Sistemes Electronics Progres Agronic Smart User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1.
BASIC FUNCTIONAL DESCRIPTION ................................................................................ 2
2.
SPECIFICATIONS .......................................................................................................................... 3
3.
CONTROLLER .................................................................................................................................4
3.1. TECHNICAL CHARACTERISTICS .............................................................................4
3.2. INSTALLATION ...................................................................................................................4
3.3. CONNECTIONS .................................................................................................................4
4.
LINKING THE CONTROLLER TO THE MOBILE APP.............................................. 7
5.
QUICK GUIDE TO CONFIGURING PROGRAMMING.............................................8
6.
MOBILE APP .................................................................................................................................10
6.1. AVAILABLE PROGRAMS ............................................................................................10
6.2. UNAVAILABLE CONTROLLERS (NO CONNECTION) .............................10
6.3. CONFIGURING THE MOBILE APP ...................................................................... 11
6.4. MENU ..................................................................................................................................... 11
6.5. START ..................................................................................................................................... 12
6.6. CONFIGURING THE CONTROLLER...................................................................14
6.7. CONFIGURING THE INSTALLER .......................................................................... 17
6.8. SECTORS ............................................................................................................................. 18
6.9. CONFIGURING A SECTOR ...................................................................................... 20
6.10. PROGRAMS ..................................................................................................................... 21
6.11. CONFIGURING A PROGRAM ............................................................................... 24
6.12. STATUS OF THE CONTROLLER ......................................................................... 26
7.
MANUAL BUTTON .................................................................................................................... 27
8.
User's Manual
AGRÓNIC
SMART
Version 1

TABLE OF CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Agronic Smart and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sistemes Electronics Progres Agronic Smart

Summary of Contents for Sistemes Electronics Progres Agronic Smart

  • Page 1: Table Of Contents

    User’s Manual AGRÓNIC SMART Version 1 TABLE OF CONTENTS BASIC FUNCTIONAL DESCRIPTION ................2 SPECIFICATIONS .......................... 3 CONTROLLER ..........................4 3.1. TECHNICAL CHARACTERISTICS ................4 3.2. INSTALLATION ........................4 3.3. CONNECTIONS .........................4 3.4. CONTROL AND MANAGEMENT OF THE CONTROLLER ......6 LINKING THE CONTROLLER TO THE MOBILE APP..........7 QUICK GUIDE TO CONFIGURING PROGRAMMING..........8 MOBILE APP ..........................10 6.1.

  • Page 2: Basic Functional Description

    Basic functional description The Agrónic Smart is a battery-powered controller for latch-type solenoid valves with two or three wires, without a screen or a keypad, for use on small land parcels and in gardens. Using a Bluetooth connection, you can view and manage your controller through the free Agrónic Smart mobile app, available in the Google Play and App Stores.

  • Page 3: Specifications

    2. Specifications 10 outputs (10 sectors, or 8 sectors with Manual actions accessible from the Agrónic general and fertilizer outputs) Smart app: • 2-wire, 2-inverted-wire and 3-wire outputs ‒ Controller: Set the clock • Output activation voltage may be selected ‒...

  • Page 4: Controller

    3. Controller 3.1. TECHNICAL CHARACTERISTICS The controller is contained in a box suitable for outdoor use with the following characteristics: Box dimensions Environment Height 150 mm Temperature -10°C to +60°C Width 150 mm Humidity < 95 % Depth 90 mm Altitude 2000 m Weight...
  • Page 5 The cables on the different hoses are identified by colour and number. Connect them using the following table based on their functionality. Agrónic Smart Functionality 1 Funcionality 2 Wire colour Cable ID (2-wire latch) (3-wire latch*) White Brown Green Yellow Grey Pink Blue...

  • Page 6: Control And Management Of The Controller

    ASSEMBLY DIAGRAM – 3-WIRE LATCH WITH DIODE BOX 3.4. CONTROL AND MANAGEMENT OF THE CONTROLLER The controller is configured and managed through the Agrónic Smart app, which must be installed on a mobile device (smartphone or tablet). The controller and mobile device communicate using standard Bluetooth. This means that the mobile device must be located near the controller in order to be able to communicate with it.

  • Page 7: Linking The Controller To The Mobile App

    4. Linking the controller to the mobile app The steps to follow to connect the app to the controller are: In the controller, open the cover On the mobile device, open Google and slide the red button to the “on” Play or the App Store and download the position.

  • Page 8: Quick Guide To Configuring Programming

    5. Quick guide to configuring programming The first step is configuring the Once the controller has been controller, which may be accessed configured, we can personalise the sectors through the icon at the upper right. in which we plan to work. In each sector, we can edit the The next step is to create an name and add a photo to better identify it.
  • Page 9 Select the type of start (if we To configure a program, access the want it to irrigate on specific days or by configuration through the “edit program” frequency) and the daily number of hours icon. of irrigation. And this is the basic configuration To incorporate sectors into the program, select “sector”.

  • Page 10: Mobile App

    6. Application 6.1. AVAILABLE CONTROLLERS The first time you access the app, you will not see any controllers. In order for the available con- trollers to appear, select the “Search for devices” button. Irrigating Configuring the app Available controllers with a Bluetooth signal Controllers that have previously...

