- Page 1 Operating instructions GN container food serving trolleys SPA/K Read the instructions prior to performing any task!
- Page 2 Internet: www.hupfer.com Document information Last update: 19.09.2022 Index: 1, en_GB All texts, illustrations and graphic designs are protected by copyright. Reproduction, distribution and issuing are permitted for internal company purposes only. © Hupfer Metallwerke GmbH & Co. KG, Coesfeld 2022...
-
Page 3: Table Of Contents
Operating instructions GN container food serving trolleys Table of contents General information............... Product information............Target group..............Symbols................Signs................Product description............... Function................Overview................. Equipment features............Variants................Technical data..............Rating plate..............Safety information..............Intended use..............Improper use..............10 Safety instructions............10 3.3.1 General information..........10 3.3.2 Transport.............. - Page 4 Operating instructions GN container food serving trolleys Keeping food cold............18 Removing the goods............20 Finishing operation............20 Care and cleaning..............20 Cleaning intervals............21 Permissible cleaning types..........21 Permissible cleaning agents........... 23 Material compatibility............24 Manual cleaning.............. 25 Disinfecting..............25 Maintenance and repair............
-
Page 5: General Information
Product information Product name GN container food serving trolleys Product type SPA/K – with active cooling Target group These operating instructions are intended for the following groups of people who perform the listed activities with or on the product: Electrician ■... -
Page 6: Signs
Operating instructions GN container food serving trolleys WARNING “Warning” indicates a hazardous situation that may result in serious injury. CAUTION “Caution” indicates a potentially hazardous situation that may result in minor to moderate injury. NOTICE “Notice” indicates a situation that may result in damage to property. “Notes”... -
Page 7: Overview
Operating instructions GN container food serving trolleys Overview Fig. 1: Overview of SPA/K Handle Swivel castor Rating plate Disk bumper Control Plug Housing with ventilation grilles Drain valve Swivel castor with locks 10 Cold well Equipment features Housing Sturdy, self-supporting design in stainless steel. -
Page 8: Technical Data
Operating instructions GN container food serving trolleys ■ Size of the cold well Technical data Model SPA/K 2 GN DW SPA/K 3GN DW Dimensions, total weight Width 1317 Depth Height Total weight Payload, total Well Effective dimensions Gastronorm (GN) 530 × 325 mm Gastronorm (GN) 530 ×... -
Page 9: Rating Plate
Operating instructions GN container food serving trolleys Rating plate Fig. 2: Rating plate Manufacturer and address Electrical serial number Type designation and product code 10 Induction frequency Order number 11 Refrigerant Total weight 12 Refrigeration capacity Payload, total 13 Protection code Electrical connection 14 Certification mark/CE label if available Model year... -
Page 10: Improper Use
Operating instructions GN container food serving trolleys Improper use The GN container food serving trolley is not to be used as a self- service trolley. The GN container food serving trolley is not suitable for machine cleaning. It may not be used for transporting living creatures. Persons must not sit or stand on or in the transport trolley. -
Page 11: Operation And Use
Operating instructions GN container food serving trolleys 3.3.3 Operation and use Transport trolleys can move off independently and in an uncontrolled manner if the castors are not locked. Secure the stationary transport trolley against rolling away. Do not park on sloping ground. Only move transport trolleys with the locks released. -
Page 12: Transport
Operating instructions GN container food serving trolleys Transport WARNING Risk of crushing Improper use or incorrect means of transport may cause the transport trolley to tip over, slip or fall. If not adequately secured, there is a danger of serious crushing injury and damage to the transport trolley. −... -
Page 13: Operating Conditions
Operating instructions GN container food serving trolleys Operating conditions For installation and operation, the BG rule “Arbeiten in Küchenbetrieben” (Working in kitchens) of the BGZ technical committee “Nahrungs- und Genussmittel” (BGR 111) BGR 500:2008-04 Chapter 2-35 must be observed, among others. Observe clearances The transport trolley requires unobstructed air exchange for cooling and for electronics to function... -
Page 14: Operation
Operating instructions GN container food serving trolleys NOTICE Instructing operating staff Before commissioning, operating staff must be instructed how to operate the transport cart correctly. NOTICE Compressor damage After delivery, the compressor oil must be allowed to settle or com- pressor damage will occur. -
Page 15: Supply The Transport Trolley With Power
Operating instructions GN container food serving trolleys CAUTION Injuries caused by rolling away The transport trolley is heavy, and if it rolls away out of control, there is a risk that people may be injured by being hit or crushed. −... -
Page 16: Moving The Cart
Operating instructions GN container food serving trolleys Switching cooling on/off Press the on/off button for at least 3 seconds. �� The display shows [OFF] when the cooling is switched off. The ventilation switches off. �� The display shows the [current temperature] when the cooling is switched on. - Page 17 Operating instructions GN container food serving trolleys Engaging the locks Swivel castors with locks can block the wheel from turning and swivel- ling. When the locks on both swivel castors are engaged, the transport cart is secured against rolling away. Engage the lock as shown on the left.
