    T A B L E C O N T E N T S Products Listed by Part Number on the Back Page LEAK DETECTION CHARGING/SCALES Refrigerant Scales Electronic ....... 2-5 Refrigerant Scales .

  • Page 3: Leak Detection

    • Elimination of false alarms • Unaffected by rapid temperature change • Sensor cannot be “poisoned” by excessive refrigerant Detects ALL Halogenated refrigerants, including R410A > TIF ZX-1 True Mechanical Pump provides instant response and clearing > Tri-color visual leak size indication >...

  • Page 4: Electronic

    R12 and R22 European – 230V, 50 Hz Charger TIFZX-1KITE Japan – 100V, 50/60 Hz Charger TIFZX-1J Optional Accessories & Replacement Parts Listed under TIF ZX-1 Heated Pentode™ Refrigerant Leak Detector 16600 Electronic Refrigerant Leak Detector Proven Corona Discharge technology >...
  • Page 5 Sensing Tip Life: approx. 20 hours (two tips included) > Operating Temp: 30º to 125º F (0º to 52º C) > Blow Molded Carrying Case included, optional holster > TIF XP-1A Certified to SAE J1627 > UL Classified & CE approved > See chart for warranty information >...
  • Page 6 Power Supply (Two) 1.5V “C” Batteries Battery Life 30 Hours (Alkaline) Probe/Cord Length Probe = 14" (35cm) Cord = 36" (91.4cm) TIF 5750A Operating Temperature 32º–125º F (0º–52º C) Optional Accessory Part Number Design Certified by MET Laboratories, Inc. to meet...
  • Page 7 LEAK DETECTION 16330 UV Leak Detection, Complete HVAC/R Leak Detection Kit > HVAC/R Dye Kit Includes: • Cordless UV light • Injector • 6 Dye Cartridges • Charger • UV Glasses • Connecting Hose (1/4” FFL) • “Date Installed” Labels •...
  • Page 8 LEAK DETECTION 16345 16345 True UV Led leak detection lights No. 16345 Cordless and Rechargeable true UV Led Light 12 Leds producing hi-intensity true UV light > UV enhancing glasses > Battery charger included > 16345 Cordless UV Light 16336, 16337, 16338 HVAC/R Dye Cartridge A/C Dye Replacement Cartridges...

  • Page 9: Combustible Gas

    LEAK DETECTION Solid state sensor technology, long life and > precision TIF8900 Broad band of combustible gas detection > Combustible Gas Detector Sensitivity as low as 5 ppm > Adjustable sensitivity > U.S. Patent #’s Re: 32,552; 4,282,521; 5,400,015 Audible "Geiger counter" signal >...
  • Page 10 Applications include: Gas lines and pipes, aids in > identifying Heat Exchanger leaks and hazardous living/working environments (Note: NOT an effective Carbon Monoxide detector – see TIF-8500A, page 47) Instantaneous response > 15" Flexible stainless steel probe >...

  • Page 11: Gauges & Hoses

    GAUGES & HOSES Manifold Gauge Sets Aluminum.............. 11 Brass ..............12 Replacement Gauges ......13 Charging Hoses .......... 15 Specialty Hoses .......... 17 Hose Fittings ..........18 General Purpose Valves ....19-21...

  • Page 12: Aluminum

    High and Low Side gauges > Brass fittings > Hanging Hook > Optical Sight glass for visual contact > Additional TIF 9600 Features 63 mm Glycerine filled gauges > 4 Way Manifold design > TIF 9600 48430 2 Valve Aluminum Manifolds...
  • Page 13 GAUGES & HOSES Two Way Brass Manifolds Our popular Side Wheel Manifold is durable and easy to use > Solid forged brass for long life; hand wheels are durable, color-coded > Lexan ® Universal Gauges – Clearly marked so they’re easy to read and protected >...

  • Page 14: Replacement Gauges/Lenses

    GAUGES & HOSES Replacement Gauges General usage gauges for multiple applications where pressure or vacuum readings are required. Dampening helps reduce excessive needle fluttering making the gauge much easier to read. Internal components are compatible with many industry applications. The ability to recalibrate the gauge is a standard feature on all gauges.

  • Page 15: Digital Gauges

    TIF9675 & TIF9685 Digital Gauges TIF digital gauges provide a quick, easy to see, accurate digital reading. These gauges allow you to read both pressure and vacuum. The high side will allow you to measure from 0 to 500 psi, while the low side ranges from –...

