brace Side Toe Board End Toe Board Platform (Fixed and Trapdoor Platforms) Diagonal Brace Clima Frame 8 Rung Stabiliser Clima Frame 4 Rung Adjustable Leg Castor Instruction Manual BoSS Clima 3T Instruction Manual... - Page 9 Building The Tower Component Weights Component Code Name Weight (kgs) 32842300 Castor 150mm 33551300 Adjustable Leg 39251300 Clima Frame 850 4 Rung 39451300 Clima Frame 850 6 Rung 39351300 Clima Frame 850 8 Rung 39151300 Clima Frame 1450 4 Rung 39751300 Clima Frame 1450 6 Rung 39651300...
-
Page 10: Assembly For 1450 Towers: Steps 4 To
Building The Tower BoSS Clima 3T Instruction Manual... -
Page 11: Assembly For 850 Towers: Steps 4 To
Building The Tower bossaccesstowers.com... -
Page 12: Quantity Schedule
High clearance frames must not be used in conjunction with walk-through frames. Component Weight Description Code (kg) High Clearance Frame 30051500 10.0 1.8m High Clearance Frame 30151500 12.0 2.5m BoSS Clima 3T Instruction Manual... -
Page 13: Stabilisers
Building The Tower Walk-through Frame If end walk-through access is required at the base of 2.2m, 4.2m, 6.2m, 8.2m, 10.2m or 12.2m platform height, 1450 wide towers, walk-through frames may be used. In this case the 1m clima frames must be fitted above the walk-through frames. -
Page 14: Assembly
Ensure when the base is levelled the distance from the ground to the first climbing rung is less than 400mm. • Stabilisers of the size specified in the quantity schedule should be fitted at the earliest opportunity. BoSS Clima 3T Instruction Manual... - Page 15 Building The Tower • Always start assembly with the smallest end frames at the base. Platform Height (m) Frame at Base 1.7, 2.2, 3.7, 4.2, 5.7, 6.2, 7.7, 9.7, 10.2, 11.7,12.2 4 Rung 2.7, 4.7, 6.7, 8.7, 10.7 6 Rung 1.2, 3.2, 5.2, 7.2, 9.2, 11.2 8 Rung •...
- Page 16 Fit a second horizontal brace between the bottom rungs on the other side of the frames to square the tower. Assembly for 1450 towers, see page 15 for following steps. Assembly for 850 towers, see page 18 for following steps. BoSS Clima 3T Instruction Manual...
- Page 17 Building The Tower 2.5.2 Assembly For 1450 Towers The procedure illustrated shows a tower starting with a 4 rung frame. Fit two additional end frames and INTERLOCK CLIP check that the frame interlock clips Locked Unlocked are engaged. Fit two diagonal braces (blue) in opposite directions between the 2 and the 6 rungs.
- Page 18 (in that order) on both sides of the platform. When horizontal braces are fitted as guardrails, they should be 0.5m and 1.0m (2 and 4 rungs) above the platform level. Do not climb onto the platform until all guardrails are in place. BoSS Clima 3T Instruction Manual...
- Page 19 Building the Tower Continue the procedure until the required height is reached, adding additional pairs of end frames, diagonal braces and fitting trapdoor platforms, as shown on previous steps. At every platform level, add horizontal braces as guardrails from the protected position within the trapdoor (as shown in Step 6).
- Page 20 The procedure illustrated shows a tower starting with an 8 rung frame. Fit a trapdoor platform on the 4 rung. Fix the horizontal braces as guardrails on the 6 and 8 rungs (2 and 4 rungs above the platform) on both sides of the tower. BoSS Clima 3T Instruction Manual...
- Page 21 Building The Tower Fit two diagonal braces (blue) in opposite directions between the 2 and 6 rungs. Ensure the frames are vertical and level by checking with a spirit level and setting the adjustable legs as necessary. Fit the next pair of end frames and check the frame interlock clips are engaged.
- Page 22 2 and 4 rungs above the platform (in that order) on both sides of the platform (as shown in Step 7). Fit these guardrail braces from the protected trapdoor position. BoSS Clima 3T Instruction Manual...
-
Page 23: Dismantling
Building The Tower Fit the toe boards. The tower is now complete. Dismantling To dismantle the tower, reverse the assembly procedure. When removing the guardrails unlock the four claws furthest from the trapdoor and return immediately to the protected position within the trapdoor. The other claws can then be unlocked, and the guardrails removed from the tower. -
Page 24: Using The Tower
Correct stabiliser size fitted and positioned Toe boards fitted to working platform Instruction manual available to user No environment changes affecting safe use have occurred or are likely Tower is the correct height for intended use BoSS Clima 3T Instruction Manual... -
Page 25: Use
Using The Tower • This tower must not be used as an anchor point for personal fall arrest equipment. • The tower must only be climbed on the inside, using the access method specified. • This tower provides a work platform. It must not be used to access other structures. -
Page 26: Movement Of The Assembled Prefabricated Tower Scaffold
Beware of rough, sloping ground and high winds. Tower stability is improved by reducing height. • Survey the route to be taken. Assess the ground condition/slope and any overhead obstructions or hazards and wind conditions. BoSS Clima 3T Instruction Manual... - Page 27 Using The Tower • Ensure there are no persons, tools, or materials on the tower. • Release the castor brakes. • Release the stabiliser top clamp to allow the feet to be raised a maximum of 25mm. Re-tighten the clamps. During •...
- Page 28 For further information and support for the Clima or any other products, design advice and services, please contact: Werner UK Sales & Distribution Ltd. Blackwater Trading Estate, The Causeway, Maldon, Essex, CM9 4LJ, United Kingdom WernerCo Hungary Kft. 6000 Kecskemét, Szt.