  • Page 11: Configuring The Mobile App

    6.3. CONFIGURING THE MOBILE APP Using the configuration button at the upper right, on the “available controllers” screen, we can configure app details, view the manual and familiarise ourselves with the version of the app. Wait time for the app to disconnect 6.4.
  • Page 12 6.5. HOME The home page on the app displays a summary of the controller. Close and return to Section for configuring the devices screen the controller Controller clock If the app is connected The background colour to the Internet, it will indicates the status also display weather of the controller.
  • Page 13 Different scenarios on the home screen: Controller is connected. Controller is connected. Controller is connected. There are programs Irrigation is programmed Manual status of the irrigating at this time. for today. controller is “stopped”. Controller is connected. No Controller is connected. Controller is not connected.

  • Page 14: Start

    6.6. CONFIGURING THE CONTROLLER The controller’s configuration may be accessed from the configuration icon on the home screen of the app. The Agrónic Smart can control one general output. If the controller has the Plus version, it can also control a fertilizer output. If the general valve or pump is activated, the output will be set and will correspond to physical output 10.
  • Page 15 Example graphic (general output water hammer and stop by sector): General: yes General: yes Water hammer: 005 Water hammer: 012 Stop by sector: yes Stop by sector: no • Sector hammer: This is the length of the delay (in seconds) between the opening and closure of consecutive sectors and the general output (from 0 to +/-999”).
  • Page 16 Stops are controls that act on irrigation programs based on values from the sensors that are connected to the inputs. We can configure the following stops: • Temporary stop: For programs in progress until the next program start. Any irrigation units left over from the program will be lost.

  • Page 17: Configuring The Installer

    6.7. CONFIGURING THE INSTALLER Select the “Installer access” button to enter the installer configuration section. The following may be established: • Summer/winter time: You can set the controller to automatically change the time during daylight savings in the spring and autumn. Automatically set by default.

  • Page 18: Sectors

    6.8. SECTORS The “sectors” screen displays a list of the 10 available sectors in the controller. Sector 1 corresponds to physical output 1, sector 2 to physical output 2, and so on. If you need to fertilize and/or activate the general output, this will occupy 2 sectors; as a result, only 8 sectors may be configured.
  • Page 19 DETAILED VIEW OF A SECTOR Screen displays the status of the sector and future programming in detail. The background colour indicates the status of the sector. Blue means it’s irrigating. Dark blue means it’s not irrigating. Purple line when there is a manual action. Edit the sector View of completed irrigation...

  • Page 20: Configuring A Sector

    Different scenarios on the view screen for the sector: Sector being irrigated; Sector not being Sector not being Sector stopped by a initiated by a irrigated; next irrigation irrigated; pending start manual action manual action start date is 14/08 of irrigation on program 1, which is active 6.9.

  • Page 21: Programs

    6.10. PROGRAMS Programs manage the controller’s irrigation and fertilization, control the irrigation and fertilization units in the various sectors and issue automatic commands. The Agrónic Smart has 5 programs, each of which can have up to 10 sectors. The 5 available programs, with irrigation information and associated sectors, are listed on the program screen in the app.
  • Page 22 DETAILED VIEW OF A PROGRAM • Screen displays the status of the program and assigned sectors in detail. Name of program Edit program By sliding the screen to the left, you can access more information View of time regarding the program of sector being irrigated Status and...
  • Page 23 Different scenarios on the program screen: Program irrigating; Program irrigating; Program not irrigating; Program not irrigating; initiated pursuant initiated by a next irrigation start next irrigation start to schedule manual action date is 13/08 date will be determined by input 2 Program stopped by Program paused Program delayed...

  • Page 24: Configuring A Program

    6.11. CONFIGURING A PROGRAM You can specify the following parameters for each program by selecting the button at the top right of the screen for the program to be configured: • Start irrigation by... Determine the type of start to the program: ‒...
  • Page 25 • Grouping of sectors Several sectors may be activated at the same time. The irrigation time of the sectors will be the same. Select the sector that will A drop-down menu Grouped sectors will be shown work through grouping will appear allowing together in the same field you to select one or more sectors...

  • Page 26: Status Of The Controller

    6.12. STATUS OF THE CONTROLLER The controller may be set manually as follows: • Stop controller: For irrigation in process, delaying it. Any new irrigation will also be delayed. • Start: Any irrigation that was delayed will continue from where it left off. •...

  • Page 27: Manual Button

    7. Manual button The Agrónic Smart controller has an internal button that allows you to carry out several basic functions or check the status of the controller: LED 1 LED 2 Button OFF > ON • Short pulses (< 0.5”): Indicates the status of the controller through the LED light on the controller: ‒...

  • Page 28: Troubleshooting Guide And Q&A

    8. Troubleshooting guide and Q&A Set forth below is a summary table with the most common problems that arise in using the Agrónic Smart. In addition, a possible solution to each is shown. CONNECTION PROBLEMS Problem Possible cause Solutions Review the device settings and ensure that Bluetooth on mobile the Bluetooth option has been activated.
  • Page 29 FUNCTIONALITY QUESTIONS Question Solutions Can I change the Agrónic Smart Yes. Once the controller has been linked to the app, the Agrónic parameters or the parameters of a Smart programming can be accessed even if it is unavailable (no program when the Agrónic Smart connection), and controller and program values can be modified.
  • Page 30 PERSONAL NOTES...
  • Page 31 PERSONAL NOTES...
  • Page 32 Sistemes Electrònics Progrés, S.A. Polígon Industrial, C/ de la Coma, 2 | 25243 El Palau d’Anglesola | Lleida | España Tel. 973 32 04 29 | info@progres.es | www.progres.es R-2342...