  • Page 16: Charging Hoses

    GAUGES & HOSES 17026 HVAC Replacement Parts Kit Contains an assortment of the most commonly needed replacement parts for repairing manifolds, hoses and various other A/C tools. Kit contains: 2 Manifold Stem Repair Kits (Conical Seal) > 2 Manifold Stem Repair Kits (Face Seal) >...

  • Page 17: Special Hoses

    GAUGES & HOSES Hose Selection Chart 1/4" FFL Enviro-Guard™ High Pressure (R-410A) Hoses with standard fittings** 740 psi working pressure/3700 psi burst pressure Length Set (Yellow, (inches) Yellow Blue Blue, Red) 67172 67272 67372 67072 1/4" FFL Enviro-Guard™ High Pressure (R-410A) Hoses with Quick Seal™ fittings* 740 psi working pressure/3700 psi burst pressure Length Set (Yellow,...

  • Page 18: Hose Accessories & Replacement Parts

    GAUGES & HOSES Special Hoses or Special Jobs Enviro-Guard™ Hoses with Ball Valves In-line ball valves control refrigerant flow with a quarter turn 65060 60" Enviro-Guard™, 1/4" FFL hoses, with Ball Valves – Set of three (Yellow, Blue, Red) 65160 60"...

  • Page 19: Hose Fittings

    GAUGES & HOSES Hose Accessories & Replacement Parts Hose Extension Coupler For connecting any number of hoses to get the required length 40404 40404 1/4" MFL x 1/4" MFL (with valve core), pkg/3 90° Style Adapters Solid brass fitting is ideal for tight spots. 10469A 1/4"...

  • Page 20: General Purpose Valves

    GENERAL PURPOSE VALVES & FITTINGS General Purpose Valves Straight Type 40464 Straight Type 1/4 MFL x 1/4 MFL 13144 Straight Type 1/4 MFL x 1/4 FPT 40464 Quick Coupler Style Valve 40380 40380 Quick Coupler Style Valve 1/4 FFL Coupler x 1/4 MFL Gauge Cocks Brass Tee Handle 40479...
  • Page 21 GAUGES & HOSES General Purpose Fittings Tees/Fittings 40382 1/4 MFL Branch with core x 1/4 OD tube or 3/8 OD solder, pkg/3* 40383 1/4 MFL Branch with core x 5/16 OD tube or 3/8 OD solder, pkg/3* 40384 1/4 MFL Branch with core x 3/8 OD tube or 40382 40386 1/2 OD solder, pkg/3*...

  • Page 22: Fittings

    GENERAL PURPOSE VALVES & FITTINGS 1/4" Valve Core Remove Installers 13145 Valve core remover/installer with 6 valve cores 13145 Charging Valve 43657 Replacement spine valve for 14476 Charging Valve Valve Core Remover/Installer 18560 Remove and install valve cores from a 1/4" male flare access fitting without the loss of refrigerant.

  • Page 23: Recovery

    RECOVERY ProVax NextGen Portable AC Service System US Patent #4,523,897; 5,209,653; others pending A Revolution in Refrigerant Recovery and Evacuation Features Combines a Refrigerant Recovery Unit and Vacuum Pump in > one portable system Recovers all halogenated refrigerants (CFC/HCFC/HFC), > including the new high pressure refrigerants, R410A Proprietary “Oil-Less”...
  • Page 24 RECOVERY RG5410AEX RG5410AEX Refrigerant Recovery Machine US Patent #D474,209 Recovers all commonly used CFC, HFC, HCFC > R410-A Refrigerants (including [Puron™]) Designed for use with High Pressure refrigerants > Selectable High Pressure safety “cut off” switches > (400 or 550 psi) Proprietary “Oil-less”...
  • Page 25 RECOVERY RG5410A Refrigerant Recovery Machine US Patent #D474,209 Recovers all commonly used CFC, HFC, HCFC Refrigerants > (including R410-A [Puron™]) Designed for use with High Pressure refrigerants > Selectable High Pressure safety “cut off” switches (400 or > 550 psi) Proprietary “Oil-less”...
  • Page 26 RECOVERY Minimax Refrigerant Recovery Machine US Patent D482,373 Maximum size - Maximum performance; ideal for residential and > appliance service Recovers all commonly used CFC, HFC, HCFC Refrigerants > (including Puron™ R-410A) Proprietary “Oil-less” compressor capable of handling both liquid >...
  • Page 27 RECOVERY 25175B Refrigerant Recovery Machines Feature: Recovers all commonly used CFC, HCF, HFCF refrigerants, > including R-410A Automatic High Pressure cut-out switch for safety > Direct liquid recovery without damaging the compressor > All new proprietary “Oil-less” compressor and 1/2 hp motor >...
  • Page 28 RECOVERY 25200B Refrigerant 25200B Refrigerant Recovery Machine Designed for the recovery medium and high-pressure > refrigerants, including R-410A Automatically switches from liquid to vapor recovery > Provides continuous recovery without the need to change the > hose or flip a switch Automatic high pressure cut-out switch for safety >...

