  • Page 1 FOS PAR ZOOM PRO User Manual...
  • Page 2 1 SECURITY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions:  non-professionals, not to disassemble the light arbitrarily and lighting accessories inside.  rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ (to be selected).
  • Page 3 2 REFERENCE Input Voltage: AC90-260V 50/60Hz Light Source: 7pcs 30w 4-IN-1 LEDs (R, G, B, W)+ 96pcsx0.2w UV SMD Power Consumption: 280W Zoom range:3-60degree Zoom Motor:2pcs Control mode:DMX512,master-slave,Sound,Auto DMX Channel: 6/9CHs Life time:60000hours 0-100% smoothly dimmer 20t/s strobe effect with variable speed IP65 protection rating Seetronic Power In/out 3-Pin XLR DMX input/output...
  • Page 4 White 0-255 0-255 Motor 0-255 Strobe 0-255 Aut1 Auto Speed(0-9) Aut2 Aut3 Reset Yes/No 4 DMX CHANNEL SHEET Channel Value Function 0--255 Red dimmer, From dark to bright 0--255 Green dimmer, From dark to bright 0--255 Blue dimmer, From dark to bright 0--255 Warm white dimmer, From dark to bright 0--255...
  • Page 5 Channel Value Function 0--255 Total Dimmer 0-100% 0--255 Red dimmer, From dark to bright 0--255 Green dimmer, From dark to bright 0--255 Blue dimmer, From dark to bright 0--255 white dimmer, From dark to bright 0--255 UV dimmer, From dark to bright 0--255 Zoom0-100% 0--255...
  • Page 6 141-145 White(8500K) 146-150 White(10000K) 151-180 Auto1 181-210 Auto2 211-240 Auto3 241-254 No function Reset (keep the value for 3 seconds) 5 FIXED EQUIPMENT Please fasten the fixture clamp before hanging. The clamp can be fasten by the little hole in the middle of the bracket, then tie with a safety cable.
  • Page 7 7 Maintenance Problems Check list Trouble Shooting The fixture do 1. If your power as same as the input 1. Make sure the voltage. not work of the machine. 2. Replace the same fuse. 2. If the fuse was broken. LED dimmed If your power us same as the input Make sure the voltage...
