LIGHT MY BRICKS SUPER MARIO THE MIGHTY BOWSER 71411 Installation Manual
  1. Manuals
  2. Brands
  3. LIGHT MY BRICKS Manuals
  4. Lighting Equipment
  5. SUPER MARIO THE MIGHTY BOWSER 71411
  6. Installation manual

LIGHT MY BRICKS SUPER MARIO THE MIGHTY BOWSER 71411 Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
LEGO
SUPER MARIO THE MIGHTY
®
BOWSER #71411
INSTALLATION GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUPER MARIO THE MIGHTY BOWSER 71411 and is the answer not in the manual?

Questions and answers

Related Manuals for LIGHT MY BRICKS SUPER MARIO THE MIGHTY BOWSER 71411

Summary of Contents for LIGHT MY BRICKS SUPER MARIO THE MIGHTY BOWSER 71411

  • Page 1 LEGO SUPER MARIO THE MIGHTY ® BOWSER #71411 INSTALLATION GUIDE...
  • Page 2 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Light My Bricks LEGO SUPER MARIO ® THE MIGHTY BOWSER 71411 INSTALLATION GUIDE Hi There! We’re here to help you get started on the LEGO ® Super Mario The Mighty Bowser #71411 Light Kit.
  • Page 3 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® PACKAGE CONTENTS: ASSORTED BRICKS: 7 x 1x1 Round Plate W/Open Stud - Black 1 x 1x2 Plate Mod W/ Stud Jumper - Black 4 x 1x2 Plate - Light Grey 4 x Orange Large Bit Light - 30cm 2 x 1x1 Plate - Light Grey 4 x Warm White Large Bit Light - 15cm...

  • Page 4: Table Of Contents

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Contents Before You Begin Blueprint Instructions Final Product Troubleshooting Contact CONTENTS...

  • Page 5: Before You Begin

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Before You Begin Laying cables in between Connecting Cable and underneath bricks Connectors To Expansion Boards Cables can fit in between and underneath LEGO bricks, plates, and tiles providing ®...
  • Page 6 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Before You Begin Connecting Cable Connecting Micro Cable Connectors To Strip Lights Connectors To Micro Expansion Board Ports Take extra care when inserting connectors to ports on the Strip Lights. Connectors Take extra care when inserting the can be inserted only one way.
  • Page 7 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Before You Begin Installing Bit Lights Under Lego® Bricks And Plates When installing Bit Lights under LEGO ® pieces, ensure they are placed the correct way up (Yellow LED component exposed). You can either place them directly on top of LEGO studs or in between.
  • Page 8 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Before You Begin The Symbols Used In This Guide Connect Turn/ Flip When going through the following guide you will Used when you need to Will be found in the top left come across symbols and formats that will assist connect a LEGO piece or LMB corner when the set needs to...
  • Page 9 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Before You Begin General Note Repeat Step NOTE This is a sample note that is Repeat the previous step eg. used anywhere in this guide. It Make a spotlight, then make a Take the 5cm Connecting Cable will explain a difficult section from the 4-Port Micro Expansion...

  • Page 10: Blueprint

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® BLUEPRINT Mighty Bowser Blueprint Orange 30cm Large Bit Light 2 x White 30cm Large Bit Light 2 x White 30cm Large Bit Light 3x Orange 30cm Large Bit Light 6-Port 6-Port Expansion Board...

