- Page 1 KEEP THIS MANUAL WITH THE BED AT ALL TIMES! STOP! WARNING - All persons operating this bed must read this entire manual before using the bed! PN 63149 Revised 0617 TF2OM0617pn63149.indd...
-
Page 2: Table Of Contents
II is a trademark of Burke, Inc. ™ The information in this manual is subject to change without notice. Burke, Inc. makes no commitment to update or keep current, the information contained in this manual. Additional copies of this manual may be obtained from Burke, Inc. -
Page 3: Introduction
This patient weight includes anyone over 181 kg. / 400 lbs. but not to exceed 455 kg. / 1000 lbs. The Tri-Flex II bed is multi-purpose capable. The patient sur- face can be raised or lowered to facilitate patient care. The bed has Trendelenberg and Reverse Trendelenberg function in the pendant as well as “Cardio-Chair”... -
Page 4: Typographical Overview
• This indicates a battery: • This indicates that a process, agent or item should not be used: • Exposion Hazard Not for use in oxygen environment • Caution When Lowering End of Bed TRI-FLEX II BED - OPERATION MANUAL... - Page 5 Use by authorized personnel only 425 lbs. Type B, Class 1 IP-54 max load: 454.5-Kg/1000-lbs. Supply: 230VAC/50HZ, 1.5-amperes Duty Cycle: 10%, 6 min/hr. 205 kg. 136 kg. 450 lbs. 300 lbs. ETL Label Tri-Flex II Trapeeze Label TRI-FLEX II BED - OPERATION MANUAL 3...
-
Page 6: Safe Working Load
(492.1 kg). The sum of the Patient Weight and Accessories installed on the bed is not to exceed the SWL. • This indicates Maximum Patient Weight (MPW): The MPW for the Tri-Flex II is 1,000 lb (453.6 kg). Calculating the Safe Working load If multiple accessories are used on the bed and they weight more than 85 lb (38.6 kg), the... -
Page 7: Specifications
Trapeze - Single Arm or 4C/3P Dual Passage Assist Manufactured by Burke, Inc. Instructions for use, cleaning and disinfecting for the 1800 Merriam Lane above options can be found in the supplemental manuals. Kansas City, Kansas TRI-FLEX II BED - OPERATION MANUAL 5... -
Page 8: Important Safety Information
• WARNING: All bed functions should be tested for correct performance prior to use. • WARNING: When bed is in use, the CASTERS must be positioned so that the tabs are locked and pointed towards the foot end of the bed. TRI-FLEX II BED - OPERATION MANUAL... - Page 9 1/2 bed length tent. Oxygen tents should not extend below the mattress support level. • WARNING: The Tri-Flex II electronics are not designed to be operated in environments containing FLAMMABLE ANESTHETICS. • WARNING: AVOID CONTACT WITH INJURED SKIN. It is not intended for this device to come in contact with injured skin.
-
Page 10: Electromagnetic Compatibility
While Burke has made every effort to ensure that RFI does not cause problems, very strong signals could cause a movement of a section of the bed. Such movement would be of very short duration and travel. -
Page 11: Basic Operational Instructions
Be sure to fully reengage the lock pin when adjusting the width of the bed. To maximize the full scope of UL 60601-1 / IEC 60601-2-38 (1996;1999), this bed is intended for patient use in ONLY THE 122 cm (48”) OR 137 cm (54”) WIDTH CONFIGURATIONS. Within the current standard, patient and caregivers are safely removed from pinch points and moving components which could cause harm. Configurations other than described reduce the distance to these points which could result in severe personal injury or equipment damage. TRI-FLEX II BED - OPERATION MANUAL 9... -
Page 12: Pull/Lock Pin Locations
TO MOVE HEAD SIDE RAIL - movement of side rail should only be performed using hand loop as shown. Release lock, grasp hand loop and move side rail TOWARD FOOT END of bed. Side rail only locks in full up position. Figure 3 TRI-FLEX II BED - OPERATION MANUAL... -
Page 13: Cpr Procedure
Operational Instructions Tri-Flex II with Fold Down Side Rails To lower the fold down side rail, hold the top of the side and pull up the spring loaded pull pin. Rotate the side rail away from the bed. Allow the side rail to rotate downward until it comes to a stop. -
Page 14: Patient Transfers
