Pipishell PIMS01 Instruction Manual

Microphone Stand
Instruction Manual
Model: PIMS01
Thank you for choosing this product! We strive to provide you with the best quality
products and services in the industry. Should you have any issues, please don't hesitate
to contact us.
Technical Support:
1-800-556-9829 Mon-Fri 10am - 5pm (PST) (USA) (CAN)
Other Info:
supportus@pipishell.net(US/CA)
Packages Included
① 5/8"-27 Male to 3/8"-16 Female Threaded Screw Adapter
②
③
④
⑤
V3.0
⑥
⑦
④
B
Step 1:
For Secure Blue you need to secure the 5/8" male copper mounting screw ② to 3/8" female
threaded screw adapter ①, then you can directly fix your Blue Microphone onto mounting screw.
For normal microphone, you do not need to use the 5/8" male copper mounting screw ②. Just
secure mic clip ③ onto female thread screw adaptor ①. You can directly fix your normal micro-
phone onto mic clip ③.
Note: The hole of some Blue Yeti Mic's mounting is bigger than 5/8" due to its manufacturing
issues. Please wrap thread tape (not included) around the screw to make it big enough to connect.
Step 2:
Put microphone arm stand
Step 3:
Tighten the knob [B] to lock
Step 4:
Adjust lever [A] to make the
maximum 2 inch thickness.
Step 5:
Tighten lever [A] to secure
Mounting Screw
Mic Clip
Microphone Arm Stand
Desk Mounting Clamp
Pop Filter
Mic Sponge
3/8"Thread
①
②
③
5/8"Thread
Mounting Screw
POP Filter
⑤
A
④ into the hole of desk mounting clamp
microphone arm stand desk mounting clamp
④ into
desk mounting clamp
⑤ adapt to the desk, shelf, counter, etc with
desk mounting clamp
⑤ to the object to be placed.
x 1
x 1
x 1
x 1
x 1
x 1
x 1
⑥
⑦
⑤ .
⑤.
