Table 2-2 Connect the 2.4inch LCD to the 40-Pin Header
2.4inch LCD Module
VCC
GND
DIN
CLK
CS
DC
RST
BL
9
40-Pin GPIO Header
Pin Number
17
39
19
23
24
40
11
18
