- Page 1 2K@60Hz 8 DVI-U inputs and 12 HDMI outputs Video Wall Processor with Preview function VWP-812 User Manual VER 1.0 Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 2: Table Of Contents
Thank you for purchasing RGBLE product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
Video Wall Processor with Preview function 1. Introduction The RGBLE VWP -812 video wall processor is a high-end video processing equipment developed and manufactured by our company for LCD large screen display and so on. It has adopted the CrossInt smart splicing technology specially designed for splicing display and all display modules are locked by FST technology before synchronous output, eliminating the asynchronous display between contents of multiple modules. -
Page 4: Specifications
4. Specification Brand Name RGBLE Model Number VWP-812 Video Inputs Type Description Support up to 1920×1200@60Hz, downward compatibility. 8 DVI-U Support DVI/HDMI/VGA/CVBS with different connectors Compatible with HDMI1.3 and lower version, EDID version 1.3 Video Outputs Type Description Resolutions: 1024×768@60Hz till 1920×1080@60Hz... -
Page 5: Operation Controls And Functions
(e.g.: computer) →Mosaic Processor →LCD. Control connection: connect control computer with device control port and debug device connection method. There are three connection methods (1) Connect 100MB network control port with splicer LAN (100M) port, which can set device Stock Code 873117 en.rgble.com 400-1661-021... -
Page 6: Debugging Steps
COM port, and plug DB9 into computer serial port. Any kind of method among the three can realize device software control. Connection diagram: 6.2 Debugging Steps Step 1: Press “MENU” to enter into main menu interface and click “Splicing Mode” to select splicing mode: 2×2、2×3、2×4、2×5、2×6、3×2、3×3、3×4、4×2、4×3、5×2、M×N. Stock Code 873117 en.rgble.com 400-1661-021... - Page 7 Window 1 H POS：0 V POS：0 H SIZE：1920 V SIZE：1080 ×1 ×10 ×100 Select window Click OK to next Press FiNGER select Note: there are two ways for number input: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 8 Then select needed mode and click “OK”. Mode 1 MODE 1 Mode 2 SPLICE 2×3 LAYOUT ¼ Mode 3 Mode 4 WIN 1 Mode 5 Mode 6 Mode 7 Mode 8 Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 9: Case Study
Num in box is PORT OK 2 map INFO view Step 2: Press “OK” to return to main menu interface; The large screen splicing is finished, select signal source needed to display on screen and click corresponding key(s1-s8). Stock Code 873117 en.rgble.com 400-1661-021... -
Page 10: Function Key
Its interface is shown as below. Red light means signal is lost while green one shows signal is normal. WIN: Image key. Click this key to enter into its interface and signal source selection can be made in following interface. Stock Code 873117 en.rgble.com 400-1661-021... - Page 11 5). VGA adjustment Since VGA signal belongs to analogue one, it tends to causes deviations among common functions. The product has two kinds of VGA corrections which are automatic correction and manual correction. 6). IP setting Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 12: Advanced Menu
All data are cleared and the device returns to default state. Common functions Click “FUNC” to get quick access to common setting function. Keyboard lock Lock front panel key to avoid misoperation of irrelevant personnel. Technical Support Inquire device version number and its IP address. Stock Code 873117 en.rgble.com 400-1661-021... -
Page 13: Software Control
7. Software Control Step 1: Please obtain the control software provided by RGBLE Step 2: Extract the rar. File and install the control software on the control PC Step 3: After install, double click to run the software. The default User name is: administrator, no password, click “ok” to login and it will show below... - Page 14 3 steps to get connected: Click “Connect”, Type the IP address 192.168.0.100, then click “OK” After well connected, it will pop-up a window for synchronization with the control software, click to “OK” to sync. After click “OK” to sync, it will jump to “Switching” interface: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 15 7: For the local sources preview (only with 1000M LAN port can support) “Device” Interface: After click “Device”, it will be showing as below: For this model, we only use the “Connect/ disconnect” and “Exit” two buttons, the rest are for other equipment. Stock Code 873117 en.rgble.com 400-1661-021...
