Lyyt 156.665UK User Manual

Introduction

Lyyt Seamless COB LED Strip provides a continuous 'no spot' linear lighting solution. The COB
(chip on board) technology consists of 528 tightly packed LED's per metre and a phosphor
layer coating which diffuses the LED's into a seamless array of light. The flexible COB strip is
supplied on a 5m reel and can be cut to desired length along the designated cutting points,
the strip is equipped with an adhesive backing for easy installation. The 24Vdc COB strip has
a high CRI of 90 making it suitable for a wide variety of applications, such as in hospitality,
retail, offices, displays, exhibitions and more. IP20 versions are for indoor use only.

Specification

Colour temperature
Voltage
Beam angle
LED Type
Reel Length
IP Rating
Power consumption per metre
Current
LED quantity per metre
LED spacing
Cut points
Colour rendering index
Cross-section
Weight
Installation of this COB Strip should be carried out by competent electrical installers, observing the
relevant electrical safety procedures. Lyyt COB Strip has a self-adhesive backing to allow it to be easily
attached to a clean, non-porous surface.
Where less than 5m of tape is needed, there are solder points as shown below, where the tape may be
cut to size. These cut points are at 4.5cm intervals. To re-connect to another length of tape after
www.avsl.com
24V Seamless COB LED Strip 5m
156.665UK: 6500K, 156.666UK: 3000K
24Vdc
180°
Sanan
5m
IP20
12W
500mA per metre
528
2mm
4.5cm
Ra>90
10 x 2mm
126kg
User Manual
lyyt COB LED Strip Manual
