- Page 1 User’s Manual – A S Drywall Sander REBO Drywall Sander AR-HE-LS700CD User’s manual Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Safety Instructions
User’s Manual – A S Drywall Sander REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/ or damage to product or property. - Page 3 User’s Manual – A S Drywall Sander REBO Insulated housing (protection class II)! General Safety Guidelines • Warning: Read all of the safety guidelines and instructions. Failure to comply with the safety guidelines or instructions can result in electrical shock, fire, and/or serious injury. The term used in the Safety Guidelines “Power Tool”...
-
Page 4: Parts List
User’s Manual – A S Drywall Sander REBO Parts List... - Page 5 User’s Manual – A S Drywall Sander REBO sandpaper screw ST3X8 screw M6*12 coil spring adhibit tray Cover wool mat cable shield sheath nylon brush/skirt cable cover spring screw ST4X8 plastic disc cable clip thread axes back cover oil seal screw ST4X14 bearing 6001 screw ST4X16...
- Page 6 User’s Manual – A S Drywall Sander REBO screw M4X20 gear shaft nut M5 triangle case cover Bevel Gear damping pillar bearing 629 triangle outside pad rotor triangle inside pad bearing 607 drilling screwST3.9X11 Wind loop triangle big gear screw ST4X50 bearing housing insulation sheet balance block...
- Page 7 User’s Manual – A S Drywall Sander REBO DELTA PAD FOREWORD • The Drywall Sander is designed for sanding walls and ceilings that are made of drywall or plaster. The Sander provides a superior finish, and is faster than conventional finishing methods for both new construction and renovation work.
- Page 8 User’s Manual – A S Drywall Sander REBO • In the case where the use of the power tool in a damp area is unavoidable, use a residual current device to reduce the risk of an electrical shock. Personal Safety •...
-
Page 9: Installation
User’s Manual – A S Drywall Sander REBO Warning While working with this tool, the dust caused can be dangerous to one‘s health: • • While working with a sander always wear eye protection and a dust mask. • Do not work with material containing asbestos. Asbestos is known to cause cancer. Special caution while sanding material containing lead: •... - Page 10 User’s Manual – A S Drywall Sander REBO • DO NOT USE THE SANDER WITHOUT A PROPER ABRASIVE PAD INSTALLED (to prevent severe damage to the work). The replacement of grinding disk • The output shaft is inserted into the adhesive disc center with an angle wrench and turned clockwise into the hex hole.
- Page 11 User’s Manual – A S Drywall Sander REBO SPEED ADJUSTER ANGLE GRINDING • In order to do side grinding work, assemble with delta pad.
-
Page 12: Carbon Brush Replacement
User’s Manual – A S Drywall Sander REBO CARBON BRUSH REPLACEMENT • The accessories include an original set of carbon brush, when the carbon brush reaches its wear limit, replace with a new one. Use a "+" screwdriver counter-clockwise to unscrew the brush cover, remove the original carbon brush, place a new carbon brush and screw the brush cover. -
Page 13: Cleaning And Maintenance
User’s Manual – A S Drywall Sander REBO Cleaning and Maintenance • Keep tools clean, clean up debris and dust. • Often add in lubricating oil and grease (reducer, bearing) to keep the tool flexible in operation. • Always check the power cable, plug, switch, so that the tool is in good condition. •... -
Page 14: Eu Declaration Of Conformity
Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10 – 11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
