1. Remote control sensor
2. Indicator LED: RED
3. Keyboard
REAR Terminals (Bottom)
All the terminals are (from left to right):
LAN, USB, COAXIAL, HDMI3, HDMI2, VIDEO, AUDIO INPUT (LEFT & RIGHT).
REAR Termianls (Side)
All the terminals are (from left to right):
RF, USB, CI, HDMI1, HEADPHONE.
The rocker button (keyboard) is located at the
bottom left near the right side of the signal indicator.
Rocker
TV Status
Power Off
No display
when power on
Play
Press and hold the rocker button to call
the setting menu, where you can power off
or select the source.
STANDBY
COAXIAL
Button
Pull Up / Down Pull Left / Right
Null Null
Move Up / Move Left /
Down Right
Fast Forward /
Play Menu
Fast Rewind
• Power off: press to power off.
• Source: press the source button to
open signal source interface.
• Menu: press the menu to display the
OSD menu.
Press
Press to power on
Press to Confirm
Press and hold to pop up setting
menu (power off / select source)
Press to
Confirm
