- Page 1 27-HTFL2E 27-HTFL2T HEDGE TRIMMER EURO/TRIMA Carefully read the operating instructions before using the product! Operating instructions translated from Swedish...
-
Page 2: Table Of Contents
Deviation form Warranty terms and conditions Kellfri designs and supplies efficient, affordable machinery and components for forestry, ag- riculture, construction and gardening in Sweden, the rest of the Nordic region and Europe. Please note that the information in this document is general and may not pertain to your par- ticular machine. -
Page 3: Introduction
It is the user’s responsibility to read through the instructions and com- ply with them. Kellfri AB has a policy of continuous product development and therefore reserves the right to make modifications, e.g. to the design and appearance of the product, without prior notice. -
Page 4: Safety Instructions
If the safety instructions or the operating manual are damaged, or become unusable for any other reason, new copies may be ordered from: Kellfri AB, Munkatorpsgatan 6, SE-532 40 SKARA, Sweden. Tel: +46 511 242 50 The safety instructions can also be downloaded from Kellfri’s website: www.kellfri.co.uk... -
Page 5: Personal Protection
PERSONAL PROTECTION Always wear suitable clothing and shoes. Do not wear loose clothing or jewellery while work- ing with the machine or the product. Long hair should be tied up when working with equip- ment that has moving parts. Use protective gloves to avoid the risk of burns if hot surfaces such as exhaust pipes are touched, and to avoid oil and petrol getting in contact with the skin. -
Page 6: Use
Only those who understand the safety instructions and the operating instructions may use the equipment or product. There is a risk of crushing when working with equipment that has moving parts. Exercise caution when working with equipment with hydraulic hoses as oil under pressure can penetrate the skin. -
Page 7: Warning Decals
Check that all nuts and bolts are tightened after maintenance and service work. Always test the machine before starting work. • Always check the condition of accessories to be connected to the machine. For spare parts: Contact Kellfri Service. Table of contents... -
Page 8: Parts
PARTS Frame for frontloader Euro Trima The hedge trimmer is supplied with a Euro or Trima bracket, depending on what you Blade arm have ordered. Cylinder Selector valve (Electric valve) Shaft with cylinder bracket Start button Nylon roll Hydraulic hoses Rubber link Stabiliser Table of contents... - Page 9 FITTING Warning: risk of crushing. Make sure that the machine cannot tip over during assembly. 1. Fit frame. 2. Fitting blade arm bracket and cylinder bracket. Loosen the bolt and remove the cylinder bracket from the blade arm bar bracket (see figures below).
- Page 10 Stabiliser 3. Fitting the stabilisers. Note: Left and right. Lock with pin. 4. Fit cylinder. Cylinder Table of contents...
- Page 11 5. Fitting the blade arm. Fit the trimmer head on the blade arm bracket. Tighten bolts. 6. Fitting the bracket. Euro Trima The hedge trimmer is supplied with Euro or Trima bracket, depending on what you ordered. The photo shows the trimmer with a Euro bracket fitted. Table of contents...
- Page 12 7. Fit the hydraulic couplings. Unscrew all protective Fit the hydraulic couplings. covers (yellow). Note: Don’t forget the Tredo tray. 8. Fit the selector valve (electric valve) to the frame. Table of contents...
- Page 13 9. Connect the hydraulic hoses. Note: 90° angle Connect to the tractor. Check that all bolts and connections are tightened. Re-tighten all bolts after 1 hour of operation. Table of contents...
-
Page 14: Hydraulic Diagram
SELECTOR VALVE CYLINDER PILOT OPERATED CHECK VALVE HYDRAULIC MOTOR Table of contents... -
Page 15: Assembly 9
10. Installing the start button 2.Start by stripping off the outer sheath of the cable to expose the wires contained in the cable. Be careful not to strip or cut so deep into the outer sheath that you damage the wires. 1.Dismantle the valve connector. -
Page 16: Exploded Diagrams And Materials List
Table of contents... - Page 17 ITEM NO. SPARE PART NO. DESIGNATION QUANTITY Frame R27-HTFL.021 R27-HTFL.017 Hydraulic hose – cylinder Cylinder coupling Bolt M12x45 R27-HTFL.011 Cylinder R27-HTFL.009 Flat washer 12 (Connecting rod incl. bearing hydraulic m./blade) (Items 7, 28, 29, 30, 31, 32) Bolt M10x45 Flat washer 12 Bolt M12x65 R27-HTFL.012 Cylinder bracket...
- Page 18 Table of contents...
- Page 19 ITEM NO. SPARE PART NO. DESIGNATION QUANTITY R27-HTFL.009 Clamp ring 34.4 (Connecting rod incl. bearing hydraulic m./blade) (Items 7, 28, 29, 30, 31, 32) R27-HTFL.009 Bearing 6201 (Connecting rod incl. bearing hydraulic m./blade) (Items 7, 28, 29, 30, 31, 32) R27-HTFL.009 Rod for hydraulic motor (Connecting rod incl.
-
Page 20: Blade Guard
The original design of the machine must not, under any circumstances, be modified without the approval of the manufacturer. Unauthorised modifications and/or accessories may cause life-threatening injuries or death to users and others. Kellfri is not liable for any modifications, changes or rebuilds carried out by customers. Table of contents... -
Page 21: Notes
NOTES: Table of contents... - Page 22 NOTES: Table of contents...
-
Page 23: Deviation Form
DEVIATION FORM We are grateful for your help in pointing out any defects in the product supplied to you by Kellfri. Before making a claim, read Kellfri’s general purchase terms and conditions in our catalogue or on our website www.kellfri.co.uk, and in the operating manual if supplied. -
Page 24: Warranty Terms And Conditions
You are always welcome to give feedback or ask us about our equipment and products. Kellfri AB has a policy of continuous product development and therefore reserves the right to make modifications, e.g. to the design and appearance of the product, without prior notice.
