A975GOT-TBA/TBD(-B)
A970GOT-TBA/TBD(-B)
Thank you for buying the MELSEC-GOT Series.
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
Mitsubishi Graphic Operation Terminal
A970GOT-SBA/SBD
A970GOT-LBA/LBD
A960GOT-EBA/EBD
MODEL
MODEL
CODE
IB(NA)-80032-H(0512)MEE
User's Manual
(Hardware)
A900GOT-U-JE
1DM100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mitsubishi GOT MELSEC A975GOT-TBA-B
Summary of Contents for Mitsubishi GOT MELSEC A975GOT-TBA-B
- Page 1 A970GOT-LBA/LBD A960GOT-EBA/EBD User’s Manual (Hardware) Thank you for buying the MELSEC-GOT Series. Prior to use, please read both this manual and detailed manual thoroughly and familiarize yourself with the product. MODEL A900GOT-U-JE MODEL 1DM100 CODE IB(NA)-80032-H(0512)MEE Mitsubishi Graphic Operation Terminal...
- Page 2 SAFETY PRECAUTIONS (Read these precautions before using.) When using this equipment, thoroughly read this manual. Also pay careful attention to safety and handle the module properly. These precautions apply only to this equipment. Refer to the user’s manual of the CPU module to use for a description of the PLC system safety precautions.
- Page 3 [DESIGN PRECAUTIONS] DANGER Do not use the GOT as the warning device that may cause a serious accident. An independent and redundant hardware or mechanical interlock is required to configure the device that displays and outputs serious warning. Failure to observe this instruction may result in an accident due to incorrect output or malfunction.
- Page 4 [MOUNTING PRECAUTIONS] CAUTION The GOT should be used in the environment given in the general specifications of this user's manual. Not doing so can cause an electric shock, fire, malfunction or product damage or deterioration. When mounting the GOT main unit to an enclosure, tighten the mounting screws in the specified torque range.
- Page 5 [WIRING PRECAUTIONS] CAUTION Please make sure to ground FG terminal, LG terminal, and protective ground terminal of the GOT power supply unit by applying Class D Grounding (Class 3 Grounding Method) or higher which is used exclusively for the GOT. Not doing so may cause an electric shock or malfunction.
- Page 6 [STARTUP/MAINTENANCE PRECAUTIONS] DANGER When power is on, do not touch the terminals. Doing so can cause an electric shock or malfunction. Before starting cleaning or terminal screw retightening, always switch off the power externally in all phases. Not switching the power off in all phases can cause a module failure or malfunction.
- Page 7 [BACKLIGHT CHANGING PRECAUTIONS] DANGER Before changing the backlight, always switch off the GOT power externally in all phases (when the GOT is connected to the bus, the PLC CPU power must also be switched off externally in all phases) and remove the GOT main unit from the enclosure.
- Page 8 Section 3.2 This manual does not warrant or license any industrial property rights and other rights. Under no circumstances will Mitsubishi Electric be liable or responsible for any consequential problems involving the industrial property rights which may arise as a result of the use of this equipment described in this manual.
-
Page 9: Table Of Contents
CONTENTS 1. Overview .......................1 1.1 Packing List ....................1 2. System Configuration ..................2 3. Specifications ....................3 3.1 General Specifications................3 3.2 Performance specifications...............4 3.3 Power supply specifications..............6 4. Name of the Parts ..................7 5. Handling .......................8 5.1 Handling instructions ................8 5.2 Installation method ...................8 5.3 Wiring diagram ..................11 5.4 The precautions on the wiring..............12 5.5 Connecting to the GOT Power Section...........15... -
Page 10: Overview
1. Overview This user's manual describes the system configuration, specifications, part names, handling and outline dimensions of the A975GOT/A970GOT/A960GOT Graphic operation terminal (Referred to as GOT, hereafter). The following GOT types are available. Item Type Display section A975GOT-TBA,A975GOT-TBD TFT color liquid crystal A975GOT A975GOT-TBA-B,A975GOT-TBD-B TFT color liquid crystal *1 A970GOT-TBA,A970GOT-TBD... -
Page 11: System Configuration
2. System Configuration The overall configuration of the GOT is shown below. Drawing software Communication module, Communication board *1 Option Memory board Flash PC card *1 External I/O interface module *1 Backlight Protective sheet Debug stand Others Audio output device (Commercially available) Printer (Commercially available) *1 Barcode reader (Commercially available) *1 *1: For details of the system configuration, refer to the GOT-A900 Series User’s... -
Page 12: Specifications
3. Specifications 3.1 General specifications Item Specifications Operating Display section 0 to 40°C *1 ambient Other than display section 0 to 55°C temperature Storage ambient -20 to 60°C temperature Operating 10 to 90%RH, non-condensing ambient humidity Storage ambient 10 to 90%RH, non-condensing humidity Frequency Acceleration Amplitude Sweep Count... -
Page 13: Performance Specifications
3.2 Performance specifications Specifications A975GOT- A970GOT- A970GOT- Item TBA(-B) TBA(-B) A970GOT-LBA A960GOT-EBA A975GOT- A970GOT- A970GOT- A970GOT-LBD A960GOT-EBD TBD(-B) TBD(-B) D-STN color Type TFT color liquid crystal monochrome liquid crystal liquid crystal 640 × 480 dots 640 × 400 dots Resolution 192 (7.57) ×... - Page 14 *4: GT Works2 and GT Designer2, are supported from the first version (Version1.00A). *5: The specifications differ depending on the version of GOT (hardware version, function version). (1) Specification differences by the version of GOT The specifications of the GOT-A900 series differ depending on the version (hardware version, function version).
