- Page 1 Ardrich HAND DRYERS User Manual MODEL A266DD-(W or S) AUTOMATIC DUAL JET HAND DRYER...
- Page 2 Page 2 WARNING personal injury accidents will happen if use improperly Do not open the front panel otherwise...you may get an electric shock. Children should not play on the machine. Prohibited Do not use in a wet environment which is subject to sprayed water and the places where the condensation may form.
-
Page 3: Parts Names And Dimensions
Page 3 Parts names and Dimensions Heat switch Speed regulator Check light Power switch Drain line Power light Drain tank Air filter Terminal box location Mounting plate INCLUDED IN THE PACKAGE 1 x Dryer 1 x Mounting plate Power cord entry 1 x 2.5 mm Allen key 6 x Screws (12 x 30mm) -
Page 4: Precautions Before Installing
Page 4 Precautions before installing Do not install in the following types of location, otherwise this may cause malfunction: Locations where the temperature can exceed -10 C or 40 C. Locations where the dryer may come into direct contact with water. Locations where the dryer is under direct or strong sunlight Locations where there is a lot of condensation. -
Page 5: Installation
Page 5 Installation Fixed wiring installation should be carried out by a qualified person. Power requirements are - 220 -240 Volt AC 50 Hz (1.4kW). Connect fixed wiring to the terminals marked L and N and ground. This dryer is a Class I appliance and requires an electrical earth (ground). -
Page 6: Installation And Testing
Page 6 Installation and Testing Fixed wiring - Wire the terminal box Re-attach the terminal box cover. Make sure the wires are not pinched. Terminal box screw Wiring access Re -attach the front panel. Dryer Put the cover into position and fit the two screws. Attach the drain tank. -
Page 7: Using The Dryer
Page 7 Using the dryer Turn on the power switch. The power indicator lights up. The blue lamp lights up in the drying cavity. Using the Unit Stretch out both hands and move them slowly into the dryer. The dryer will start automatically. Pull them out slowly, letting the air blow the water off. -
Page 8: Routine Cleaning
Page 8 Routine Cleaning Cleaning the dryer exterior WARNING Before you clean the dryer Clean the dryer with a soft cloth.If the unit gets very dirty, clean turn off the power switch. with a soft cloth dampened with neutral agent, then clean with a Do not splash water on the dryer.
