- Page 1 USER’S MANUAL...
-
Page 3: Table Of Contents
English CONTENTS 1. GUIDE ......................1 IMPORTANT SAFETY INSTRUCTIONS ........... 1 1.2 GENERAL DESCRIPTION ................1 1.3 PRODUCT OVERVIEW & ILLUSTRATION ..........2 3. QUICK MENU GUIDE................4 4. TECHNICAL SPECIFICATION ..............6... -
Page 5: Guide
English 1. GUIDE 1.1 IMPORTANT SAFETY INSTRUCTIONS Thank you for choosing our product. Before installation, we would like to remind you some notes, which is very important for operating safely and properly, as follows: • Be sure to read this user manual before starting your op- eration. -
Page 6: Product Overview & Illustration
LCD TV or set-top-box. It can be used in series with other modulator so the number of channels in the coaxial cable no the SMATV system can be increased as desired. 1.3 PRODUCT OVERVIEW & ILLUSTRATION Description Function Switch options Switch options Switch to Country option Switch to Channel option... - Page 7 English 2. FEATURES • High level of integration, high-performance, Full-featured, integrated design • Single input modulator that converts HD source to a DVB-T channel • Standard COFDM modulation and H.264 encoding • Multiple video format compatibility including 720p / 1080p •...
-
Page 8: Quick Menu Guide
3. QUICK MENU GUIDE • Country Setting Step 1: Press the CNT key to enter the country selection status; Step 2: Press YZ key to switch countries. Country Display Europe Italy Russia Australia New Zealand • Channel Setting Step 1: Press the CH key to enter the channel selection status; Step 2: Press YZ key to switch channels. - Page 9 English Step 1: Press the ATT key to enter the attenuation edition status; Step 2: Press YZ key to change attenuation value in 0 ~ 30dB range.
-
Page 10: Technical Specification
4. TECHNICAL SPECIFICATION Modulator DVB-T Standard 64QAM Constellation 7 / 8 MHz Bandwidth Carriers Guard Interval 1/32 Code Rate >28 dB Frequency Range 174 - 230 MHz, 470-862 MHz RF Level 70 ~ 100 dBuV Output Impedance 75Ω Compression H.264 - bitrate 5-15 Mb/s 1920*1080_60P, 1920*1080_50P;... - Page 11 English Note: 1.Since the modulator uses H.264 encoding, users need using DVB-T service which supports standard H.264 encoding for normal display. 2.If the image and sound are not synchronous, please insert HD port again, it will return to normal.
- Page 12 USER’S MANUAL...