  • Page 29: Recharge Machine

    RECOVERY 17800B Refrigerant Recovery, Recycle, Evacuate and Recharge Machine Recovers, Recycles, Evacuates and Recharges > Continuous operation – all through one hook up > In-plant maintenance – Ideal for departments that use > different types of refrigerants for various systems Multiple Refrigerants –...

  • Page 30: Evacuation

    EVACUATION The Importance of The Importance of Deep Vacuum The purpose of a vacuum pump is to remove moisture and air from an A/C-R system. Modern systems are built tighter and charges are more critical. That means these systems have a greater sensitivity to moisture and other contaminants, making thorough evacuation more important than ever before.
  • Page 31 EVACUATION Selecting the Right Size Pump The more air a pump moves, the faster it can reach an acceptable vacuum. A smaller pump takes more time to evacuate a system than one that’s the correct size for the job. Use this Chart as a Guide to Selecting the Right Size Pump System Recommended Pump Size CoolTech...

  • Page 32: Vacuum Pump Oil

    EVACUATION Premium High Vacuum Premium High Vacuum Pump Oil The performance of your pump depends largely on the quality and purity of the vacuum pump oil. Robinair’s oil is engineered to maintain maximum viscosity at high running temperatures and to improve cold weather starts.
  • Page 33 EVACUATION CoolTech® Vacuum Pumps > Power and capacity for a wide range of service applications. > High CFM rating for fast, thorough evacuation. > Two-stage rotary vane design. Features: No. 15120A Iso-Valve™ – Isolates the pump from the system with just a 10 CFM quarter-turn.
  • Page 34 EVACUATION VacuMaster™ Economy Vacuum Pumps > Performance tested to meet Robinair’s high standards > Power and capacity for a wide range of service applications. > High CFM rating for fast, thorough evacuation. > Two-stage rotary vane design. Features: Two-stage Design – Cleans the system more thoroughly than a single-stage pump;...
  • Page 35 EVACUATION Vacuum Valve Assembly Valve assemblies give the service technician maximum control during evacuation and recharging. Installed directly to the vacuum pump, they connect the pump, manifold and thermistor gauge, providing one central control. Saves time – no need to connect/disconnect hoses. Made of durable forged brass for long life. 13047A 1/2"...
  • Page 36 EVACUATION The Importance of Measuring Vacuum Moisture in an A/C system is a serious problem for the If you look at the compound gauge face, you can see that technician – it causes freeze-ups and corrosion, seriously it’s not possible to clearly differentiate between damaging the A/C system.
  • Page 37 EVACUATION Thermistor Vacuum Gauge Solid-state instrument constantly monitors and visually indicates the vacuum level in 10 segments from atmosphere to 50 microns. > LCD screen can be read even in direct sunlight and minimizes battery consumption. > There are no adjustments to make, no calibrations for atmospheric pressure or altitude.
  • Page 38 Three foot sensor cord > Built into ABS Carrying Case > One year warranty > TIF 9450D S p e c i f i c a t i o n s Range 500,000 to 200 microns Hg (auto ranging) Resolution 100/10/1 microns Hg Vacuum Fitting 1/4"...

  • Page 39: Charging/Scales

    Compact design, completely portable > Can be used with all refrigerants > Removable control box with prop stand/hanging hook > Compatible with TIF 9020 for automatic capability > CE approved > Two year warranty > TIF 9010A ADS-100...
  • Page 40 Charging and Recovery capabilities > CE approved > One year warranty > Optional Accessories Part Number TIF 9030 Soft case TIF9031 TIF9055 Programmable Charging/ Recovery Meter 220 pound OR 100 kg capacity > Allows automatic Charging or Recovery operations >...

