2. Preparation

Before executing the demo program, make sure you prepare the following:

2.1. Preparing Hardware

Prepare the following hardware items before running the demo code:
Table 2-1 Hardware Preparation
*
Type M/O Item
Gener­ M StarFive single board computer
al
Gener­ M
al
SPI
LCD
Note:
*: M: Mandatory, O: Optional

2.1.1. Hardware Setup

The following table and figure describe how to connect LCD to the 40-pin header:
www.starfivetech.com
• 16 GB (or more) micro-SD
card
• micro-SD card reader
• Computer (Windows/MAC/
Linux)
• USB to serial converter (3.3
V I/O)
• Ethernet cable
• Power adapter (5 V / 3 A)
• USB Type-C Cable
• 2.4inch LCD Module
• Dupont Line
© 2018-2022 上海赛昉科技有限公司
版权所有
Notes
The following boards are applica­
ble:
• StarLight
• VisionFive
These items are used for flashing
Fedora OS into a micro-SD card.
-
