DINING CHAIR W/ARMS
I N ST R U C T I O N S
ASSEMBLY
STEP 1. Attach chair seat to left and right front legs using (4) barrel
bolts and barrel nuts.
Note: Name plate hidden to show assembly.
RIGHT
RIGHT
FRONT
FRONT
LEG
LEG
BARREL
BARREL
NUT
NUT
CHAIR SEAT
CHAIR SEAT
LEFT
LEFT
FRONT
FRONT
LEG
LEG
HARDWARE PACK
HHDCA1: Hardware Pack Weight: 6.5 oz.
CHAIR PARTS
• CHAIR BACK/BACK LEGS
• CHAIR SEAT
• LEFT LEG ASSEMBLY
• RIGHT LEG ASSEMBLY
• NAMEPLATE
• LOWER FRAME
SUGGESTED TOOLS
• RUBBER MALLET
• PHILLIPS HEAD SCREWDRIVER
• DRILL
(4) 2" SCREWS
(2) 3" SCREWS
(12) 2" BARREL BOLTS
(12) BARREL NUTS
(1) ALLEN WRENCH
(1) SQUARE-HEAD BIT
Advertisement
Related Manuals for Hatteras Hammocks HHDCA1-K
Summary of Contents for Hatteras Hammocks HHDCA1-K
- Page 1 DINING CHAIR W/ARMS HARDWARE PACK I N ST R U C T I O N S HHDCA1: Hardware Pack Weight: 6.5 oz. (4) 2” SCREWS (2) 3” SCREWS (12) 2” BARREL BOLTS (12) BARREL NUTS (1) ALLEN WRENCH (1) SQUARE-HEAD BIT ASSEMBLY STEP 1.
- Page 2 ASSEMBLY STEP 2. Use (2) 3” screws to attach STEP 3. Use (6) 2” bolts and barrel name plate to chair front legs. nuts to attach chair back to chair seat. CHAIR BACK 3” SCREW 2” BOLT NAME PLATE BARREL STEP 5.
