SAN55BB Instruction Manual
Milestone AV Technologies
6436 City West Parkway
Eden Prairie, MN 55344 USA
Customer Service
Americas: 800-359-5520 • 651-484-7988 • info@sanus.com
Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe.sanus@milestone.com
Asia Pacifi c: 86 755 8996 9226 • sanus.ap@milestone.com
accents.sanus.com
©2012 Milestone AV Technologies, a Duchossois Group Company.
All rights reserved. Accents is a Milestone brand.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
(6904-002023 <01>)
Scan here to view
product demo and install
videos or visit san.us/115
Advertisement
Table of Contents
Related Manuals for sanus accents SAN55BB
Summary of Contents for sanus accents SAN55BB
- Page 1 SAN55BB Instruction Manual Scan here to view product demo and install videos or visit san.us/115 Milestone AV Technologies 6436 City West Parkway Eden Prairie, MN 55344 USA Customer Service Americas: 800-359-5520 • 651-484-7988 • info@sanus.com Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe.sanus@milestone.com Asia Pacifi...
-
Page 2: Technical Specifications
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Specifi cations Weight capacity-DO NOT EXCEED: 58.9 kg (130 lb) includes TV and any accessories CAUTION: Avoid potential personal injuries and property damage! Do not use this product for any purpose not explicitly specifi ed by manufacturer. The wall must be capable of supporting fi ve times the weight of the monitor and mount combined. -
Page 3: Supplied Parts And Hardware
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: M4, M6, or M8 describes the diameter, mm describes the length of screws that are labeled M# X ##mm. - Page 4 Select TV Hardware and Mount TV Brackets 1-1 Select the hardware diameter and length Your TV type will help you determine which hardware confi guration to use. Installation option without spacers (TVs with fl at backs) Installation option using spacers (TVs with irregular backs) Hand thread screws into the threaded inserts on the back of your TV to determine the correct screw diameter (M4, M6, or...
- Page 5 1-2 Attach brackets to a TV with an irregular back Ensure the bracket is level on the back of the TV. Standard confi gurations are shown. For special applications, or if you are uncertain about your hardware selection, contact Customer Service. M4/M6/M8 [02, 03] [02]...
- Page 6 Mount the Wall Plate 13 mm Wood stud 5.5 mm (1/2 in.) (7/32 in.) 2-1 Locate stud Verify the center of the stud using an awl, a thin nail, or an edge to edge stud fi nder. < 16 mm CAUTION: (5/8 in.) Avoid potential personal injuries and property...
- Page 7 Mount the Wall Plate Solid Concrete and Concrete Block 13 mm 10 mm (1/2in.) (3/8 in.) Level wall plate [01] and mark hole locations CAUTION: Avoid potential personal injuries and property damage! Mount the wall plate [01] directly onto the concrete surface. Minimum solid concrete thickness: 203 mm (8 in.).
- Page 8 Hang the TV onto the Wall Plate There is an audible click when the brackets HEAVY! You will need [02, 03] are securely latched to the wall assistance with this step. plate [01]. [02, 03] [01] [01] [02, 03] 6904-002023 <01>...
-
Page 9: Adjust Level
Adjust Level If needed, tighten a screw on the TV brackets [02, 03] to level the TV. [02] [03] 6904-002023 <01>... - Page 10 Maintenance - Removing the TV from the Wall Plate To remove the TV from the wall plate, simultaneously pull release cords down and TV out, and then lift the TV up and out away from the wall. HEAVY! You will need assistance with this step. Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete.
