SAN18B Instruction Manual
Milestone AV Technologies
6436 City West Parkway
Eden Prairie, MN 55344 USA
Customer Service
Americas: 800-359-5520 • 651-484-7988 • info@sanus.com
Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe.sanus@milestone.com
Asia Pacifi c: 86 755 8996 9226 • sanus.ap@milestone.com
accents.sanus.com
©2012 Milestone AV Technologies, a Duchossois Group Company.
All rights reserved. Accents is a Milestone brand.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
(6904-002028 <01>)
Scan here to view
product demo and install
videos or visit san.us/111
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for sanus accents SAN18B
Summary of Contents for sanus accents SAN18B
- Page 1 SAN18B Instruction Manual Scan here to view product demo and install videos or visit san.us/111 Milestone AV Technologies 6436 City West Parkway Eden Prairie, MN 55344 USA Customer Service Americas: 800-359-5520 • 651-484-7988 • info@sanus.com Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe.sanus@milestone.com Asia Pacifi...
-
Page 2: Technical Specifications
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Specifi cations Weight capacity-DO NOT EXCEED: 22.6 kg (50 lb) includes TV and any accessories Tilt: ±12° CAUTION: Avoid potential personal injuries and property damage! Do not use this product for any purpose not explicitly specifi ed by manufacturer. -
Page 3: Supplied Parts And Hardware
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;... - Page 4 Before You Begin - Determine TV Hole Pattern 200 x 200 mm TV hole pattern Install bracket extensions [03] ONLY if your TV has a 200 x 200 mm (79⁄10 x 79⁄10 in.) hole pattern. [01] [03] [05] [06] 6904-002028 <01>...
- Page 5 1 Select TV Hardware and Mount TV Bracket 1-1 Select the hardware diameter and length Your TV type will help you determine which hardware confi guration to use. Installation option without spacers (TVs with fl at backs) Installation option using spacers (TVs with irregular backs) Hand thread screws into the threaded inserts on the back of your TV to determine the correct screw diameter (M4, M6, or...
- Page 6 1-2 Attach bracket to a TV with an irregular back Ensure the bracket is level on the back of the TV. Standard confi gurations are shown. NOTE: If the hole pattern on your TV is 75mm x 75mm the washers [16,17] will not be used. For special applications, or if you are uncertain about your hardware selection, contact Customer Service.
- Page 7 2 Mount the Wall Plate 12 mm 3 mm (7/16 in.) (1/8 in.) 2-1 Locate stud Verify the center of the stud using an awl, a thin nail, or an edge to edge stud fi nder. < 16 mm CAUTION: Avoid potential personal injuries and property (5/8 in.) damage!
- Page 8 3 Hang the TV onto the Wall Plate For tilting see option A For low profi le see option B HEAVY! You will need assistance with this step. [01] [02] [01] 34.92 mm 3⁄8 in.) [02] 6904-002028 <01>...
- Page 9 4 Secure the TV to the Wall Plate Secure the TV to the wall plate using the locking tab (T). NOTE: If you need to remove the TV from the wall plate, unsecure the locking tab (T). 6904-002028 <01>...
- Page 10 5 Adjust Up / Down Tilt Tension Loosen the tilt tension nut to adjust the tilt of your TV. Tighten the tilt tension nut when your TV is set to the desired tilt. ± 12° Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
