65031T
MONTAJE
Colección Mari-Sol /
Instrucciones para montaje /
x 2
Soporte Abatible
Folding Mechanism
!
Tuerca Autoblocante M 10
M 10 Self-locking Nut
Varilla Roscada M 10
M 10 Threaded Rod
Tubo
Cylindrical Tube
Base
Base
Tuerca con Collar M1 0
!
Llave Hexagonal Nº 17
M 10 Flange Nut
Nº 17 Hexagonal Wrench
www.vondom.com / t. +34 96 239 84 86 / vondom@vondom.com / Polígono 6, 16 / 46293 / Beneixida / Valencia / Spain
x 2
x 2
Mari-Sol Collection
Assembling instructions
x 2
x 12
x 2
x 2
Soporte Abatible
Folding Mechanism
!
!
Pata de Nivelación
Leveling leg piece
