M3201C-BA
32" Class (31.5" diagonal) LCD Widescreen HD Monitor
342" LCD HD CAPABLE MONITOR
SHOWN WITH OPTIONAL STAND
• 32" Class (31.5" diagonal) Widescreen
LCD Monitor
• 1366
• 16:9 Aspect Ratio
• 178 Degree Viewing Angle (S-IPS)
Super IPS Technology allows for distortion-
free viewing from almost any angle
• 500 cd/m
• 8ms Response Time
• 1600:1 Contrast Ratio
768 Resolution (WXGA)
2
Brightness
LG Electronics USA, Inc.
• HDMI
™
/ Composite (BNC) / Component
(BNC) and S-Video inputs
• Tile Mode: 4
4 available multiplying the
size of display
• Temperature and Lamp Fault Sensor
• Limited Warranty 3 years
Note: IP-ready via interface box using LG's IP card
solutions for Digital Signage applications. Contact
DSinfo@LGcommercial.com for more information.
www.LGcommercial.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LG M3201C
Summary of Contents for LG M3201C
- Page 1 • Tile Mode: 4 4 available multiplying the size of display • Temperature and Lamp Fault Sensor • Limited Warranty 3 years Note: IP-ready via interface box using LG's IP card solutions for Digital Signage applications. Contact DSinfo@LGcommercial.com for more information. www.LGcommercial.com...
-
Page 2: Specifications
Screen image is simulated. Dimensions and weights are approximate. Design, specifications, and features subject to change without notice. ©Copyright 2008 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a registered trademark of LG Corp. VESA All other product and brand names are trademarks or registered trademarks of their respective companies. HDTV monitors require optional set-top box to receive high-definition broadcast.
