XCPC-9200
Table 1-3 PMC 1 and PMC 2 Connector Pin Out
Connectors J14
Signal PIN PIN Signal
PMC1I/O-1 1
PMC1I/O-3 3
PMC1I/O-5 5
PMC1I/O-7 7
PMC1I/O-9 9
PMC1I/O-11 11
PMC1I/O-13 13
PMC1I/O-15 15
PMC1I/O-17 17
PMC1I/O-19 19
PMC1I/O-21 21
PMC1I/O-23 23
PMC1I/O-25 25
PMC1I/O-27 27
PMC1I/O-29 29
PMC1I/O-31 31
PMC1I/O-33 33
PMC1I/O-35 35
PMC1I/O-37 37
PMC1I/O-39 39
PMC1I/O-41 41
PMC1I/O-43 43
PMC1I/O-45 45
PMC1I/O-47 47
PMC1I/O-49 49
PMC1I/O-51 51
PMC1I/O-53 53
PMC1I/O-55 55
PMC1I/O-57 57
PMC1I/O-59 59
PMC1I/O-61 61
PMC1I/O-63 63
Note: The PMC rear I/O signals from Jn4 (CON8 and CON12) are routed to CompactPCI
connectors J3 and J5, the pin-out for which is described later in this chapter.
10
2 PMC1I/O-2
4 PMC1I/O-4
6 PMC1I/O-6
8 PMC1I/O-8
10 PMC1I/O-10 PMC2 I/O-9
12 PMC1I/O-12 PMC2 I/O-11
14 PMC1I/O-14 PMC2 I/O-13
16 PMC1I/O-16 PMC2 I/O-15
18 PMC1I/O-18 PMC2 I/O-17
20 PMC1I/O-20 PMC2 I/O-19
22 PMC1I/O-22 PMC2 I/O-21
24 PMC1I/O-24 PMC2 I/O-23
26 PMC1I/O-26 PMC2 I/O-25
28 PMC1I/O-28 PMC2 I/O-27
30 PMC1I/O-30 PMC2 I/O-29
32 PMC1I/O-32 PMC2 I/O-31
34 PMC1I/O-34 PMC2 I/O-33
36 PMC1I/O-36 PMC2 I/O-35
38 PMC1I/O-38 PMC2 I/O-37
40 PMC1I/O-40 PMC2 I/O-39
42 PMC1I/O-42 PMC2 I/O-41
44 PMC1I/O-44 PMC2 I/O-43
46 PMC1I/O-46 PMC2 I/O-45
48 PMC1I/O-48 PMC2 I/O-47
50 PMC1I/O-50 PMC2 I/O-49
52 PMC1I/O-52 PMC2 I/O-51
54 PMC1I/O-54 PMC2 I/O-53
56 PMC1I/O-56 PMC2 I/O-55
58 PMC1I/O-58 PMC2 I/O-57
60 PMC1I/O-60 PMC2 I/O-59
62 PMC1I/O-62 PMC2 I/O-61
64 PMC1I/O-64 PMC2 I/O-63
Connectors J24
Signal PIN
PMC2 I/O-1 1
PMC2 I/O-3 3
PMC2 I/O-5 5
PMC2 I/O-7 7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
PIN Signal
2 PMC2 I/O-2
4 PMC2 I/O-4
6 PMC2 I/O-6
8 PMC2 I/O-8
10 PMC2 I/O-10
12 PMC2 I/O-12
14 PMC2 I/O-14
16 PMC2 I/O-16
18 PMC2 I/O-18
20 PMC2 I/O-20
22 PMC2 I/O-22
24 PMC2 I/O-24
26 PMC2 I/O-26
28 PMC2 I/O-28
30 PMC2 I/O-30
32 PMC2 I/O-32
34 PMC2 I/O-34
36 PMC2 I/O-36
38 PMC2 I/O-38
40 PMC2 I/O-40
42 PMC2 I/O-42
44 PMC2 I/O-44
46 PMC2 I/O-46
48 PMC2 I/O-48
50 PMC2 I/O-50
52 PMC2 I/O-52
54 PMC2 I/O-54
56 PMC2 I/O-56
58 PMC2 I/O-58
60 PMC2 I/O-60
62 PMC2 I/O-62
64 PMC2 I/O-64