- Page 16 Users can set the video wall configuration accordingly. Open new window, save or recall user’s mode, and default back to factory mode and so on function here. Screen config and Output Map: Screen config (for the Video wall number and resolution settings): Stock Code 873117 en.rgble.com 400-1661-021...
- Page 17 Output Map (for adjusting the output ports to match with the displays): Drag the OUT1...OUT12 up to the Port1...Port12 to replace and adjust Stock Code 873117 en.rgble.com 400-1661-021...
- Page 18 For open a window, it also can be done by pressing and holding left click of the mouse to drag and release on the video wall operation area, and users can adjust the window size by moving to the edge of the window: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 19 User-Mode: For recalling the saved user mode(presets), total can save 32 presets Save-Mode: For save the current settings as a user-mode/preset Factory default: Click this one will reset all the parameters as factory default mode Stock Code 873117 en.rgble.com 400-1661-021...
- Page 20 Echo On: Turn on the local preview function on the control PC (only support with 1000M Port) Echo Off: Turn off the local preview function on the control PC (only support with 1000M Port) Screen Control: those functions are not available for this mode Stock Code 873117 en.rgble.com 400-1661-021...
- Page 21 “Tools” interface With interface, users can add more operation users here with different rights, language setting and also change to baud rate and IP address: Users management: add new users or delete the users: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 22 Mode switching effects setting: users can set up the switching effects(CUT or Fade) and time while recall the save user-mode The Auto, Schedule and Shortcut are not functional on this mode: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 23 Bright: Users can adjust the brightness and Contrast of the output Black: Users can set up the output video as Black/Blue screen if the video not correct: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 24 Config file: for users to import or export the configurations Language selection: At present, there are 3 languages for selections: COM Config: Users can change the baud rate here accordingly Stock Code 873117 en.rgble.com 400-1661-021...
- Page 25 Users can set and select the UI style from here. Other functions/Interfaces: On the left side, users can find the Signal source, Monitor Setting and User Mode icons here. With different icons, it will show different contents: Stock Code 873117 en.rgble.com 400-1661-021...
- Page 26 For closing the window, users either can click the red “X” to close one by one or right click the mouse to find the “close all” function Stock Code 873117 en.rgble.com 400-1661-021...
- Page 27 Recall mode 5：e9_01_11_05_00_00_0d_0a Recall mode 6：e9_01_11_06_00_01_0d_0a Recall mode 7：e9_01_11_07_00_02_0d_0a Recall mode 8：e9_01_11_08_00_03_0d_0a Recall mode 9：e9_01_11_09_00_04_0d_0a Recall mode 10：e9_01_11_0a_00_05_0d_0a Recall mode 11：e9_01_11_0b_00_06_0d_0a Recall mode 12：e9_01_11_0c_00_07_0d_0a Recall mode 13：e9_01_11_0d_00_08_0d_0a Recall mode 14：e9_01_11_0e_00_09_0d_0a Recall mode 15：e9_01_11_0f_00_0a_0d_0a Recall mode 16：e9_01_11_10_00_0b_0d_0a Stock Code 873117 en.rgble.com 400-1661-021...
- Page 28 Recall mode 21：e9_01_11_1e_00_10_0d_0a Recall mode 22：e9_01_11_1f_00_11_0d_0a Recall mode 23：e9_01_11_20_00_12_0d_0a Recall mode 24：e9_01_11_21_00_13_0d_0a Recall mode 25：e9_01_11_22_00_14_0d_0a Recall mode 26：e9_01_11_23_00_15_0d_0a Recall mode 27：e9_01_11_24_00_16_0d_0a Recall mode 28：e9_01_11_25_00_17_0d_0a Recall mode 29：e9_01_11_26_00_18_0d_0a Recall mode 30：e9_01_11_27_00_19_0d_0a Recall mode 31：e9_01_11_28_00_1a_0d_0a Recall mode 32：e9_01_11_29_00_1b_0d_0a Stock Code 873117 en.rgble.com 400-1661-021...
