Summary of Contents for Mobile ECO MINI

  • Page 2: General Specifications

    Thank you for using our pallet truck. Your pallet truck is made of high quality steel and is designed for the horizontal lifting and transport of loads on a pallet or standardized containers on a level, fixed base. For your safety and correct operation, please carefully read this instruction before using it.

  • Page 3: To Adjust Release Device

    When attaching the handle, you had better squat just behind the pallet truck. Then you: 2.1 Insert the draw-bar onto the pump piston (303), then use a hammer to insert the axle with hole (G105) into the hydraulic pump and draw-bar from the right to left. (See fig. 2 ). 2.2 Let control handle(G117) to the ‘LOWER’...

  • Page 4: Maintenance

    3.4 If the forks do not elevate while pumping in the RAISE position, turn the nut (G104) or screw (318) counter-clockwise until the forks elevate while pumping in the RAISE position. Then check the LOWER and DRIVE position according to item 3.1, 3.2 and item 3.3. 4.

  • Page 5: Troubles Shooting

    6. TROUBLES SHOOTING Trouble Clause Fixing Methods 1 The forks can not be -The hydraulic oil is not enough. -Pour in the oil. up the max height. -Without hydraulic oil. -Fill in the oil. The forks can not be -The oil has impurities. -Change the oil.
  • Page 8 Mobile No. Description Qty. G101 18E101 Release Rod G102 18E102 Chain G103 18E103 Adjusting Bolt G104 18E104 Adjusting Nut G105 18E105 Axle with Hole G106 18E106 Elastic Pin G107 18E107 Bushing G108 18E108 Roller Pin G109 18E109 Pressure Roller G109A...
  • Page 9 Fork Frame Unit...
  • Page 10 Mobile No. Description Qty. G201L 18G201L Fork Frame G202 18G202 Elastic Pin G203L 18G203L Rock - Arm G204 18G204 Bushing G205 18G205 Shaft G206 18G206 Grease Cup G208 18G208 Retaining Ring G209 18G209 Joint G210 18G210 G211 18G211 G212L 18G212L...
  • Page 11 Hydraulic Pump Unit...
  • Page 12 Shaft of loading Wheel 18E317 18E318 Screw 18E319 Lever Plate 18E320 Elastic Pin 18E321 Valve Cartridge 322SL 18E322SL Pump Body For ECO MINI Only 18E323Y Seal Washer 18E324Y Screw Plug 18E325 Seal O – Ring 18E326 18E327 Dust Ring 18E328 Piston Rod...