  • Page 41: Charging Cylinders

    CHARGING/SCALES Dial-A-Charge Charging Cylinders ® U.S. Patent No. 3,052,101; Canadian Patent No. 688,223 Allows systems to be charged quickly, with the precise amount of > refrigerant required by the manufacturer Simply “dialing” the shroud to correspond with the pressure gauge, >...

  • Page 42: Heater Blankets

    CHARGING/SCALES 16258 Oil Injector Syringe-Type, allows you to add refrigerant oil to a fully charged > A/C system Simply fill the barrel with the amount of oil required > 16258 Check valve prevents any “back flow” of refrigerant > 1/4" SAE fitting >...

  • Page 43: Diagnostic Instruments

    DIAGNOSTIC INSTRUMENTS TIF7000 Digital Thermometer/Pyrometer The TIF7000, the original TIF Thermometer, comes with 3 different probes. The first is the Air Probe which can be used for instant readings of air temperatures from –40ºF to over 1000ºF. The second probe, the Surface Probe, is used for quick surface readings from –40ºF to 1999ºF.
  • Page 44 (TIF7612 and TIF7620 only) (MAX), (MIN), Difference between MAX and MIN (DIF), and average > (AVG) modes are available in TIF7612 and TIF7620 The new TIF IR thermometers incorporate visual low battery indication > TIF7612 and simple operation of two “AAA” batteries...
  • Page 45 DIAGNOSTIC INSTRUMENTS TIF7201 Pocket IR Thermometer System-on-a-Chip SoC technology: > compact and lightweight Backlit LCD display w/ dual readings > °C / °F Switch and MAX function > Auto power off after 15 sec. > Battery level indication > Distance to spot (D/S): 1:1 >...

  • Page 46: Analog & Digital Thermometers

    DIAGNOSTIC INSTRUMENTS Analog Thermometers These pocket thermometers include a protective sheath with pocket clip. > Model No. Temperature Range Dial Diameter 10596 –40º to 160ºF 1" 10597 0º to 220ºF 1" 40859 –40º to 70ºC 1" 10945 10945 0º to 220ºF 1-3/4"...

  • Page 47: Hvac Analyzer

    DIAGNOSTIC INSTRUMENTS TIFVA500A Digital HVAC Analyzer The TIF VA500A offers a range of features never before included in a single instrument. More than just an Anemometer, the VA500A measures all HVAC inlet and outlet variables, allowing an intelligent analysis of system performance.
  • Page 48 External AC power adapter for continual monitoring > Fast, simple calibration procedure > Flip out stand for desktop monitoring > TIF 8600 S p e c i f i c a t i o n s Ranges Carbon Dioxide (CO2) 0 to 10,000 ppm Temperature 32ºF to 122ºF (0ºC to 50ºC)

  • Page 49: Carbon Monoxide Analyzer

    Headphones included for high noise areas or for privacy > Cordless and portable > Ranges from 1 – 10,000 ppm with resolution of 1-ppm > TIF 8500A Replacement Parts (supplied with product) Part Number Replacement Filter TIF8501 Replacement Sensor TIF8505...

  • Page 50: Refrigerant Identifier

    DIAGNOSTIC INSTRUMENTS 42160 Gas Manifold Pressure Test Kits Use these handy kits to Measure Natural gas or LP gas > pressure across appliance manifolds Test gas stoves, furnaces, dryers and other gas appliances > Economical and accurate – easier to use than a manometer >...

  • Page 51: General Tools

    GENERAL TOOLS Valve Cores 40352 Replacement valve cores (pkg/6) > 40352 Pinch-Off Tool 12294 Patented clamping mechanism quickly and > securely pinches off tubing and cloth-reinforced hose Comfortable cushion grip > Ideal for closing off compressor process > tubes For 3/16", 1/4", 5/16" and 3/8" tubing 12294 >...
  • Page 52 GENERAL TOOLS Tubing Cutter with Tubing Cutter with Deburring Tool 42028 Aluminum alloy body and nickel-chrome durable finish > Includes tubing deburring tool located on the head of cutter > For use on cooper, aluminum, steel and stainless steel tubing >...
  • Page 53 GENERAL TOOLS Double Flaring Tool Set 6506 Also performs 45° single flares on 4mm, > 4.75mm, 6mm,8mm, 10mm, 12mm, and 14mm copper, aluminum, brass,and magnesium tubing. Includes tubing cutter and adapters for > doubleflaring 4mm, 4.75mm, 6mm, 8mm, and 10mm tubing 6503 Also performs 45°...
  • Page 54 GENERAL TOOLS Process Tube Adapter Kit Process Tube Adapter Kit 12458 Kit provides the quickest and easiest means of connecting > charging lines to process tubes for evacuating and recharging a system Assures an absolute seal between tubing and the charging >...

