Colección
instrucciones de
1
Carry out the assembly following the numerical sequence shown in the drawing.
Hacer el montaje exactamente según la secuencia numérica del dibujo.
1
Lock Nut
/ Tuerca
2
Fix Joint
/ Soporte jo + anti-twist
3
Threaded rod
/ Varilla con rosca
4
Tube
/ Tubo
5
Base
/ Base
6
Washer
/ Arandela
7
Blind Nut
/ Tuerca ciega
www. v ondom.com
t. +34 96 239 84 86
vondom@vondom.com
Avda. Valencia 3 / 46891 / Palomar / Valencia / Spain
2014 - rev 1
MARI-SOL/MARI-SOL Collection
montaje/assembly instructions
Ref. 65009T / 65010T / 65011T
1
2
3
4
5
6
7
anti-twist
