TUBE LIGHT

Caution: Please read this guide carefully before installation

Damage caused by misuse is not covered by the warranty

Introduction

Thank you for choosing Lyyt Tube Light as part of your decorative lighting installation.

This product has been designed to add light and colour to indoor or outdoor areas for

displays, architectural highlights and themed installations. Please use the following guide to

avoid incorrect installation and get the best results from Lyyt Tube Light.

Version 1.0

Red

155.010UK

White

155.015UK

Blue

155.020UK

Green 155.025UK

Yellow 155.030UK

Orange 155.035UK

Table of Contents

Do you have a question about the 155.010UK and is the answer not in the manual?

Page 1 Version 1.0 Introduction Thank you for choosing Lyyt Tube Light as part of your decorative lighting installation. This product has been designed to add light and colour to indoor or outdoor areas for displays, architectural highlights and themed installations. Please use the following guide to...
Page 2 • Lyyt Tube Light is IP44 water-resistant and can be used outdoors. Do not submerge or install the Tube Light in water and keep away from constant flow or jets of water.
Page 3 Installation Lyyt Tube Light can be attached to building surfaces, frameworks, suspended or laid into channels as required. Mounting clips are available which can be screwed in place to fix the Tube Light to various surfaces and shape it to follow architectural details or specific designs.
Page 4 Slide the supplied heat-shrink tubing over the connector and Tube Light and push the rounded pins into the corresponding sockets inside the shroud (either way around is OK). Apply silicone glue where the Tube light emerges from the shroud and slide the heat-shrink tubing back over this joint area.
