- Page 1 USER’S MANUAL...
-
Page 3: Table Of Contents
English CONTENTS 1. GUIDE ......................2 1.1 IMPORTANT SAFETY INSTRUCTIONS ..................2 1.2 GENERAL DESCRIPTION ......................2 1.3 PRODUCT OVERVIEW & ILLUSTRATION ................3 2. FEATURES .......................4 THE MENU OSD INSTRUCTION ..............5 3.1 RF1 SYSTEM SET .........................5 3.2 CHANNEL 1/2/3/4 SETUP ......................6 4. TECHNICAL SPECIFICATION ................7... -
Page 4: Guide
1. GUIDE 1.1 IMPORTANT SAFETY INSTRUCTIONS Thank you for choosing our product. Before installation, we would like to remind you some notes, which is very important for operating safely and properly, as follows: • Be sure to read this user manual before starting your operation. • When the unit is suddenly moved to a hot area from a cold area, it may cause some problems. -
Page 5: Product Overview & Illustration
English 1.3 PRODUCT OVERVIEW & ILLUSTRATION Description FUNCTION Power indicator light Channel HD channel indicator light RETURN Return to superior menu and save settings Switch settings in menu or cursor left Switch settings in menu or cursor right Change the frequency point or cursor down Change the frequency point or cursor up Confirm the current operation RF OUT... -
Page 6: Features
2. FEATURES • Integration of H.264/AVC HD Encoder and DVB-T Modulator in a 19” 1U rack mount system • Quad HD video inputs • Adopt multiple audio formats • 1 x DVB-T RF out • Bandwidth: 6/7/8MHz • Frequency range: 50~860MHz • Software attenuator • Support Low Delay • LCN (Logical Channel Number) support... -
Page 7: The Menu Osd Instruction
English THE MENU OSD INSTRUCTION Modulator will initialize to the boot interface after power on, and press into the main menu. There are 5 options in main menu: • RF1 System Set • Channel 1 Setup • Channel 2 Setup • Channel 3 Setup • Channel 4 Setup 3.1 RF1 SYSTEM SET... -
Page 8: Channel 1/2/3/4 Setup
70~100dBuV. • NID: Network ID can be modified by YZAB key. • ONID: Original Network ID can be modified by YZAB key. • TSID: Transport Stream ID can be modified by YZAB key. • Factory Set: press to confirm factory reset. 3.2 CHANNEL 1/2/3/4 SETUP • LCN: Logic Channel Number can be modified by YZAB key. -
Page 9: Technical Specification
English 4. TECHNICAL SPECIFICATION INPUT 4 x HDMI(HDCP): Type A receptacle VIdeo Input 4 x HDMI type A receptacle Audio Input Encoding Video Resolution 1080p @30p/25p Video Compression H.264/ AVC Audio Compression MPEG-1 Audio layer II (ISO/IEC 11172-3) PID Setting PMT/ Video/ Audio/ PCR NID/ ONID/ P.D.S./ TS ID At most 4 numbers... - Page 10 USER’S MANUAL...
