1. Introduction

This application note provides steps to use VisionFive's SPI to make a 2.4inch LCD display
with specified pictures.

1.1. 40-Pin Header Definition

The following figure shows the location of the 40-pin header. The VisionFive board is taken
as an example:

Figure 1-1 40-Pin Definition
