Laser SPK-BT530WP Quick Operation Manual

PAIRING MODE
When your speaker is first turned on you will enter pairing mode. The BLUE Led light will be flashing.
Turn the BLUETOOTH on, on your smart phone (for example), scan for new Bluetooth devices and
then connect to your Bluetooth speaker. A short melody will sound when connected successfully.
BUTTONS
ON / OFF
Adjust volume down
Previous song
Make a call
Answer a call
End or refuse a call
Play/Pause
Adjust volume up
Next/Previous
Disconnect the
LED INDICATOR
Blue light flashes rapidly
Blue light flashes slowly
(every 3 seconds)
Green light on
Red light on
Red light off
QUICK OPERATION GUIDE
Power
Long press to power ON / OFF.
Short press to turn volume down.
Long press to go to the previous song.
Long press to call the last dialled number.
During an incoming call, short press key to answer the
phone, short press again to hang up the phone (and return
back to music playback)
Short press to end a call or long press to refuse the call.
Short press to start or stop music playback.
Short press to turn volume up.
Long press to go to the next song.
Long press both "+" and "-" buttons to disconnect the
current current Bluetooth connection. (You can then search and
Bluetooth connect to another new Bluetooth device.)
SPK-BT530WP / 560WP
Pairing mode
Bluetooth connected
Line in mode
Charging status
Charging completed