-
Page 18: Loading Goods
Operating instructions GN container food serving trolleys Disconnect the connection to the power supply. Hang the plug in the holder provided. Release the locks. Move the transport trolley using the push handle. Make sure that path ahead is clear. Only move the transport trolley over flat, dry and stable surfaces. Have someone help you if the transport trolley needs to be moved on a slope. - Page 19 Operating instructions GN container food serving trolleys The GN container food serving trolley can only effectively keep food cold if it is precooled for 0.5 hours. The GN container food serving trolley can be switched on manually for pre-cooling. Close the drain valve. Cover the well with a suitable lid.
-
Page 20: Removing The Goods
Operating instructions GN container food serving trolleys Removing the goods Cold well Remove the lids from the GN containers. �� You can remove food or the entire GN containers. Practical tip It is easier to carry cold GN containers on drop handles. -
Page 21: Cleaning Intervals
Operating instructions GN container food serving trolleys WARNING Flammable refrigerant A flammable gas is used as a refrigerant. Closed vents will result in a flammable air-gas mixture in the event of leakage. − Do not close the vents in the floor of the cart. −... - Page 22 − Use a flat stream nozzle. Cleaning type Definition of the cleaning operation Approval for SPA/K Manual cleaning Cleaning with dry cleaning agents Damp Cleaning with a damp cloth and degreasing liquid cleaner Cleaning with a wet sponge and...
-
Page 23: Permissible Cleaning Agents
Operating instructions GN container food serving trolleys Cleaning type Definition of the cleaning operation Approval for SPA/K Wet steam ≤135°C Cleaning the surfaces: ■ max. 30-90 seconds ■ Short exposure time for individual sec- tions ■ Do not spray into the bearings... -
Page 24: Material Compatibility
Operating instructions GN container food serving trolleys Cleaning agent Approval Degreasing agent ■ Neutral liquid cleaner Salty cleaning agents ■ Table salt ■ Hydrochloric acid Sulphuric cleaning agents ■ Sulphur dioxide ■ Sulphuric acid Chlorinated cleaning agents ■ Chlorine cleaner ■... -
Page 25: Manual Cleaning
Operating instructions GN container food serving trolleys Manual cleaning Clean the well of the transport trolley after each use and according to the operator’s instructions. Clean the outer surfaces of the transport trolley after use or as required. For wet cleaning, use a soft cloth or an uncoated sponge. Use degreasing liquid cleaners. -
Page 26: Maintenance And Repair
Operating instructions GN container food serving trolleys Maintenance and repair DANGER Electrical hazard Electricity is a serious hazard and can cause injury or even death. − Before starting any cleaning and maintenance work, disconnect the transport cart from the mains. −... -
Page 27: Maintenance Intervals
Operating instructions GN container food serving trolleys Maintenance intervals Regularly check that the following components are functioning prop- erly: Interval Maintenance work Personnel before each use Check connecting cable and mains plug for mechan- Operator ical damage and ageing. daily Carry out a visual inspection of the entire unit. -
Page 28: Error Messages
Operating instructions GN container food serving trolleys Remove the housing. Clean the heat exchanger with a vacuum cleaner. Be careful with the plates of the heat exchanger. Bent plates make the heat exchanger ineffective. The metal plates present a cutting hazard. Close the housing. -
Page 29: Repairs And Spare Parts
Operating instructions GN container food serving trolleys Fault description Cause Remedy Personnel Insufficient cooling Incorrect required tem- Set the required temperature cor- Operating staff power perature rectly Well iced up De-ice the well Operating staff Compressor defective Service or replace the com- Refrigeration spe- pressor cialist... -
Page 30: Disposal
Operating instructions GN container food serving trolleys 10 Disposal Help protect our environment. Make sure that the materials are recycled. − Have the transport trolley disassembled and dis- posed of by recycling companies. All the mate- rials are recyclable. − Electrical components may only be removed by qualified electricians.
