Lenovo ThinkPad X40 2371 Install Manual

X40 series Setup Poster
P/N 39T2157
08/02/2005

Initial Setup Instructions

For more detailed information, press the Access IBM button.
Unpack:
ThinkPad(R) computer Battery pack
or
2 TrackPoint(R) caps
Modem cord
* See reverse for notes about unlisted, missing,
or damaged items and recovery CD.
Note: Please read the safety notices in the
Service and Troubleshooting Guide before you
use the computer.
Install battery pack:
Your battery is ready to use.
Note: Some models have a
battery that is shaped differently.
Connect to power:
3 2
Turn on the power:
Point and click with TrackPoint(R) Navigation System:
Press the TrackPoint cap in the direct ion you want to move the pointer. The lef
buttons below the space bar function like mouse buttons.
Configure the Operating System following on-screen instructions:
This process takes several minut es, and your computer may restart mul
For more detailed information, press the Access IBM button:
UltraConnect(TM)
Wireless Antenna
Optimal placement provides
superior range and performance
Power cord AC adapter
Books
- Setup Instructions (this sheet)
- Service and Troubleshooting Guide
- Other supplements or flyers
1
2
1
1
t and right
tiple times.
Fn Key
Use in combination with keys
with blue icons to access
special ThinkPad features
One - Handed Latch
Volume and Mute
Buttons
Powered USB Connector
Use USB optical drives
without a separate power
adapter.
Internet Navigation
Keys
Web browser back and
forward
Full Screen Magnifier
Zooms the entire screen
Manage Power Scheme
Fingerprint Reader
TrackPoint Center Button
Replace logon passwords for
Scroll documents or magnify an
simple and secure user access.
Specific models only.
ThinkLight(R)
Keyboard Light
Illuminates your
keyboard, so you can
work in the dark
Wireless Radio
Control
Presentation
Director
Easily give presentations
or use multiple monitors
EasyEject
Use to undock and
remove attachable
Brightness Control
or
P/N: 39T2157
