- Page 1 OPERATING INSTRUCTIONS AirSafe PM CONTINUOUS, INDOOR MONITOR FOR DUST EXPOSURE ENVEA Process GmbH - Gutedelstraße 31 – 79418 Schliengen - GERMANY Tel.: +49 (0) 7635 827248-0 / info.process@envea.global / www.envea.global...
-
Page 2: Table Of Contents
CONTENTS Page System overview ......... . 3 2. -
Page 3: System Overview
System overview A complete system consist of a AirSafe PM with its optional wall mounting bracket. 290,1 mm Fig. 1: Drawing of AirSafe PM... -
Page 4: Function
2. Function The AirSafe PM uses a high end optical measurement system that is embedded in the sensor. The air flows through the measuring device which counts the particles and defines their size. The raw measurement is processed by a unique algorithm which enables continuous and accurate measurement for the different sizes of particles as well as classification of A or E dust fractions (also known as inhalable and respirable fractions). Particles size / glossary PM describe all dust particles smaller than the mentioned size. PM1 include all dust particles smaller than 1 µm Example: PM2.5 include all dust particles smaller than 2.5 µm PM4.5 include all dust particles smaller than 4.25 µm... -
Page 5: Safety
Normal use • The measuring system may only be installed indoor, in workplace, production area, storage areas, rest areas, rooms, open spaces and in industrial work areas. • Only original spare parts and accessories from ENVEA must be used. 3.2 Identification of hazards Possible hazards, when using the measuring system, are marked by the following symbols: Warning! • This symbolises a situation where personal safety is at risk if used in an improper manner. Attention! • This symbolises the possible damage to the system, if used in an improper manner. -
Page 6: Maintenance
3.5 Technical statement The manufacturer reserves the right to change any technical data concerning technical developments, without prior notice. If any queries arise, ENVEA will be happy to inform customers of any possible changes made. 3.6 Reliability For any additional information concerning product reliability, please contact ENVEA. -
Page 7: Mounting And Installation
Mounting and installation The AirSafe PM can be mounted on any flat surface or on a wall using mounting brackets (ENVEA recommend to install the sensor in a flat position if possible). The sensor is designed for monitoring ambient air in workplaces in industries such as cement plants, foundries, wood workshops, incineration plants or logistic warehouses. The AirSafe PM can be easily mounted to most surfaces and areas: • In or around process areas • Storage rooms • Laboratories • Breakrooms • Changing rooms • In or around office areas • Other footfall areas of health and safety exposure concern •... -
Page 8: Electrical Connection
Electrical connection Fig. 2: Electrical connections +24 V DC Input power supply 24 V DC Input power supply 0 V DC RS485 A RS 485 interface data A RS485 B RS 485 interface data B OC 2 - Non attributed OC 2+ Non attributed OC 1 -... -
Page 9: Setup
6. Setup To setup AirSafe PM, it is necessary to use a USB connection via the supply cable between the sensor and a PC software running on Windows operating system (WinXP or more recent). USB connection For connection via USB, it is necessary to open the sensor. -
Page 10: Service Software
6.2 Service software 6.2.1 List Fig. 3: List Panel Attention! To start the communication between the PC and the sensor, the “ON” button (beside cyclic querry) must be checked. This panel provide you the different dust value in mg/m as well as ambient temperature and air moisture. Firmwire version is also displayed. -
Page 11: Dust
6.2.2 Dust Fig. 4: Dust panel Values You can see the values of the different size of dust. By selecting channel 1/2/3 on the left, you can change the value from instant/15 minutes average / 8 h average. It can also display the temperature and moisture values. Current Output You can set the different parameters of the currents outputs. - Page 12 E-Dust Long limit: Limit exposure value to E-Dust for 15 mins Status This code can help for trouble shooting. In case of sensor malfunction and if any of the boxes are checked, please contact ENVEA or and official repre- sentative for help. Sensor Usage T min/max: Minimum and maximum temperature in °C that the sensor has been exposed to.
-
Page 13: Trend Pm
6.2.3 Trend PM Fig. 5: Trend PM panel This panel allows you to display as a graph the trend of any selected dust (also temperature and moisture) with 1 times average. Instant average 15 minutes average Shift (8 hours) average Save to File: It will generate a .csv file containing the data of the graph display. -
Page 14: Trend Avg
6.2.4 Trend Avg Fig. 6: Trend Avg panel This panel allows you to display as a graph the trend of 1 type of dust (also temperature and moisture) with up to 3 times average. Instant average 15 minutes average Shift (8 hours) average Zoom: You can zoom on in/out time frame. -
Page 15: System
6.2.5 System Fig. 7: System panel The system panel will allow you to change some system parameters: Datalogger: You can here set the parameters of the datalogger. Frequency and .csv file parameters. PC Modbus parameters: You can change the baud rate and the com port. Write sensor parameters in file: This will generate a file with all parameters of the sensor. -
Page 16: Esam Interface
ESAM Interface How to connect to ESAM Go to you network / wifi menu and select AirSafe PM AirSafe PM Secure Connect automatically Log in Default Password is “123456789” Use a web browser and input “192.168.43.1/esam”, press ENTER 192.168.43.1/esam/ 7.2 How to connect as ADMIN / profile / languages 7.2.1 ADMIN Select “Change Profile” Guest Default login is “admin/admin” 7.2.2 Languages... -
Page 17: Admin Menu
7.2.3 Admin menu Change profile My account Logout Help About Reboot Change profile: You can log with a different admin profile. My account: See below Logout: To logout and go back to guest mode. Help/About: Not in use yet. Reboot: You can reboot eSAM interface. My account Preferences: You can select the default page that will be displayed at each connection to eSAM. Units: When ticked, the units displayed will be mg/m as standard. -
Page 18: Equipment Status
Equipment Status Equipment status menu allows you to see the different available PM size measurement. You can display them in a graph by selecting desired value (a left click) in the left menu (another click will remove them from chart). You can select the time period: You can adjust the scale: for Minimum for Maximum You can quickly export the values seen on the screen by choosing “export”, export is available as .PDF or .PNG files: Download as PNG Download as PDF... -
Page 19: Historical And Datas
Historical and datas This panel allows you to download data stored in the sensor datalogger. You can select the dust type, the time from and the sampling rate. You can export them as a graph or as a chart and a tool can calculate the min/max/average values. On the left panel you can choose the dust type. -
Page 20: Settings
Settings Site Equipment Channels Analog outputs Modbus outputs Logic states Pages Process Initialization Site name: You can rename the sensor. Languages: You can switch sensor language. - Page 21 In the panel, you can select each type of dust separetaly and rename them if necessary. Name: Name of the dust, you can rename it if necessary. Unit: You can change the unit. Attention: It only change the unit name and not the value. You need to use „Coef A“...
-
Page 22: Maintenance
ENVEA free of charge at the discretion of ENVEA. Replaced parts will become the property of ENVEA. If the customer requests that parts be repaired or replaced at its plant, the customer must pay the travel expenses for ENVEA service personnel. -
Page 23: Technical Data
290,1 x 259 x 107 mm (L x W x H) Weight Approx. 2.5 kg ENVEA Process GmbH Gutedelstraße 31 · 79418 Schliengen (Germany) Fon +49 7635 827248-0 · Fax +49 7635 827248-48 · www.envea.global PART OF THE ENVEA GROUP EN 19/09/2022...