-
Page 15: Power Supply Specifications
3.3 Power supply specifications Specifications A975GOT-TBA(-B) A975GOT-TBD(-B) A970GOT-TBA(-B) A970GOT-TBD(-B) Item A970GOT-SBA A970GOT-SBD A970GOT-LBA A970GOT-LBD A960GOT-EBA A960GOT-EBD Input power supply 100AC to 240V (+10%,-15%) 24VDC(+25%,-20%) voltage 50/60 ± 3 Input frequency [Hz] Using 100VAC Communication board loaded: 50VA or less Communication module loaded: Input max. -
Page 16: Name Of The Parts
4. Name of the Parts 3) 4) 6) 7) 13) 12)11) When 9) is removed 14) 16) Name Description 1) Display section Shows the screen 2) Reset button Used to reset the hardware of the GOT Used to set the condition of access to the PC card when it is loaded during power-on (Factory-set to 3) memory card access switch OFF) -
Page 17: Handling
5. Handling 5.1 Handling instructions When mounting the main unit to a control box or the like, set the display section as shown below. When the temperature inside the enclosure is 40 to 55°C or less, the mounting angle should be in the range 60 to 105 degrees. 105°... - Page 18 (2) Mounting position When mounting the GOT, the following clearances must be left from the other device. (80mm (3.15 inch) or more) (100mm Other (50mm (50mm (3.94 inch) device (1.97inch) (1.97inch) or more) or more) or more) Plate thickness within 2mm to 4mm (0.08inch to 0.16inch) Part A size: As the GOT connection cable is led out downward, the following clearance must be provided in consideration of the bending radius.
- Page 19 (3) Mounting method (a) Put the GOT main unit into the panel opening, with its front face first. (b) Mount the GOT in the following four locations at its top and bottom. (Top) (Bottom) Mounting Position Mounting position (c) How to mount and fix the mounting fixture is given below. 1) Insert the mounting fixture into the fixture fitting portion of the GOT main unit.
-
Page 20: Wiring Diagram
5.3 Wiring diagram (1) 100AC to 240V INPUT 12/24VDC 0.1A RUN OUTPUT 100-240VAC (LG) (FG) DC12/24V (2) DC24V INPUT 24VDC INPUT 12/24VDC 0.1A RUN OUTPUT 24VDC (LG) (FG) DC12/24V * For application of external outputs of RUN OUTPUT, please refer to the[A985GOT/A975GOT/A970GOT/A960GOT User’s Manual]... -
Page 21: The Precautions On The Wiring
5.4 The Precautions on the Wiring DANGER Completely turn off the externally supplied power used in the system when installing or placing wiring. Not completely turning off all power could result in electric shock, damage to the product. CAUTION Be sure to ground the FG terminal and LG terminal of the GOT power supply section to the protective ground conductor. - Page 22 (1) Power supply wiring Separate the GOT's power supply line from the lines for I/O devices and power devices as shown below. When there is much noise, connect an insulation transformer. Power supply wiring diagram Main power GOT power Insulation supply supply Transformer...
- Page 23 (2) Grounding For grounding, perform the following: Use a dedicated grounding wire as far as possible. (Grounding resistance of 100 or less.) When a dedicated grounding cannot be performed, use (2) Common Grounding shown below. Also, be sure to take noise countermeasures other than grounding. Power Power Power...
-
Page 24: Connecting To The Got Power Section
(b) An example of common grounding Power equipment (Servo, etc.) Connection cable CN1A CN1B Grounding terminal block Panel grounding Use a grounding wire as thick and short as possible. * Apply single-point grounding for one system. 5.5 Connecting to the GOT Power Section The following diagram shows the wiring example of power lines, grounding lines, etc. -
Page 25: Connection Cable Wiring
POINT (1) Use the thickest possible (max. 2 mm (14 AWG)) wires for the 100/200 VAC and 24 VDC power cables. Be sure to twist these wires starting at the connection terminals. To prevent a short-circuit should any screws loosen, use solderless terminals with insulation sleeves. (2) When the LG terminals and FG terminals are connected, be sure to ground the wires. -
Page 26: Precautions For Back Light Replacement
0401 AW POWER MAX 115VA DATE 0401 AW Hardware version US LISTED 80M1 IND.CONT.EQ. Production date MITSUBISHI ELECTRIC CORPORATION MADE IN JAPAN BD992C189H02 Conformed standard BACKLIGHT A9GT-70LTTBW Back light model Rating plate (The applicable back light model is described.) The applicable back light differs with the GOT hardware version and function version. -
Page 27: Appendices
Appendices Appendix 1 Outline dimension drawing Unit: mm(inch) Item A975GOT, 15.4 A970GOT (11.70) (8.20) (9.26) (9.02) (11.35) (7.84) (0.40) (1.81) (1.58) (0.24) (1.34) (1.22) (0.61) 15.4 A960GOT (10.56) (7.56) (8.04) (7.80) (10.13) (7.17) (0.40) (1.94) (1.69) (0.24) (1.38) (1.26) (0.61) -
Page 28: Appendix 2 Depth Dimension For When Mounting Each Type Of Module
Appendix 2 Depth dimension for when mounting each type of module (1) A97*GOT Installed communication module A [mm] (inch) B [mm] (inch) Communication A9GT-QBUSS, A9GT-BUSS 40 (1.57) 85 (3.35) board loading A9GT-QBUS2S, A9GT-BUS2S 62 (2.44) 85 (3.35) A9GT-BUSSU, A9GT-BUS2SU 74 (2.91) 15 (0.59) A9GT-RS2(T) 40 (1.57) - Page 29 MEMO...
- Page 30 Warranty Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
