Summary of Contents for Laser SPK-BT313
- Page 1 User Manual Portable Mini Bluetooth TWS Speaker SPK-BT313...
- Page 2 Thank you for your purchase! Laser Corporation is 100% Australian owned & operated. To get the most out of your product please read the user manual carefully and keep for future use. For specific information relating to your product such as Spare Parts, FAQs, Warranty claims, and...
-
Page 3: What's In The Box
WHAT’S IN THE BOX • SPK-BT313 Speaker • USB Charging Cable • User Manual... -
Page 4: Specifications
SPECIFICATIONS Bluetooth Version: 10 meters Bluetooth Range: Bluetooth Name: SPK-BT313 Up to 32GB drives USB: in FAT32 format Up to 32GB cards Micro SD Card: in FAT32 format Radio: FM only Speaker Size: 52mm Speaker Quantity: 4 /5W Power Output: 120Hz –... - Page 5 CONTROLS Up to 32GB drives in FAT32 format. 1. USB Input Only MP3 files are supported. 2. Micro SD Up to 32GB cards in FAT32 format. Card Input Only MP3 files are supported. Use the included USB charging cable 3. DC 5V Charging Input to charge the speaker.
- Page 6 CONTROLS Continued... Press and hold to turn speaker on/off. 4. Power Button During music playback, tap to play/pause. In FM Radio mode, tap to start auto-channel search. The process will take approx. 2 minutes to complete. Tap during auto-channel search to stop.
-
Page 7: Bluetooth Pairing
Bluetooth pairing mode by default. Alternatively tap the “Mode Button” to switch to Bluetooth mode. • Search for and select “SPK-BT313” under the Bluetooth settings of device you are connecting to e.g. smartphone or tablet. • Once connected you will hear a tone from the speaker. - Page 8 • Press and hold the “Mode Button” for 2 – 3 seconds on one of the speakers. A tone will be heard when successfully paired. • Search for and select “SPK-BT313” under the Bluetooth settings of a device you are connecting to e.g. smartphone or tablet.
- Page 9 MICRO SD CARD PLAYBACK • Insert a Micro SD Card for playback of MP3 files only. • Up to 32GB cards formatted to the FAT32 file system are compatible. • The speaker will automatically switch to Micro SD Card playback when inserted. •...
-
Page 10: Usb Playback
USB PLAYBACK • Insert a USB drive for playback of MP3 files only. • Up to 32GB drives formatted to the FAT32 file system are compatible. • The speaker will automatically switch to USB playback when inserted. • Remove the USB drive to exit this mode. TIP: If USB drive is not recognized, check you are only using MP3 files for playback, or if the... -
Page 11: Hands-Free Calls
HANDS-FREE CALLS • When connected to a smartphone this speaker can support hands-free calls. • Tap the “Power button” to accept an incoming call. • Tap the “Power button” during a call to hang up. • Press and hold the play/pause button during a call to switch call from the speaker to the connected smartphone. - Page 12 CHARGING • Connect the included USB cable to charge the speaker. • A USB wall adapter up to 5V/0.5A is recommended however charging via a Computer/Laptop USB port is also possible. • Once charging has finished the 4 LED lights will be solid. •...
-
Page 13: Troubleshooting
TROUBLESHOOTING No Power: • Check battery level and charge if required. • Try charging the speaker with a USB wall adapter (like a smart phone charger) instead of a laptop or computer. • A USB wall adapter up to 5V/0.5A is recommended for charging. - Page 14 Bluetooth: • Place the speaker next to the smart device you are pairing to e.g.,Smartphone. • If the Bluetooth name “SPK-BT313” does not appear on the list of available devices, then try refreshing the list or searching again. • Allow up to 1 minute for the device to appear on the Bluetooth list.
- Page 15 TROUBLESHOOTING Continued... Micro SD Card or USB not recognised or files not playing: • Make sure the storage device is 32GB or less. • If the storage device is brand new out of the packaging, you may need to format it on a Windows based computer to the FAT32 files system first.
- Page 16 Visit our website www.laserco.com.au Check us out at www.youtube.com/lasercoau...
