- Page 1 User’s Manual – A S Drywall Sander REBO Drywall Sander AR-HE-LS700C8 User’s Manual Please follow all security measures in this user’s manual to ensure a secure use.
-
Page 2: Safety Instructions
User’s Manual – A S Drywall Sander REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/ or damage to product or property. - Page 3 User’s Manual – A S Drywall Sander REBO • Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. •...
- Page 4 User’s Manual – A S Drywall Sander REBO of your power tool. Incorrectly sized accessories cannot be adequately guarded or controlled. • Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted by flanges, the arbour hole of the accessory must fit the locating diameter of the flange.
- Page 5 User’s Manual – A S Drywall Sander REBO • Maintain firmly the power tool and position your body and arm for you allow to resist kickback forces. Always use auxiliary handle, where applicable, for maximum control of kickback or torque reaction during startup. The operator can control the reaction torques or forces rebound, if precautions are taken.
-
Page 6: Installation
User’s Manual – A S Drywall Sander REBO Installation Description 1. Plastic guard 2. Motor 3. Foldable button 4. Speed adjuster 5. Push switch 6. Extendable handle INSTALLATION • Before repairing or replacing any electrical parts or accessories, be sure to unplug the appliance. - Page 7 User’s Manual – A S Drywall Sander REBO • Insert the telescopic pipe into the front pipe, adjust to the desired length, turn the locking nut into the front plastic pipe and lock. • The Drywall Sander is designed for sanding walls and ceilings made of drywall or plaster. The Sander provides superior finish and is faster than conventional finishing methods for both new construction and renovation work.
- Page 8 User’s Manual – A S Drywall Sander REBO CHOOSING THE SANDPAPER • According to the material and grinding effect, choose the appropriate sandpaper. Material Usage Sandpaper Pigment Removal of pigment layer Paint Removal of paint Filling agent Sanding pigment (such as finishing bottom) Interstitial material Removal of pickling, sanding residues Pigment layer drips and...
- Page 9 User’s Manual – A S Drywall Sander REBO STARTING AND STOPPING THE DRYWALL SANDER • Make sure power circuit voltage is the same as shown on the specification plate on the sander and that the sander switch is on OFF. Connect Sander to power circuit. •...
- Page 10 User’s Manual – A S Drywall Sander REBO SANDING OF GYPSUM JOINTS • The Drywall Sander has a special sanding head: the head can rotate in multiple directions, allowing the abrasive pad to adjust to the work surface. This enables the operator to sand the top, middle and bottom of a wall or ceiling joint without changing its position.
-
Page 11: Cleaning And Maintenance
User’s Manual – A S Drywall Sander REBO LARGE BRUSH • A large brush surrounds the abrasive pad. It serves two purposes: (1) It extends below the surface of the abrasive pad so that it is in contact with the work surface first. This positions the sanding head parallel to the work surface before the abrasive comes into contact with the working surface, preventing the abrasive from causing scratches. -
Page 12: Technical Specifications
User’s Manual – A S Drywall Sander REBO Technical Specifications Power 750W Voltage supply 230-240V Frequency 50Hz Speed 1000-2100 rpm Protection class Disc Diameter Ø225mm 83,1 dB(A) ；KpA = 3 dB(A) Sound pressure level Lpa Sound power level Lwa 94,1 dB(A)； KwA = 3 dB(A) •... -
Page 13: Disposal Instruction
User’s Manual – A S Drywall Sander REBO Disposal Instruction Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. - Page 14 Korhan Canbolat Office address: Canbolat Vertriebs GmbH Gneisenaustraße 10 – 11 D-97074 Würzburg Return address can be found in the imprint: https://www.arebos.de/impressum/ VAT identification number: DE 263752326 Court of the Commercial Register is Würzburg, HRB 10082 WEEE Reg.-No. DE 61617071...
