Channel
DMX Value
Descriptions
1
000-255
Zoom 0-100%
2
000-255
Master dimmer 0-100%
3
000-255
Strobe from slow to fast
4
000-255
Red intensity 0-100%
5
000-255
Green intensity 0-100%
6
000-255
Blue intensity 0-100%
7
000-255
White intensity 0-100%
8
001-255
Color Macro
000-010
No function
011-119
Color step changing
9
120-179
Color cross fade
180-255
Color step changeing + cross fade
10
000-255
Auto program (CH9) speed from fast to slow
SPECIFICATIONS
Source: 19*15W RGBW high power LEDs
Beam angle: 10°-60°motorized zoom
0-100% linear dimmer, high speed strobe
DMX,Auto, Master/Slave
DMX Channel: 10ch
IP20 for indoor use only
Power input: AC100-240V 50/60Hz
Power consumption:300W max.
Dimensions: 226*285*380mm
Weight: 6.5 kg
I
MPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials that old
appliances contain and reduce the impact on human health and the
environment, ensure that this product is recycled at the end of its life.
3
FOS PAR ZOOM ULTRA
User Manual