WARNING: DO NOT PULL OR PUSH ON HEAD GATCH TO MOVE THE BED. NOTE: Remember to plug the Tri-Flex II bed into the wall outlet once transport of the bed is complete. TRI-FLEX II BED - OPERATION MANUAL... -
Page 15: Repositioning (Boosting) Procedure
43 cm - 48 cm (17” - 19”) from wall with a trapeze when in the Trendelenberg position. • WARNING: Keep clear of head end bed when repositioning a patient towards the head end of the bed. TRI-FLEX II BED - OPERATION MANUAL 13... -
Page 16: Cleaning / Disinfection Instructions
Burke recommends a chlorine based solution no greater than 10,000 PPM for routine decon- tamination. The bed and components should also be cleaned and disinfected between patients and be- fore returning to service after a period of storage, per facility guidelines. - Page 17 CLEAINING & INSPECTION CHECK-LIST This list is provided as a guide to assist with documentation. Burke recommends the following procedures be conducted before each new patient and before return to service if bed has been in storage. Cleaning & Disinfecting Bed Unplug power cord of bed before performing maintenance Wipe down frame and appropriate options with disinfectant.
-
Page 18: Storage And Service
The manufacturer of this equipment will provide assistance to the user’s appropriately qualified technical personnel to repair those parts of the equipment which are designated by the manufacturer( Burke) as repairable. Use only replacement components which are approved and designated as acceptable by the manufacturer ( Burke) See also the options/mattress manuals for specific service instructions for the Impulse Drive, Low Air Loss Mattress and Barri-Float Foam Mattress. TRI-FLEX II BED - OPERATION MANUAL... -
Page 19: Troubleshooting
If none of these suggestions results in full function returning to the bed, then refer to a properly trained service personnel for technical assistance. WARNING: If the bed loses any function or is damaged in any way stop using the bed immediately and refer it to a qualified service personel. Otherwise further equipment damage or personal injury may result. TRI-FLEX II BED - OPERATION MANUAL 17... -
Page 20: Control Schematics
The fuses are designated as follows: 5x20mm 1.6L250V Time-Lag fuse (1.6A/250V) Wickmann Series 19195 or equivalent DISPOSAL The bed and various components consist of plastic, metal parts and electrical components. Recycle per local, state or national regulations. TRI-FLEX II BED - OPERATION MANUAL... -
Page 21: Identification Of Major Components
Major Component Identification TRI-FLEX II BED - OPERATION MANUAL 19... -
Page 22: Scale System (Optional)
Scale System System Wiring Diagram (Optional) TRI-FLEX II BED - OPERATION MANUAL... -
Page 23: Setup / Disassembly Instructions
(See Figure 12). As you adjust the turnbuckle body the dots on the screws will move toward each other when tightening and away from each other when loosening. • Observe the correct movement inward/outward as you install/remove this piece. • Install one turnbuckle making sure not to over tighten. Install and tighten the opposite turnbuckle the same as the first. TRI-FLEX II BED - OPERATION MANUAL 21... -
Page 24: Folding For Transport
Lower the Head Gatch and Foot Gatch. 5. Raise the bed hi-low approx. 12.7 cm (5”) to allow the Transport Wheel assemblies enough room to pivot down. 6. Remove the pull pin securing the central transport wheel assembly. Pivot each assembly down and lock in place with the pull pin. TRI-FLEX II BED - OPERATION MANUAL... - Page 25 17. Carefully raise foot end and lock to transport pole with the transport latch bracket. 18. Secure the AC power cord to holder. 19. Store the head and foot boards on the bed as well as the Foot Side Rails. (See Figure 15.) Figure 15 TRI-FLEX II BED - OPERATION MANUAL 23...
- Page 26 LIMITED WARRANTY Burke, Inc. - Tri-Flex II, Serial Number ( _________________ ) warrants to the original purchaser (whom the bed is shipped to) against manufacturers defects in material and or workmanship for the indicated from the date of purchase under normal usage* and so long as all applicable procedures** are adhered to. Burke’s warranty does not include labor in the field. Only...
