  • Page 1 LEGO® THE MANDALORIAN’S N-1 STARFIGHTER #75325 LIGHT KIT INSTALLATION GUIDE...
  • Page 2 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Light My Bricks LEGO THE MANDALORIAN’S N-1 STARFIGHTER #75325 INSTALLATION GUIDE Hi There! We’re here to help you get started on the LEGO The Mandalorian’s N-1 Starfighter 75325 Light Kit.
  • Page 3 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE ASSORTED BRICKS: PACKAGE CONTENTS: • 12 x Round Plate 1x1 - Trans Dark Blue • 2 x Round Plate 1x1 Open Stud - Light Grey 1 x Red & Blue 15cm Bit Light •...

  • Page 4: Table Of Contents

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Contents Before You Begin Blueprint Instructions Final Product Troubleshooting Contact CONTENTS...

  • Page 5: Before You Begin

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Before You Begin Laying cables in between Connecting Cable and underneath bricks Connectors To Expansion Boards Cables can fit in between and underneath LEGO® bricks, plates, and tiles providing Take extra care when inserting connectors they are laid correctly between the to ports of Expansion Boards.
  • Page 6 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Before You Begin Connecting Cable Connecting Micro Cable Connectors To Strip Lights Connectors To Micro Expansion Board Ports Take extra care when inserting connectors to ports on the Strip Lights. Connectors Take extra care when inserting the can be inserted only one way.
  • Page 7 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Before You Begin Installing Bit Lights Under Lego® Bricks And Plates When installing Bit Lights under LEGO® pieces, ensure they are placed the correct way up (Yellow LED component exposed).

  • Page 8: Blueprint

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE BLUEPRINT INSTRUCTIONS...

  • Page 9: Instructions

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE INSTRUCTIONS To ensure a smooth installation of your light kit, please read and follow each step carefully. If you run into any issues, please refer to the online troubleshooting guide.
  • Page 10 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 11 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 12 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Warm White 30cm Headlight CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 13 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Round Plate 1x1 - Trans Dark Blue CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 14 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Ensure the LED side is on be bottom White 30cm Bit Light Identify which side the LED is on. This will determine which way the motor is reconnected CONNECT /...
  • Page 15 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 16 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Warm White 30cm Headlight CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 17 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Round Plate 1x1 - Trans Dark Blue CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 18 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Ensure the LED side is on be bottom White 30cm Bit Light Identify which side the LED is on. This will determine which way the motor is reconnected CONNECT /...
  • Page 19 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 20 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE 8-Port Expansion Board Bar 4L - Trans Light Blue CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 21 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Ensure the Red Axle goes through the Middle Axle hole White 30cm Bit Light CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON...
  • Page 22 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE When reconnecting this section, ensure the large circular side is facing away from the ship CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON...
  • Page 23 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 24 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Red & Blue 15cm Bit Light CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 25 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE USB Power Cable CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 26 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Gun Effects Board 5cm Connecting Cable Connect the 5cm Connecting Cable to the ‘+5V’ port of the Gun Effects Board, and the other end to the 8-Port Expansion Board CONNECT /...
  • Page 27 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Green 30cm Bit Light Round Plate 1x1 Open Stud - Light Grey CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON RECONNECT INSTRUCTIONS...
  • Page 28 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Connect the 2x Green 30cm Bit Lights to the ‘OUT’ ports of the Gun Effects Board CONNECT / Legend DISCONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST...
  • Page 29 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE If you experience any issues with the lights not working and suspect an issue with a component, please try a different port on the expansion board to verify where the fault lies (with the light or expansion board).

  • Page 30: Final Product

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE FINAL PRODUCT This finally completes installation of the Light My Bricks LEGO The Mandalorian’s N-1 Starfighter 75325 Light Kit. FINAL PRODUCT...

  • Page 31: Troubleshooting

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE TROUBLESHOOTING Light My Bricks lighting To prevent unnecessary If you are experiencing kits contain individual damage to components, issues with your Light components that are very we highly recommend that...
  • Page 32 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Troubleshooting Firstly, ensure that the Check For CR2032 Batteries batteries have power using a Using The Flat Battery Pack battery charge gauge. Inside the battery pack is a symbol indicating which side the (round) CR2032 If the batteries have no power, battery should be inserted.
  • Page 33 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Troubleshooting Check For Cr2032 Batteries Check for AA batteries Using The Round Battery using the AA battery pack Pack Inside the battery pack are symbols indicating which direction the AA battery Inside the battery pack is a symbol indicating should be inserted.
  • Page 34 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Troubleshooting Check Your Wires In order for Light My Bricks components to fit If the wiring is detached from the LED itself, the in between and underneath LEGO® bricks, the light will not operate.
  • Page 35 LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE Troubleshooting Check Your Expansion Board A short circuit can also result in overheating of the board, cable or Ports/ Strip Light Ports / batteries. If you suspect a short circuit,...

  • Page 36: Contact

    LEGO THE MANDALORIAN’S N-1 STARFIGHTER 75325 LIGHT KIT INSTALL GUIDE CONTACT US If you have an enquiry regarding the online shop, our products or a general enquiry please refer to our Frequently Asked Questions webpage here. Alternatively, you can contact our Customer Services team by visiting our online support portal here.
