- Page 1 RO DRINKING SYSTEM USER MANUAL / Standard 5 Stage Version...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ................1 2. WHAT IS REVERSE OSMOSIS (RO) ..........2 3. SAFETY INFORMATION ..............3 4. SPECIFICATION ................5 5. INLET WATER REQUIREMENT ............5 6. HOW QUICK CONNECTORS WORK ..........5 7. PRODUCT DESCRIPTION ...............6 8. FLOW CHART ..................7 9. ACCESSORIES ................8 10. -
Page 4: Introduction
RO water purifiers, and thus able to provide pure and healthy water. You will find Puricom CT8-R3 RO system very easy to maintain, with its quick, simple, sanitary filter replacements. The good tasty water flows directly a special is also perfect for beverages such as coffee, tea and lemonade. -
Page 5: What Is Reverse Osmosis (Ro)
WHAT IS REVERSE OSMOSIS (RO): To fully understand the technology of Reverse Osmosis, it is a must to understand normal osmosis. Osmosis is a natural process that occurs in all living things. For instance, osmosis permits water and nutrient absorption through the root system of plants;... -
Page 6: Safety Information
SAFETY INFORMATION: Please read this information to prevent property loss and to ensure your safety. INSTALLATION SAFETY 1. Keep the product away from inflammable gas or burnable materials. 2. Do not install the unit near heaters. 3. Do not spray with water. Use a damp cloth to clean. 4. - Page 7 4. Periodical filter replacement is prerequisite for clean water. If filters are overused, the performance of filters is degraded. 5. Use with Puricom filter products to maintain expected product lifespan and performance. 6. After activated carbon filter replacement, a certain amount of carbon fines may be introduced to the water.
-
Page 8: Specification
SPECIFICATION: Model CT8-R3 without PUMP Capacity 50 GPD Storage Tank Size D14cm × W34cm × H44.5cm INLET WATER REQUIREMENT: Inlet water TDS < 1000 ppm Inlet water pressure 15 - 45 psi Total hardness < 250 ppm Temperature - 45... -
Page 9: Product Description
PRODUCT DESCRIPTION: Lighten Bracket 1st Stage Pre-filter Shut-off Valve 2nd Stage Pre-filter Q-PACK Storage Tank 3rd Stage Pre-filter 4th Stage RO Membrane 5th Stage Post Filter... -
Page 10: Flow Chart
FLOW CHART: Feed Water In To Faucet Shut-off Valve TANK Drain... -
Page 11: Accessories
ACCESSORIES: Accessories Pack ( * for optional ) A. PE tube B. Drain clamp C.Feed water ball valve D. Feed water connector E. Faucet F. PVC plug and screws Filters ( * for optional ) G. 1 st Stage- PP 5μ filter H. -
Page 12: Filter Function Description & Recommended Filter
FILTER FUNCTION DESCRIPTION & RECOMMENDED FILTER REPLACEMENT: REPLACEMENT STAGE FILTER FUNCTION INTERVAL FT-82 PP 5μ 3~6 months Traps dirt, rust, and other impurities. Removes chemicals and odors, such (G.A.C.) FT-83 as chlorine and chemical fertilizer. 3~6 months Set before the RO membrane can Carbon protect it from being damaged. -
Page 13: Installation Diagram
INSTALLATION DIAGRAM: Feed Water Drain Pressure Tank Pure Water... -
Page 14: Installation
INSTALLATION: A. Feed Water Assembly 1. Turn off the feed water supply, and disconnect the existing cold water line from the existing cold water supply valve. 2. Wrap several turns of seal tape on the new feed water connector and install it with the black washer on the existing cold water supply valve. - Page 15 B. Drain Clamp Assembly 1.Drill a 6mm hole on the existing drain pipe. 2.Tighten the drain clamp evenly on both sides. Connect the PE tube and complete the drain clamp Refer to p.10 assembly. C. Storage Tank Assembly 1.Connect the PE tube to the quick connector. 2.
- Page 16 D. Faucet Assembly 1. Drill a 12mm hole on the right or left hand side of the sink. 2. Install the new faucet in the sink hole, and from below the sink, assemble the mounting hardware. 3. Slide the nut from the bottom of the faucet onto the end of the tube.
-
Page 17: How To Mount The Water Purifier On Wall
HOW TO MOUNT THE WATER PURIFIER ON WALL: 1.Drill 6mm holes. 2.Hammer in PVC plugs into the wall. 3. Use a screwdriver to screw the screws into the PVC plugs. The depth of screw protrusion must be uniform ( 10mm ) to avoid damage to unit body. 4.Aim at the hole of the bracket. -
Page 18: Filter Replacement (For 1St, 2Nd, 3Rd And 5Th Stage )
FILTER REPLACEMENT (FOR 1st, 2nd, 3rd and 5th STAGE ): 1. Turn off feed water at the feed water valve. 2. Turn off the storage tank ball valve. 3. Turn on the faucet to release pressure from the tubing. Loosen Loosen Tighten Tighten... - Page 19 7. Turn on feed water at the feed water valve. 8. Turn on the storage tank ball valve. 9. Allow a tank of water to rinse through the system before use.
-
Page 20: Ro Membrane Replacement
RO MEMBRANE REPLACEMENT: 1. Turn off feed water at the feed water valve. 2. Turn off the storage tank ball valve. 3. Turn on the faucet to release pressure from the tubing. 4. Pull the disposable RO filter from the bracket. 5. - Page 21 7. Connect all the fittings. 8. Put the RO cartridge into the bracket. 9. Turn on feed water at the feed water valve. 10. Turn on the storage tank ball valve. 11. Allow a tank of water to rinse through the system before use.
-
Page 22: Troubleshooting
TROUBLESHOOTING: Problem Possibility Troubleshooting 1. Flow restrictor is clogged. 1. The ratio of permeate water to TDS value of Clean it, or replace it. drain water is less permeated water than 1:3. is rising (rejection rate is lower than 2. RO membrane is 2. - Page 23 DEMO...
- Page 24 D010123001 / 2015.12...
