assembly instructions collapsable top
1
Threaded rod
/ Varilla con rosca
2
Base
/ Base
3
Pro le
/ Per l
4
Adapter disc
/ Disco adaptador
5
Folding Joint + anti twist
6
Nut
/ Tuerca
7
Screw M6 (x6)
/ Tornillo M6 (x6)
8
Allen wrench
/ Llave Allen
www. v ondom.com
t. +34 96 239 84 86
vondom@vondom.com
Avda. Valencia 3 / 46891 / Palomar / Valencia / Spain
2018 - rev 1
DELTA Collection
66006T / 66007T / 66008T
/ Sistema abatible + anti twist
66006T
/ instrucciones de montaje abatible
66007T
6
5
4
3
2
1
66008T
