DUNBAR Tank Cover
Model number 742
® Registered trademark of FMI Brands Inc.
FMI BRANDS INC. 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5
USA, Canada Toll Free: 1-888-514-1663 | Tel: (+1) 778-294-0988
Email: info@outlandliving.com | Hours of Operation 8:30 AM - 4:00 PM (Pacific Time)
OWNER'S MANUAL
DUNBAR
TANK COVER
Propane cylinder,
pressure regulator &
gas hose assembly
not included.
D.742.000.V0
Advertisement
Related Manuals for Outland Living 742
Summary of Contents for Outland Living 742
- Page 1 & gas hose assembly not included. DUNBAR Tank Cover Model number 742 ® Registered trademark of FMI Brands Inc. D.742.000.V0 FMI BRANDS INC. 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5 USA, Canada Toll Free: 1-888-514-1663 | Tel: (+1) 778-294-0988...
- Page 2 Owner & Safety Manual DUNBAR Tank Cover CAUTION: Model number 742 Watch for sharp edges. Wear protective gloves if necessary. WARNING: Improper installation, adjustment, NOTE TO INSTALLER: alteration, service or maintenance can Leave this guide with the consumer. cause injury or property damage.
- Page 3 SUPPLIED PARTS & HARDWARE LIST: PART # DESCRIPTION PICTURE SIDE PANEL WITH HANDLE (X2) H-FRAME LP CLYLINDER SUPPORT (x1) LID TRAY (x1) U-CLIPS (X12) M4x10 SCREWS (x16) + 1 Extra RUBBER FEET (x8) REQUIRED TOOLS (Not Supplied): Philips (cross) screw driver (PH2) En-2 1-888-514-1663 | WWW.OUTLANDLIVING.COM...
- Page 4 Fasten firmly with the M4 screws. f) Repeat with both side panels. SLIDE U-CLIP OVER HOLES FASTEN FIRMLY Note logo position: bottom right corner En-3 OUTLAND LIVING - DUNBAR TANK COVER - OWNER & SAFETY MANUAL D.742.000.V0 ®...
- Page 5 SECTION 1: ASSEMBLY (continued) ASSEMBLY TIP STEP 3 For the best look, ensure the panel edges are Install the H-Frame Propane Cylinder Support. square and aligned on the sides and the ends. a) Slide the H-Frame ends down through the If they seem misaligned, loosen the screws a slots in the Side Panels.
- Page 6 Confirm the bottom feet holes are on the same side as the others. e) Check the panel alignment is flush on the sides and the ends. f) Fasten firmly with the M4 screws. En-5 OUTLAND LIVING - DUNBAR TANK COVER - OWNER & SAFETY MANUAL D.742.000.V0 ®...
- Page 7 SECTION 1: ASSEMBLY (continued) STEP 5 Install the Rubber Feet. a) Turn the assembly upside down. b) Push-fit the (8x) Rubber Feet into the holes. STEP 6 Turn the assembly upright, with rubber feet on the ground. En-6 1-888-514-1663 | WWW.OUTLANDLIVING.COM...
- Page 8 STEP 7 Place full propane (LP) cylinder in the base ring of the H-Frame. * * Propane cylinder, pressure regulator and gas hose assembly not included. En-7 OUTLAND LIVING - DUNBAR TANK COVER - OWNER & SAFETY MANUAL D.742.000.V0 ®...
- Page 9 SECTION 1: ASSEMBLY (continued) STEP 8 The gas hose should go through the rear hole. STEP 9 Place the Lid Tray (part 5) on the top of the assembly. Assembly complete! IMPORTANT: Ensure all screws are fastened tightly. If the screws are loose, the frame will be loose.
-
Page 10: Product Dimensions
DEPTH: 400 mm / 15.7 in The tank cover is designed to accommodate a standard size 20lb propane (LP) cylinder with dimensions approximately 12” Diameter x <=18” H SIDE FRONT En-9 OUTLAND LIVING - DUNBAR TANK COVER - OWNER & SAFETY MANUAL D.742.000.V0 ®... -
Page 11: Maintenance
SECTION 3: MAINTENANCE MOVING THE TANK COVER The tank cover has two handles, one on each side to enable transport. ACCESSING THE PROPANE CYLINDER Lift the lid to access the compartment to turn on or off the propane (LP) cylinder valve. CLEANING Should any part of this appliance become soiled or dirty, wipe down with a damp wet cloth. -
Page 12: Year Limited Warranty
Any returns sent back to FMI Brands must be sent via prepaid freight and in the original retail packaging. Please register your OUTLAND Living product for proof of purchase and warranty at https://outlandliving.com/register-products/ For more warranty information and details please contact FMI Brands Inc. at info@outlandliving.com...
