- Page 1 User’s Manual Portable Media Player...
-
Page 2: Table Of Contents
Contents 01 Main Functions..02 Precautions... 03 About Player ... 04 Display Description ... 05 Basic Operations ..06 System Menu... 08 Music Play ... 10 Video Play ... 11 Voice Record ... 11 Resource Manager ... 12 Picture Browse ... -
Page 3: Main Functions
02 Main Functions 2.8-inch real color TFT display Support MP3, WMA, FLAC, APE (only fast and normal solution) music format Support micro SD card Support MPEG-4 (AVI) video (requiring file to be converted), and FLV (320*240 and low Resolution), ultra clear display Support picture browse in JPEG, BMP and GIF format Built-in MIC, ultra long record Energy-saving setting, brightness control, auto power off... -
Page 4: Precautions 03
Don’t use the player in extremely hot, cold, dusty or damp environment. Don’t drop the player when using it. The service life of the battery is subject to the using condition, manufacturer and production date. Please charge the battery in the following instances: A. -
Page 5: Display Description 05
Next/F.FWD VOL+ MENU/Exit Previous/F.REV A-B repeat, record VOL - Play/Pause Enter / Select Mini SD port Microphone Earphone Speaker Power switch USB port Display Description 05... -
Page 6: Basic Operations
06 Basic Operations... - Page 7 Power On/Off Power On: push power switch to position, then press and hold display the boost picture and enter into Function Selection menu. Power Off: a. In Play status, short press b. In other modes, press and hold for 3 seconds to power off. c.
- Page 8 Connect to Computer and File Transfer After starting your computer, plug the USB cord into the player and wait for the computer to recognize the device. Select the file that is associated with the device and then drag and drop your selected media in the window.
-
Page 9: System Menu
08 System Menu In the main menu, press enter function, in submenu press and hold to exit and return main menu. In Main menu, select [Setting] option, press to enter Setting menu (shown as following picture), then press to select your required sub item to set. (Music and Record settings are described in relative functions) Display Setting 1. -
Page 10: Music Play
Auto Play Set Two sub items Text, and Jpeg. Text: 1s, 2s, 3s, 4s, 5s, text turn over page time. Jpeg: 1s, 2s, 3s, 4s, 5s, text turn over page time. System Setting Three sub items: Language, About, and Update. Language: 20 languages such as Chinese, English and so on. -
Page 11: Video Play 11
Play/Stop In Music Play menu, press to select your song files to play, and then press playing press to pause, press to play again. Or short press file to play. If the file is attached with LRC file, the player will simultaneously display lyrics. Setting Menu of Music Play In Music Play status, press and hold to enter the Main Menu, then select “Settings”，then “Music.”... -
Page 12: Voice Record 11
Play/Stop In Video Play menu, press to select your required video file to play, short press short press into Video Explorer to select the video file to play. Recording In Main interface, select “record”, press to enter prepared Record, and then press to begin or pause recording. - Page 13 12 Explorer Explorer Explorer is a feature of this player; it provides you with clear information about the file categories and directories inside player, for the management and search of file directories by category. Select and delete File In Explorer, you can select your favorite music or video files, then press During the selection, if you do not require the file, you can short press to select “YES”...
-
Page 14: Txt Browse
Download Files of TXT Format Connect player to computer, select your required file to download, open the file with tools of notebook, save to portable disk in TXT format and ANSI code. You can also copy TXT file with ANSI code to the portable disk. Read Files In Main interface, select “TEXT”... -
Page 15: Usb And Charge
14 Game Russian Block Keys Description: Russian Block is operated in horizontal, short press Pause. to control the block to move leftwards or rightwards, short press shape, to fast fall down, short press to fall down directly, long press 14 Use USB and Charge USB Display Mode This player has high-speed USB2.0 port, with standard portable disk function, supports Windows98 (driver is required), Windows 2000/XP (no need of driver) system, after... -
Page 16: Convert Video File
The conversion software of this player supports formats of avi, mpg, mpeg, rm, rmvb, dat and converts to the supportable AVI format of this player in fast speed and high quality. 01> Run the Video Conversion Tool in attached disk, click to install AVIConverter V3.0 After the installation, open and click the desktop Start/Program/AVIConverter/AVIConverter. - Page 17 16 Convert Video Files 02> Display the dialog box of conversion parameters: A: Firstly select video source file: click “Source File” button in the right of converter, then select the video file to be converted. B: Then select targeted path: click “Targeted Path” button in the right of converter, and then select the path to save the file.
- Page 18 03> Select the conversion quality and height/width (resolution should be set as 320x240), after setting the parameters, click “Save” button. 04> After saving the set parameters, click “Begin to convert file”. Convert Video Files 17 When the converting process reaches 100%, it will indicate Conversion Finished, which means the Video Conversion was successful, transfer the converted file to MP3 via USB data cable for watching.
-
Page 19: Firmware Update
18 Firmware Update Player can resume the damaged driver firmware via the updating tool of tool software in attached disk. Notice: Firmware updating tool .exe is the installation version for the Updating tool of Firmware. Please install firstly, then run the updating tool in Start menu or desktop. After the running, push the player power switch to the on position, then press and hold , then connect USB, do not release until the new hardware is found, at the time, if it is the first updating for your computer, please install the driver, directly click NEXT to search the... - Page 20 02> Please run next step per the prompt from dialog box, then click Browse, point to the RockUSB Driver directory in updating tool of driver CD-ROM, then the installation is finished. 20 Firmware Update...
- Page 21 03> Please run next step per the prompt from dialog box, then click Browse, point to the RockUSB Driver directory in updating tool of driver CD-ROM, then the installation is finished. Firmware Update 21...
- Page 22 04> When the program required by computer has been installed, you can carry out the Updating; first turn off MP4 (push ON/OFF to OFF position) to select and run Firmware updating tool, (Turn on computer: Start=>Program=>ConsumerUpdate=>FirmwareUpdate), then open Option to select RM600-10002.rfm file (shown as interface).
-
Page 23: Troubleshooting 23
05> Connect player to PC via USB cable (before connection, press and hold), then click [Record Firmware] till the auto updating is finished (shown as above figure). Or turn on MP4 and enter into Setting=>System Setting=>Firmware Update=>Confirm and connect via USB, then click [Record Firmware] till the auto updating is finished. -
Page 24: Technical Specifications
The player cannot be turned on. Check if the battery is weak Connect to power adapter, and check again If the player cannot power on after charge, please contact our distributor No voice can be heard from the earphone. Check if the volume is set as 0 Confirm the earphone is properly connected. - Page 25 Display Connect to computer Flash memory 600mAh lithium polymer battery Power, Play time Video play for about 3~4 hours; Audio play for about 15 hours (earphone, no display) Sampling rate Voice record MIC record format Record method Max. output power of earphone MP3 bit rate WMA bit rate FLAC...
