MVPS1000
1000 Watts
•
5 x 9.51" Footprint, 1.61" for 1U installation
•
Medical approvals; IEC60601-1 3.1, BF rated, IE60601-1-2 4th ed
•
Up to 3 units load share for higher powers
•
+/-3% Output voltage adjust
•
EN55011 Level B conducted & radiated
•
3 Year warranty
The MVPS1000 series of low profile, medical grade AC-DC power modules offer 500-1000W in a 5" x
9.51" package conforming to the latest IEC60601-1 (3.1), IEC60601-1-2 4th ed standards. The units
are fully featured including 5V 1.5A auxiliary output, low standby power of 3W and are suitable for
body floating applications. They have a wide operating temperature of –40 to 70°C, in a range of
voltages from 12V to 58V. All units come with a FiDUS 3 year warranty.
Models & Ratings
Model Number
MVPS1000-1012
MVPS1000-1015
MVPS1000-1024
MVPS1000-1030
MVPS1000-1048
MVPS1000-1058
Notes
1. Combined output power is main DC output + fan output 12V / 500mA max
Key specifications
Parameter
AC Input range
Operating temperature
Efficiency
Dimensions
EMC
Safety
1
Series
(1)
Output Power
500W
625W
1000W
1000W
1000W
1000W
Minimum
Typical
85
-40
120VAC 88% and 240VAC 93% typical
5 x 9.51 x 1.61" (127 x 241.6 x 40.9mm)
EN55011 Level B conducted and radiated with king core K5B RC 25x12x15-M on input. EN61000-3 and EN61000-4, harmonics,
flicker, Surge, EFT, ESD, conducted and radiated, IEC60601-1-2 4th ed
EN60601-1, IEC60601-1 (ed3), ANSI/AMMI ES 60601-1, CSA C22.2 No 60601-1
www.fiduspower.com
Output Voltage
12V
15V
24V
30V
48V
58V
Maximum
Units
264
VAC
70
°C
Dimensions:
5 x 9.51 x 1.61" (127 x 241.6 x 40.9mm)
INSTALLATION ADVICE PG6
Output Current
41.67A
41.67A
41.67A
33.33A
20.83A
17.24A
Notes & Conditions
Derate from 100% at 120VAC to 70% at 85VAC
See derating curve p3.
Advertisement
Table of Contents
Related Manuals for FiDUS MVPS1000 Series
Summary of Contents for FiDUS MVPS1000 Series
- Page 1 • 3 Year warranty The MVPS1000 series of low profile, medical grade AC-DC power modules offer 500-1000W in a 5” x 9.51” package conforming to the latest IEC60601-1 (3.1), IEC60601-1-2 4th ed standards. The units are fully featured including 5V 1.5A auxiliary output, low standby power of 3W and are suitable for Dimensions: body floating applications.
- Page 2 ULP275 WLP350 VPS1000 MVPS1000 Series Series Series Series Input Parameter Minimum Typical Maximum Units Notes & Conditions Input voltage Derate from 100% at 120VAC to 70% at 85VAC Input frequency EN61000-3-2 class D compliant, at full load. 0.98 at Power factor 0.95 0.98 120VAC and 0.95 at 240VAC...
-
Page 3: Emc: Emissions
ULP275 WLP350 MVPS1000 Series Series Series Power Derating Curve 12V Power Derating Curve 15V Power Derating Curve Others 1000 20 40 60 -40 -20 20 40 60 -40 -20 20 40 60 -40 -20 Temperature (ᵒC) Temperature (ᵒC) Temperature (ᵒC) EMC: Emissions Standard Test level... -
Page 4: Application Notes
ULP275 ULP275 WLP350 MVPS1000 Series Series Series Series AC Power Derating Curve Application notes Signals Power Good: TTL output activated at 90% of Vout. Delay between 100 and 500mS At least 1mS before Vout falls below 90% TTL signal switches low Remote Sense: Compensation for 200mV voltage drop on cable runs Remote on/off: Unit comes pre-configured with pin 6 &... -
Page 5: Mechanical Details
ULP275 ULP275 WLP350 MVPS1000 Series Series Series Series Mechanical Details J1: Input Connector Pin Connections Function Line Neutral Earth J2: Output Connector Pin Connections Function +Vout -Vout J3: I/O Connector Pin Connections Function +5V 1.5A PGPF Remote on/off Current limit p2 Current limit p1 Load share Notes... -
Page 6: Installation Advice
Then consider the impact of operational time, load and temperature profile to estimate a more realistic lifetime for your PSU. Also, many FiDUS power supplies offer a Peak Power rating to provide for customers with pulsing loads. When using a peak power capability customers must consider: 1) Peak duration rating: the maximum length of time the peak can be drawn for 2) Duty cycle: the frequency with which the peak can be drawn.
