- Page 1 P/N: D00204 18Gbps 4K@60Hz HDMI 1X4 HDBT Splitter DH-4HT-U User Manual VER 1.0 Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 2: Table Of Contents
P/N: D00204 Thank you for purchasing RGBLE product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. -
Page 3: Introduction
P/N: D00204 1. Introduction The RGBLE 18Gbps HDMI 1x4 HDBT Splitter can distribute 1 source signal to any 4 display devices. The HDMI signal transmission distance can be extended up to 120 meters at the resolution of 4K2K@60Hz, 150 meters at... -
Page 4: Specifications
(US/EU standards, CE/FCC/UL certified) Power Consumption 35W Operation 0° C ~ 40° C / 32° F ~ 104° F Temperature Storage Temperature -20° C ~ 60° C / -4° F ~ 140° F Relative Humidity 20~90% RH (non-condensing) Stock Code 873117 en.rgble.com 400-1661-021... -
Page 5: Operation Controls And Functions
When the HDMI LOOP OUT port connects an active display device, the green LED will be on. OUT (1~4) LED When the HDBT OUTPUT port connects an HDBT Receiver, the corresponding green OUT LED will be Rear Panel Stock Code 873117 en.rgble.com 400-1661-021... - Page 6 Dark: No signal transmission. Plug the DC 24V power supply into the unit and connect the adaptor to an AC outlet. (Note: The ⓫ DC 24V transmitter can power the receiver via a CAT cable.) Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 7: Hdbt Receiver
Connect to the IR Receiver cable. The IR signal will send to IR IN the IR OUT port of the transmitter. Connect to the IR blaster cable, the IR signal is from IR ➑ IR OUT IN port of the transmitter. Stock Code 873117 en.rgble.com 400-1661-021... -
Page 8: Ir Pin Definition
P/N: D00204 5.3 IR Pin Definition Stock Code 873117 en.rgble.com 400-1661-021... -
Page 9: Edid Mode
00111 COPY_FROM_HDBT OUT3 00110 COPY_FROM_HDBT OUT4 00101 1080P, Stereo Audio 2.0 00100 1080P, Stereo Audio 2.0 00011 1080P, Stereo Audio 2.0 00010 1080P, Stereo Audio 2.0 00001 1080P, Stereo Audio 2.0 00000 PC control mode Stock Code 873117 en.rgble.com 400-1661-021... -
Page 10: Ascii Commands
1! output hdbt output 1: connect port, y=0~5(0=all, 1~4=HDBT 1~4, 5 = loop out) Reset to factory defaults System Initializing... Initialization Finished! FW s reset! Reset to factory s reset! version x.xx.xx defaults Stock Code 873117 en.rgble.com 400-1661-021... - Page 11 Enable hdbt output 1 hdcp r hdbt y hdcp! r hdbt 1 hdcp status, hdcp! y=0~4(0=all) Enable hdbt output 1 Get hdbt output r hdbt stream! r hdbt 1 stream y stream status, stream! y=0~4(0=all) Stock Code 873117 en.rgble.com 400-1661-021...
- Page 12 Get EDID status of the input r edid in! 444, Stereo Audio 2.0 r edid in data! EDID data: 00 FF FF Get the EDID data of the hdmi input r edid in data! FF FF FF 00 …… Stock Code 873117 en.rgble.com 400-1661-021...
- Page 13 1 57600 parity none! data size :8, stop:1 parity: none set send RS232 command wait time s rs232 send RS-232 time 200! command wait s rs232 time 200ms x=200~5000ms time 200ms Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 14: Application Example
P/N: D00204 8. Application Example Stock Code 873117 en.rgble.com 400-1661-021...
