Goodwe HCA Series Quick Installation Manual
Ac charger
Hide thumbs
Also See for HCA Series:
- Quick installation manual (100 pages) ,
- User manual (63 pages) ,
- Quick installation manual (29 pages)
Related Manuals for Goodwe HCA Series
Summary of Contents for Goodwe HCA Series
- Page 1 Quick Installation Guide AC Charger HCA Series (GW7K-HCA GW11K-HCA GW22K-HCA) V1.0-2022-10-18...
- Page 2 The manufacturer shall not be liable for equipment damage or personal injury if you do not follow the instructions. For more warranty details, please visit: https:// en.goodwe.com/warranty. Safety Disclaimer Instructions during Installation 1. Do not dismantle the charger modules personally. Do not extend the charging cable.
-
Page 3: Check Before Power On
High-temperature hazard. Do Grounding point. not touch the product under operation to avoid being burnt. CE Certification Marking Do not dispose of the inverter as household waste. Discard the product in compliance with local laws and regulations, or send it back to the manufacturer. -
Page 4: Product Introduction
Product Introduction RS485 Communication Indicator Input Port for AC cable Port Charging Cable Mounting Plate 6. Emergency Stop Button Charging Connector... - Page 5 170mm 150mm 208mm 219mm 100mm 150mm RCD for GW11K-HCA & GW22K-HCA 107mm 92mm RCD for GW7K-HCA...
- Page 6 120mm 60mm 185mm 115mm 250mm 250mm 250mm...
-
Page 7: Installation
Installation Deliverables N=Quantity depends on the specific system configuration. Space Requirements... - Page 8 Angle Requirements Wall Mounting - Charger Φ: 8mm D: 50mm 2N·m...
- Page 9 Wall Mounting-Distribution Board Distribution Board (Type I) Φ: 6mm D: 35mm Distribution Board (Type II) Φ: 8mm D: 45mm Post Mounting-AC Charger Φ: 14mm D: 75mm...
- Page 10 2N·m Post Mounting-Distribution Board Distribution Board (Type I)
-
Page 11: Electrical Connection
Distribution Board (Type II) Electrical Connection Cable Requirements Cable Type Cable Specification GW7K-HCA Three core outdoor AC • Copper, -30℃ ~ +50℃, 450/750V cable • Outer diameter: 11~17mm • Conductor cross-sectional area: 6mm GW11K-HCA • Copper, -30℃ ~ +50℃, 450/750V AC Cable •... - Page 12 RCD-1 Connector 260mm 10mm 120mm 10mm 230mm 10mm 10mm 3.5N·m...
- Page 13 RCD-2 Connector 330mm 10mm 100mm 10mm 285mm 3.5N·m...
- Page 14 AC-1 Connector 25-35mm 10mm 1.2N·m...
- Page 15 AC-2 Connector 25-35mm 10mm 1.2N·m...
- Page 16 Power ON and OFF Connected to the grid Utility Grid Utility Meter Charger Connected to PV String and Batteries Charger Inverter PV String Utility Meter Utility Grid Battery Power ON Power OFF Connected to Connected to the grid: the grid: Connected to PV Connected to PV String and Batteries:...
- Page 17 Commissioning Commissioning via SolarGo App Commissioning via SEMS Portal App For more information, please scan the following QR for User Manual. HCA Series User Manual...
- Page 18 Official Website GoodWe Technologies Co., Ltd. No. 90 Zijin Rd., New District, Suzhou, 215011, China www.goodwe.com service@goodwe.com 340-00857-00 Local Contacts...