  • Page 55: Tube Bender

    GENERAL TOOLS 4-In-1 Tube Bender 18548 Bends four sizes of soft or annealed tubing > Prevents crimping, flattening or scratching > Calibration allows duplication of any angle > Long handles (8-1/2") no extensions required > “Glass/plastic” construction combines strength > with lightweight durability 18548 For use on 3/16", 1/4", 5/16"...

  • Page 56: Floor Crane

    GENERAL TOOLS Mechanical Grip-O-Matic Puller Mechanical Grip-O-Matic Puller 1023 2-ton, 2/3-jaw, 1 Lb. ; 5 Oz (Reversible Jaws) > Forged from quality steel, heat treated, and > subjected to rigorous tests which exceed its rated capacity. 1025 2-ton, Long 2-Jaw; 21 lbs. (Reversible Jaws) >...
  • Page 57 GENERAL TOOLS Ratcheting Terminal Crimper 4497 Heavy-gauge steel crimping tool designed for insulated > wire terminals. Ratcheting action crimps terminal to correct tightness > on the wire, making crimping fast and easy. Insulated handles with compound mechanical leverage > for power. For wire sizes: AWG 22-18 (0.6mm—1.0mm) red >...
  • Page 58 GENERAL TOOLS Hose Clamp Plier Set 4502 Includes a cross-slotted jaw pliers and a wide, flat-band > hose clamp pliers. Services most ring-type or flat-band hose clamps. The clamps are held open with a ratchet locking > mechanism. Jaws swivel to access hose clamps in any position.
  • Page 59 GENERAL TOOLS Straight-Blade Hose Cutter 4509 Cuts rubber hoses ranging from 1/4" to 1-1/2". > Simply place hose in tool and squeeze handle to cut. > Hose Pinch-off Pliers Set 4510 Shuts off flow through vacuum lines, fuel lines, coolant lines, etc. >...
  • Page 60 GENERAL TOOLS Mini Snap Ring Plier Set 4514 Small-size pliers for work in tight areas. > Service S-ring and R-ring clips, internal or external, straight or angled. Ruggedly built of heat-treated chrome molybdenum steel. Set includes two internal snap ring pliers (one straight, one >...
  • Page 61 GENERAL TOOLS Punch & Chisel Set 4605 Safety protective handle allows easy grip and protects > hand from being hit by hammer. 12 punches and chisels included: > 5 flat chisels: 1/2", 5/8", 3/4", 7/8", and 1" wide blades 1 cape chisel: 1/4" wide blade 2 taper punches: 1/8"...
  • Page 62 GENERAL TOOLS 3/8" Impact Driver 4608 Loosens hard-to-turn screws, bolts or nuts. > Handle design prevents possibility of hitting hand with > hammer when striking impact driver. Bit holder has 3/8" drive and 5/16" hex for Phillips and flat > screwdriver bits.
  • Page 63 GENERAL TOOLS Screw Extractor Set 4651 Removes broken studs and bolts. > Includes ten guide bushings, five drill bits and five > screw extractors with extractor nuts. Drill bits are left handed to help removal. > Blue Force — Handled Pry Bar Set Finally, a heavy-duty pry bar made of tempered >...

  • Page 64: Heat Gun

    GENERAL TOOLS Heat Gun 14450 Direct heat source with three > settings – 500º F/750º F/Air-only Lightweight, shock-proof & > cool running with tough Lexan ® housing Fast heating/drying of materials > Quick curing/drying of epoxies > Applying shrink tubing >...
  • Page 65 I N D E X Products Listed by Part Number Item ...Page # Item ...Page # Item ...Page # Item ...Page # Item ...Page # Item ...Page # Item ...Page # Item ...Page # 1023....55 11735 ....13 16263....6 31079....