  • Page 11: Instructions

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS To ensure a smooth installation of your light kit, please read and follow each step carefully. If you run into any issues, please refer to the online troubleshooting guide.
  • Page 12 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 13 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Orange 30cm Large Bit Light Round Plate 1x1 Open Stud - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 14 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Plate 1x1 Mod Rounded W/ Handle - Black Plate 1x2 Mod W/ Stud Jumper - Black Tile 1x1 W/ Clip Round Edges - Black INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 15 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Plate 1x1 - Light Grey Plate 1x1 - Light Grey INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 16 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Plate 2x2 W/ Rounded Bottom - Trans Clear INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 17 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 18 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 19 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® 8-Port Expansion Board NOTE Connect to a 5V USB Power Bank, 5V USB Wall Adaptor, or USB to AA Battery Pack (sold separately) USB Power Cable If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify...
  • Page 20 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Plate 1x2 - Light Grey Wireless Power Connector Pad INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 21 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® NOTE Slightly disconnect the following section but do not fully remove. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 22 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Flicker Effects Board 5cm Connecting Cable 2-Port Expansion Board NOTE Connect the Wireless Connector Cable from the into one of the “OUT” ports of the Flicker Effects Board 5cm Connecting Cable NOTE Connect the 5cm Connecting...
  • Page 23 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Wireless Power Connector Pad INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 24 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® NOTE Slightly disconnect the following section but do not fully remove. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 25 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® 2x Plate 1x2 - Light Grey Plate 1x1 Mod W/ Horizontal Clip - Wireless Power Connector Pad Light Grey Plate 1x2 Mod W/ Handle On Side - Black Plate 1x1 Mod W/ Horizontal Clip - Light Grey INSTRUCTIONS...
  • Page 26 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® NOTE Connect the Wireless Connector Cable to the “OUT” port of the Pulse Effects Board 5cm Connecting Cable NOTE Connect the 5cm Connecting Cable into the “IN” port of the Pulse Effects Board Pulse Effects Board INSTRUCTIONS...
  • Page 27 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® 2x Adhesive Square NOTE Fit all cables and components into section shown here. Ensure the USB Power Cable is hanging out the back. INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT...
  • Page 28 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 29 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Wireless Power Connector Stud INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 30 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 31 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® 2 x 6-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 32 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Warm White 15cm Large Bit Light INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 33 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 34 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Plate 1x1 Mod Rounded W/ Handle - Black Warm White 15cm Large Bit Light Round Plate 1x1 Open Stud - Black Tile 1x1 W/ Clip Round Edges - Black Round Plate 1x1 Open Stud - Black INSTRUCTIONS...
  • Page 35 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 36 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 37 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Orange 30cm Large Bit Light Plate 2x2 W/ Rounded Bottom - Trans Clear INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 38 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 39 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Wireless Power Connector Stud Plate 1x2 - Light Grey INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 40 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® NOTE Ensure you HOLD down the Wireless Power Connector as you reconnect the Tiles 2 x 2 Inverted to prevent the PCB from lifting. NOTE Ensure the PCB is flat as shown otherwise it will not connect to the corresponding Wireless Power Connector.
  • Page 41 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® 2-Port Expansion Board INSTRUCTIONS DISCONNECT POWER ON TEST CONNECT DIRECTIONAL BEND / PIVOT TURN / FLIP TWIST / BRAID NOTE ICON...
  • Page 42 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® NOTE Connect the fire pillars back in place. Make sure to look underneath so the Wireless Connectors align. NOTE For the Bit Light in Bowsers mouth to light up ensure the tail’s Wireless Connector is alined with the Base Plates Wireless Connector.
  • Page 43 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Removed Pieces NOTE If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify Connect to a 5V USB Power where the fault lies (with the light or Bank, 5V USB Wall Adaptor, or...

  • Page 44: Final Product

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® FINAL PRODUCT This finally completes installation of the Light My Bricks LEGO Super Mario The Mighty Bowser 71411 Light Kit. ® FINAL PRODUCT...

  • Page 45: Troubleshooting

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® TROUBLESHOOTING Light My Bricks lighting To prevent unnecessary If you are experiencing kits contain individual damage to components, issues with your Light components that are very we highly recommend that...
  • Page 46 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Troubleshooting Firstly, ensure that the Check for AA batteries batteries have power using a using the AA battery pack battery charge gauge. Inside the battery pack are symbols indicating which direction the AA battery If the batteries have no power, should be inserted.
  • Page 47 SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Wires In order for Light My Bricks components to fit If the wiring is detached from the LED itself, the in between and underneath LEGO bricks, the light will not operate.
  • Page 48 LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® Troubleshooting Check Your Expansion Board A short circuit can also result in overheating of the board, cable or Ports/ Strip Light Ports / batteries. If you suspect a short circuit, Effects Board Ports DISCONNECT POWER IMMEDIATELY Batteries can fail, catch fire, or even...

  • Page 49: Contact

    LEGO SUPER MARIO THE MIGHTY BOWSER #71411 LIGHT KIT INSTALL GUIDE ® CONTACT US If you have an enquiry regarding the online shop, our products or a general enquiry please refer to our Frequently Asked Questions webpage here. Alternatively, you can contact our Customer Services team by visiting our online support portal here.
  • Page 50 © 2022 Light My Bricks Pty Ltd - Head Office: 4/26 Rushdale Street, Knoxfield VIC 3180, Australia. Phone: +61 420 643 543 | All Rights Reserved | Light My Bricks™ sell LED lighting kits only. All LEGO sets featured in images are sold ®...
